140XTS10215模块备件

140XTS00200

内阁
这些暴露的电气连接存在电击危险：
可能导致伤害或死亡。（第7-4页）
如果在电源输入面板上断开系统电源后，输入或输出电路存在电击危险，则应关闭机柜门
包含这些外部供电的电路必须标有
警告说明存在多个电源。（第7-4页）
八、WBPEEUI240774A0
支持服务
ABB将在its的运行和维修方面提供协助
产品。销售或应用程序服务请求应为：
送到近的销售或服务办公室。ABB还可以提供安装、维修和维护合同服务。
订购零件时，使用命名法或零件编号，以及
设备手册中的零件说明。不带
说明必须从近的销售或服务处订购
办公室推荐备件清单，包括价格：
可通过近的销售或服务办公室获得。
ABB拥有现代化的培训设施，可用于培训您
全体人员还提供现场培训。联系您的
近的ABB销售办事处获取具体信息，以及
行程安排。
本说明或其他说明的其他副本可以
以合理的价格从近的ABB销售办事处获得
要价
WBPEEUI240774A0 ix
商标和注册
本文件中使用的注册和商标包括：
™ ABB Automation股份有限公司的Composer商标。
®ABB Automation股份有限公司的INFI 90注册商标。
WBPEEUI240774A0
WBPEEUI240774A0
前言
IMASI23模拟输入模块是一个和谐机架I/O
作为Symphony企业管理的一部分的模块
以及控制系统。它有16个模拟输入通道
接口隔离热电偶、毫伏、RTD和高电平
以24位的模数转换分辨率向控制器发送模拟信号。每个通道都有自己的模数转换器，可以独立配置为：
处理所需的输入类型。这些模拟输入用于：
用于监视和控制过程的控制器。
IMASI23模块可直接用于：
IMASI03或IMASI13模块只需稍作修改。功能代码216中规范S11的变更如下：
需要处理分辨率选择的差异。验证电源尺寸计算和系统电流
需求可能是必要的，因为
功耗。
本说明解释了IMASI23模块规格
和操作。它详细说明了完成所需的程序
设置、安装、维护、故障排除和
更换模块。
WBPEEUI240774A0
有效页面列表
注：更改的文本或表格由更改区域附近的垂直条表示。更改后的地物由地物标题旁边的垂直条表示。dat
W

140XTS00200

140XT cabinet.
These exposed electrical connections present a shock hazard that
can cause injury or death. (p. 7-4)
If input or output circuits are a shock hazard after disconnecting system power at the power entry panel, then the door of the cabinet
containing these externally powered circuits must be marked with a
warning stating that multiple power sources exist. (p. 7-4)
viii WBPEEUI240774A0
Support Services
ABB will provide assistance in the operation and repair of its
products. Requests for sales or application services should be
made to your nearest sales or service office. ABB can also provide installation, repair and maintenance contract services.
When ordering parts, use nomenclature or part numbers and
part descriptions from equipment manuals. Parts without a
description must be ordered from the nearest sales or service
office. Recommended spare parts lists, including prices are
available through the nearest sales or service office.
ABB has modern training facilities available for training your
personnel. On-site training is also available. Contact your
nearest ABB sales office for specific information and
scheduling.
Additional copies of this instruction, or other instructions, can
be obtained from the nearest ABB sales office at a reasonable
charge.
WBPEEUI240774A0 ix
Trademarks and Registrations
Registrations and trademarks used in this document include:
™ Composer Trademark of ABB Automation Inc.
® INFI 90 Registered trademark of ABB Automation Inc.
 WBPEEUI240774A0
WBPEEUI240774A0
Preface
The IMASI23 Analog Input Module is a Harmony rack I/O
module that is part of the Symphony Enterprise Management
and Control System. It has 16 analog input channels that
interface isolated thermocouple, millivolt, RTD, and high level
analog signals to a controller with an analog-to-digital conversion resolution of 24 bits. Each channel has its own analog-to-digital converter and can be independently configured to
handle the desired input type. These analog inputs are used by
a controller to monitor and control a process.
The IMASI23 module can be used as a direct replacement for
the IMASI03 or IMASI13 modules with only minor modifications. Changes to specification S11 in function code 216 are
required to handle the differences in resolution choices. Verification of power supply sizing calculations and system current
requirements could be necessary because of the change in
power consumption.
This instruction explains the IMASI23 module specifications
and operation. It details the procedures necessary to complete
setup, installation, maintenance, troubleshooting, and
replacement of the module.
 WBPEEUI240774A0
List of Effective Pages
NOTE: Changed text or tables are indicated by a vertical bar adjacent to the changed area. Changed figures are indicated by a vertical bar next to the figure caption. The dat
 WS00200
