140CHS41010模块备件

140CHS41010

主要的
产品范围Modicon Quantum自动化平台
产品或部件类型模拟输入模块
滤波器类型：单极低通-3 dB，15 Hz+/-20%
互补的
模拟输入8
输入型差动
寻址要求9输入字
模拟输入分辨率12位
线性测量范围1…5 V
4…20毫安
大输入25 mA
50伏直流电
50伏直流电
输入阻抗>20 MOhm电压
250欧姆电流+/-0.01%
精度误差+/-0.05%满刻度
+/-满量程大值的0.1%
线性误差+/-0.04%
根据温度的精度漂移+/-0.0025%满刻度/°C
<=0.005%满量程/°C
共模抑制>-72 dB 60 Hz
通道和总线之间的隔离1000 V DC
3000伏直流电持续60秒
30 V直流通道之间的隔离
更新时间：5毫秒
故障类型：断线4…20 mA
欠压范围1…5 V
标记CE
本地信号1 LED绿色总线通信存在（激活）
1 LED红色外部故障
8个LED绿色通道打开
8个LED红色通道故障
母线电流要求240 mA
功耗（W 2 W）
模块格式标准
产品重量0.66磅（美国）（0.3千克）
环境
标准CSA C22.2142号
UL 508
产品认证CUL
FM 1级2分部
符合IEC 801-2的4 kV触点抗静电放电能力
符合IEC 801-2的4 kV触点
本文件中提供的信息包含本文所含产品性能的一般说明和/或技术特征。
本文件不旨在替代，也不用于确定这些产品对于特定用户应用的适用性或可靠性。
任何此类用户或集成商都有责任对产品的相关特定应用或使用进行适当和完整的风险分析、评估和测试。
施耐德电气工业股份有限公司及其任何附属公司或子公司均不对误用本协议所含信息负责。
1/3
符合IEC 801-2的8 kV空气
符合IEC 801-3的抗电磁场9.14 V/yd（10 V/m）80…1000 MHz
运行环境空气温度32…140°F（0…60°C）
储存环境空气温度-40…185°F（-40…85°C）
相对湿度95%，无冷凝
工作高度<=16404.2英尺（5000米）
提供可持续性
绿色产品绿色产品
符合-自0852年起-施耐德电气声明
一致性
符合-自0852年起-施耐德电气符合性声明
参考不包含高于阈值的SVHC参考不包含超过阈值的SVHC
可用可用
可用可用
合同保证
保修期：18个月
模块安装支架
模块和机架的尺寸
模拟输入8通道单极模块
接线图
（1） 2个插槽
（2） 3个插槽
（3） 4个插槽
（4） 6个插槽
（5） 10个插槽
（6） 16个插槽
2/3
大通道间工作电压不能：

140CHS41010

140CHS41010
Main
Range of product Modicon Quantum automation platform
Product or component type Analogue input module
Type of filter Single pole low pass - 3 dB at 15 Hz +/- 20 %
Complementary
Analogue input number 8
Input type Differential
Addressing requirement 9 input words
Analogue input resolution 12 bits
Linear measuring range 1...5 V
4...20 mA
Absolute maximum input 25 mA
50 V DC
50 V DC
Input impedance > 20 MOhm voltage
250 Ohm current +/- 0.01 %
Absolute accuracy error +/- 0.05 % of full scale
+/- 0.1 % of full scale maximum
Linearity error +/- 0.04 %
Accuracy drift according to temperature +/- 0.0025 % of full scale/°C
<= 0.005 % of full scale/°C
Common mode rejection > - 72 dB 60 Hz
Isolation between channels and bus 1000 V DC
3000 V DC for 60 s
Isolation between channels 30 V DC
Update time 5 ms
Fault type Broken wire 4...20 mA
Undervoltage range 1...5 V
Marking CE
Local signalling 1 LED green bus communication is present (Active)
1 LED red external fault
8 LEDs green channel is turned on
8 LEDs red channel fault
Bus current requirement 240 mA
Power dissipation in W 2 W
Module format Standard
Product weight 0.66 lb(US) (0.3 kg)
Environment
standards CSA C22.2 No 142
UL 508
product certifications CUL
FM Class 1 Division 2
resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2
4 kV contact conforming to IEC 801-2
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
1 / 3
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields 9.14 V/yd (10 V/m) 80...1000 MHz conforming to IEC 801-3
ambient air temperature for operation 32...140 °F (0...60 °C)
ambient air temperature for storage -40...185 °F (-40...85 °C)
relative humidity 95 % without condensation
operating altitude <= 16404.2 ft (5000 m)
Offer Sustainability
Green Premium product Green Premium product
Compliant - since 0852 - Schneider Electric declaration
of conformity
Compliant - since 0852 - Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold Reference not containing SVHC above the threshold
Available Available
Available Available
Contractual warranty
Warranty period 18 months
Racks for Modules Mounting
Dimensions of Modules and Racks
Analog Input 8-Channel Unipolar Module
Wiring Diagram
(1) 2 slots
(2) 3 slots
(3) 4 slots
(4) 6 slots
(5) 10 slots
(6) 16 slots
2 / 3
The maximum channel to channel working voltage cannot
