140DAO84210模块备件

140DAO84210

结构清晰，优势明显
作为程序的灵活性
由于其可扩展性，AC500 PLC可以适应不同的
自动化任务：相关设备可以灵活地使用和组合
方法相应地，库存的不同部件的数量被小化。
AC500的系统架构
中央处理器
CPU在性能等级PM571，
PM581和PM591都可以在五种情况下编程
不同的语言，并提供LCD显示器
操作员键盘、一个SD卡插槽和两个
集成串行接口。CPU可以是
只需插入CPU终端基座即可。
任选地，
它们也可用于集成以太网
或ARCNET。
CPU终端基座
有三种不同版本，支持
易于插入CPU和一个、两个或四个
通信模块。
I/O模块
不同版本的数字和模拟。
可以简单地插入终端单元
–用于CPU的本地扩展（多七个
模块）和通过
FBP接口。由于可配置信道，使用灵活。
终端设备
数字和模拟的多用途使用
I/O，用于1线、2线和3线设计。启用简单
无电子设备的预接线。对于24V直流，以及
230 V AC，可选弹簧或螺钉型
终端。
通信模块
用于连接到标准现场总线系统
并集成到现有网络中。高达
任意所需组合的四个通信模块
在一个CPU上允许，导致高度通信。
FBP接口模块
带有嵌入式数字I/O和现场总线中性接口，用于连接
选择FBP连接器。通过多七个I/O模块进行分散扩展。
SD卡
可选用于数据记录、下载和上传用户程序，无需
PC或所有设备（CPU、耦合器或I/O模块）的固件更新。
2.
1.
3.
1.
5.
4.
6.
7.
1个背光LCD显示器
和键盘
2个SD卡插槽
3.插入式通信
模块（1至多4个）
4.可选集成
以太网或ARCNET
5 FBP接口（从机）
6两个串行接口，用于
编程、ASCII、Modbus或
CS31现场总线（主）
7.多可扩展七个本地
I/O模块
一般资料
总自动化（877）268-3700·www.abplc。com·sales@grossautomation.com
4.
4.
AC500可编程逻辑控制器
低压产品和系统4.3
AC500增长以满足要求
控制+通信：
分散扩张：
集中扩展：
总自动化（877）268-3700·www.abplc。com·sales@grossautomation.com
4.
4.
4.4低压产品和系统
AC500可编程逻辑控制器
网络化
网络
调制解调器
总自动化（877）268-3700·www.abplc。com·sales@grossautomation.com
4.
4.
AC500可编程逻辑控制器
低压产品和系统4.5
控制生成器AC500
Control Builder AC500是所有CPU性能类的工程工具
设计用于标准化IEC 61131-3五种编程的AC500
不同的语言。该工具的其他功能包括：整个系统的配置，包括现场总线和接口、广泛的诊断功能、报警处理、集成可视化和开放软件接口。
符合IEC 61131-3的编程
除了合适的硬件，高性能、用户友好和
方便的工程工具对于自动化应用程序的简单规划、编程、测试和调试是必不可少的。AC500 Control Builder提供以下功能：
•五种标准化编程语言：
功能框图（FBD）、指令列表（IL），
梯形图（LD）、结构化文本（ST）、顺序函数图（SFC）
•免费图形功能图（CFC）
•程序测试的调试功能：
-单步
-单循环
-断点
离线模拟
可以在不连接PLC的情况下模拟IEC 61131-3命令，包括相关故障。在程序测试之后，
应用程序可以下载到控制系统。
采样轨迹
具有事件触发器的环形缓冲区中的过程变量和数据存储的时序图。
配方管理和观察列表
显示选定变量的值。预定义值可以是：
分配给变量，然后可以一次下载到控制系统（“写入配方”）。来自控制系统的持续值
也可以预先分配读取到手表和配方管理器中，并存储在内存中（“读取配方”）
例如，也有助于设置和输入控制参数。
可视化
包括颜色更改、移动元素、位图、文本显示，允许输入
从PLC、动态条读取的设定值和过程变量显示
图表、报警和事件管理、功能键和ActiveX元素。
通信接口的配置程序
适用于PROFIBUS DP、CANopen、DeviceNet、以太网、Modbus和CS31。
开放接口
DDE和OPC。
编程
串行或通过以太网或ARCNET网络。
工程接口
公共关系

