. Use an Antistatic Field Service Vacuum. Remove dust
from the cards if necessary.
7. Use a Grounded Wrist Strap. Connect the wrist strap to
the appropriate grounding plug.
8. Do Not Use Lead Pencils to Set Dipswitches. To avoid
contamination of switch contacts that can result in unnecessary circuit board malfunction, do not use a lead pencil to set a
dipswitch.
Unpacking and Inspection
1. Examine the hardware immediately to verify it has not been
damaged in transit.
2. Notify the nearest ABB Automation sales office of any such
damage.
3. File a claim for any damage with the transportation company that handled the shipment.
4. Use the original packing material and container to store the
hardware.
5. Store the hardware in an environment of good air quality,
free from temperature and moisture extremes.
Setup and Installation
NOTE: Refer to Appendix C for information about replacing an IMASI03 module or Appendix B for an IMASI13 with an IMASI23 module.
Before applying power to the ASI module, make these checks:
1. Check that the module address is set correctly.
2. Check that the jumpers on the module are set correctly.
3. Be sure the dipshunts in the module mounting unit's I/O
expander bus are installed correctly.
4. Check that the jumpers on the termination units are set
correctly.
5. Verify I/O cabling connections.
Setup and Installation
WBPEEUI240774A0 3 - 3
6. Verify there is sufficient logic and field power for the modules in the module mounting unit.
Address Selection Switch (S1)
The ASI module must have an address to communicate with
the controller. The ASI module can have any one of 64
addresses (address 0 to 63) on the I/O expander bus. This
address identifies the ASI module to the controller and must be
the same as the address set in the controller configuration data
(FCs 215 and 216, specification S1).
Set the address with the eight position address dipswitch S1
(Fig. 3-1). The six right switch positions (three through eight) of
S1 set the six-bit address. Positions one and two must remain
closed (set to zero) for normal operation (Fig. 3-2).
The address is set in binary format. Table 3-1 shows some
example address settings for switch S1. Refer to Section 6 for
the diagnostic settings. Record the I/O expander bus address
of the ASI module in the space provided.
Figure 3-1. Module Layout
P 1
P 3
P 2
M O D U L E S TAT U S
LEDS
S1 ADDRESS
SWITCH
EDGE
CONNECTORS
ANALOG INPUT
C O N F IG U R AT IO N JU M P E R
BLO CKS, J1-J16
U29 S 1
J1 J2 J3 J4 J5 J6 J7 J8 J9 J10 J11 J12 J13 J14 J15
J16
T01063C
3 - 4 WBPEEUI240774A0
Setup and Installation
Configuring Inputs
Configure the ASI module by setting the specifications in FCs
215 and 216 in the controller and setting the input jumpers on
both the ASI module and the termination unit. Refer to
Section 4 for more information on configuration and calibration.
Each input on the ASI module has a jumper block. The jumper
block has different ways it can be configured: millivolt, thermocouple, RTD, voltage and current. Jumper block J1 matches
channel one, jumper block J5 matches channel five, jumper
block J16 matches channel 16, etc. Each channel can be configured independently. The ASI module can have any number
of inputs configured as resistance, low level voltage, or high
level voltage.
Figure 3-2. S1 Switch
Table 3-1. Sample Address Switch Settings (S1)
Address
Example
Switch Position1,2
(Binary Value)
3
(32)
4
(16)
5
(8)
6
(4)
7
(2)
8
(1)
08 0 0 1 0 0 0
32 1 0 0 0 0 0
63 1 1 1 1 1 1
User setting
NOTES:
1. Switch positions 1 and 2 must be closed.
2. 0 = closed or on, 1 = open or off.
1 2 3 4 5 6 7 8
OPEN
MUST
REM AIN
CLOSED
I/O
ADDRESS
MSB LSB
N OT E: OP E N PO S ITION = LOGIC 1 T01800A
Setup and Installation
WBPEEUI240774A0 3 - 5
Refer to figure 3-3 for the jumper block configurations.
Termination Unit Configuration
An NTAI06 termination unit connects the field device wiring to
the Symphony system. The terminal blocks are located on the
termination unit. Set up the termination unit to accept the
analog field inputs sent to the IMASI23 module. Refer to
Appendix A for the termination unit information.
Physical Installation
NOTE: This section provides data on the physical installation of the analog
input module only. For complete cable and termination module information,
refer to Appendix A.
The IMASI23 module occupies one slot in a standard module
mounting unit (MMU). To install the module:
1. Verify the slot placement of the module.
2. Verify that a dipshunt is in the I/O expander bus socket on
the MMU backplane between the analog input module and
controller.
3. Connect the hooded end of the cable from the termination
unit to the MMU backplane. To do this, insert the connector
into the backplane slot in the same slot as the one assigned to
the analog input module. The latches should snap securely
into place.
Figure 3-3. Six Pin Jumper Block Configurations
mV/TC V/mA RTD
T04355A
WARNING
Disconnect power before installing dipshunts on the MMU
backplane. Failure to do so will result in contact with cabinet
areas that could cause severe or fatal shock.
3 - 6 WBPEEUI240774A0
Wiring Connections and Cabling
4. Align the module with the guide rails in the module mounting unit. Carefully slide the module in until the front panel is
flush with the top and bottom of the MMU frame.
5. Push and turn the two captive latches on the module faceplate one half turn to the latched position. It is latched when
the slots on the latches are vertical and the open ends face the
center of the module. Refer to Figure 3-4.
Wiring Connections and Cabling
The IMASI23 module has three card edge connectors to supply
power (P1), connect I/O expander bus communication (P2),
and provide analog inputs (P3).
Wiring
Install the analog input module in the module mounting unit
to connect the module to the +5 VDC voltages needed to power
the circuits. The module mounting unit also connects P2 to the
I/O expander bus for communication with the controller. P1
and P2 connection require no additional wiring or cabling.
NOTE: A dipshunt on the backplane of the module mounting unit connects the
I/O expander bus between the ASI module and the controller. Locate the module so the bus can connect to them or they will not communicate.
Figure 3-4. Latched and Un-Latched Positions of Captive Latches
FRONT