140DAO84210

140DAO84210

Clear advantages thanks to clear structures
Flexibility as program
Thanks to its scalability, the AC500 PLC can be adapted to the most different
automation tasks: The devices concerned can be used and combined in a flexible
way. The number of different parts to be kept in stock is correspondingly minimized.
The AC500’s system architecture
CPUs
CPUs are available in the performance classes PM571,
PM581 and PM591, can all be programmed in five
different languages, and provide an LCD display, an
operator keypad, an SD card slot, andtwo
integrated serial interfaces. The CPUs can be
simply plugged onto the CPU terminal base.
Optionally,
they are also available with integrated Ethernet
or ARCNET.
The CPU terminal base
Available in three different versions, enables
easy plugging of the CPU and one, two or four
communication modules.
The I/O modules
Digital and analog in different versions.
Can be simply plugged onto the terminal units
– for local expansion of the CPU (max. seven
modules) and decentralized expansion via the
FBP interface. Flexible use thanks to configurable channels.
The terminal units
Multi-purpose usage for both digital and analog
I/Os, for 1, 2 and 3-wire designs. Enable simple
prewiring without electronics. For 24 V DC and
230 V AC, optionally for spring or screw-type
terminals.
The communication modules
For connection to standard field bus systems
and integration into existing networks. Up to
four communication modules in any desired combination
are allowed at one CPU, resulting in a high degree of communication.
The FBP interface module
With embedded digital I/Os and a field-bus-neutral interface for connecting the
chosen FBP connector. For decentralized expansion by up to seven I/O modules.
The SD card
Optional for data logging, downloading and uploading the user program without a
PC or a firmware update for all devices (CPU, couplers or I/O modules).
2
1
3
1
5
4
6
7
1 Back-lighted LCD display
 and keypad
2 SD card slot
3 Plug-in communication
modules (1 to max. 4)
4 Optionally with integrated
Ethernet or ARCNET
5 FBP interface (for slave)
6 Two serial interfaces for
programming, ASCII, Modbus or
 CS31 field bus (master)
7 Expandable by up to seven local
 I/O modules
General information
Gross Automation (877) 268-3700 · www.abbplc.com · sales@grossautomation.com
4
4
AC500 PLCs
Low Voltage Products & Systems 4.3
AC500 grows to meet requirements
Control + communication:
Decentralized expansion:
Centralized expansion:
Gross Automation (877) 268-3700 · www.abbplc.com · sales@grossautomation.com
4
4
4.4 Low Voltage Products & Systems
AC500 PLCs
Networked
Network
Modem
Gross Automation (877) 268-3700 · www.abbplc.com · sales@grossautomation.com
4
4
AC500 PLCs
Low Voltage Products & Systems 4.5
Control Builder AC500
Control Builder AC500 is the engineering tool for all CPU performance classes
of the AC500, designed for standardized IEC 61131-3 programming in five
different languages. Other features of this tool are: Configuration of the overall system including field buses and interfaces, extensive diagnostic functions, alarm handling, integrated visualization and open software interfaces.
Programming in conformity with IEC 61131-3
Besides the suitable hardware, a high-performance, user-friendly and
convenient engineering tool is indispensable for simple planning, programming, testing and commissioning of an automation application. AC500 Control Builder provides the following functionalities:
• Five standardized programming languages:
 Function Block Diagram (FBD), Instruction List (IL),
 Ladder Diagram (LD), Structured Text (ST), Sequen tial Function Chart (SFC)
• Free graphical function chart (CFC)
• Debugging functions for the program test:
 - Single step
 - Single cycle
 - Breakpoint
Offline simulation
IEC 61131-3 commands can be simulated without a PLC being connected, including the relevant malfunctions. After the program test,
the application can be downloaded to the control system.
Sampling trace
Timing diagrams for process variables and storage of data in a ring buffer with event trigger.
Recipe management and watch lists
Values of selected variables are displayed. Pre-defined values can be
assigned to variables which can then be downloaded to the control system all at once (“Write recipe”). Ongoing values from the control system
can also be pre-assigned for reading into the Watch and Recipe Manager, and stored in memory there (“Read recipe). These functions are
also helpful, for example, for setting and entering control parameters.
Visualization
Includes color change, moving elements, bitmaps, text display, allows input of
setpoint values and display of process variables read from the PLC, dynamic bar
diagrams, alarm and event management, function keys and ActiveX elements.
Configurators of the communication interfaces
For PROFIBUS DP, CANopen, DeviceNet, Ethernet, Modbus and CS31.
Open interfaces
DDE and OPC.
Programming
Serial or via Ethernet or ARCNET networks.
Engineering interface
Provides access from the programming system to an external project
database in which the program source code of one or several automation projects is managed. Optionally, a version control system, such
as Visual Source Safe, can be used in order to ensure data consistency of the program code for several different users and projects.
• Comprehensive libraries.
• Windows 32-bit standard.
• Operating systems Wind
