el校准
本节提供了低液位的现场校准程序，
高电平和电阻。要校准中的每个通道：
模块：
1.在系统中配置点。
2.禁用信道。
3.用两个校准点校准通道。
4.启用信道。
本示例显示了为通道1的低电平电压范围校准调整FC 217规格的值
在块地址处由FC 215引用的ASI模块上
100.FC 216的S4也必须设置为任何热电偶
或毫伏类型。
此示例显示了要在中调整规范的值
将通道现场校准数据重置为原始数据
地址1处ASI模块的出厂设置。这是
仅当现场校准不成功时才需要。
以下步骤为低电平现场校准通道1：
电压范围为-100至+100毫伏。更改规格S4
功能FC 217规范
S1 S2 S3 S4 S5 S6
禁用点1 100 1 x1 x1
点校准2 2 100 1 0值x1
启用点3 100 1 x1 x1
笔记：
1.x是一个不关心的值。
2.重复此项至少2次，使规格5等于施加的低电压值
连接到输入端子。为获得大精度，多可识别11个点，用于调整
输入通道非线性，导致10个线性段进行校正。
功能FC 217规范
S1 S2 S3 S4 S5 S6
重置工厂
标定
11 100 x1 x1 x1x1
注：
1.x是一个不关心的值。它可以保持在先前的值。
现场校准
WBPEEUI240774A0 4-9
并使用这些步骤配置高电平或电阻
输入。此外，FC 216的S4必须与以下类型一致：
正在进行校准。
1.在FC 217的控制器中定位块地址。
2.验证I/O扩展器总线分路是否到位，以
允许ASI模块总线通信。
3.在ASI模块上，对于每个输入通道，将
跳线如图3-3所示。
4.将FC 217的S2设置为FC 215的块地址
参考ASI模块。
5.将ASI模块插入通电插槽。绿色LED
将为实心，表示模块链接到中的FC 215
配置
6.让ASI模块预热至少15分钟。
7.将控制器置于执行模式。
8.将FC 217设置为所需规格。在通过执行调谐操作发出每个校准命令之后，
监控校准命令状态，以确定是否存在
现场校准期间发生错误。
本示例校准ASI模块上的通道1，该模块：
由块地址100处的FC 215引用。对于低电平
电压，通过调整这些值禁用所需通道
进入规范。
a、 禁用点（S1=1）。
b、 块地址100处FC 215引用的ASI模块
（S2=100）。
c、 ASI模块信道一（S3=1）。
9.验证低电平电压源是否连接到
待校准的ASI模块和源的通道1
电压设置为满刻度值（+100毫伏）。
注：每次电源电压改变时，至少15秒稳定
进行点场校准之前需要时间。如果源本身
具有可测量的沉降时间，将其添加到15秒的要求中。
4-10 WBPEEUI240774A0
现场校准
10.将FC 217规范S5调谐到输入电压或电阻值。对于本例，调整以下规范：
a、 执行点校准（S1=2）。
b、 块地址100处FC 215引用的ASI模块
（S2=100）。
c、 ASI模块信道一（S3=1）。
d、 校准类型零（低电平）（S4=0）。
e、 校准参数1-100（毫伏）（S5=100）。
成功的现场校准操作可通过以下方式进行验证：
检查FC 217输出N+1和N+4中的零值。如果
点校准不成功，将显示错误代码
在FC 217中，输出N+1和N+4，这有助于
故障排除。
11.成功的现场校准操作可通过以下方式进行验证：
检查FC 217中的零值，输出N+1和N+4用于
零值。如果点校准不成功，则出现错误
代码将出现在FC 217中，输出N+1和N+4
可以帮助进行故障排除。
在此步骤中，已对两个点进行了现场校准（0和完全
刻度），并且可以执行启用校准命令。
三个输入范围为低电平、高电平或RTD。
如果需要，对通道2至16重复步骤7至10
以校准ASI模块上的所有16个通道。
12.启用该点。将FC 217规范S1调谐到
启用信道。对于本例，调整这些
规格：
a、 启用信道（S1=3）。
b、 块地址100处FC 215引用的ASI模块
（S2=100）。
c、 ASI模块信道一（S3=1）。
d、 校准类型x（S4=x）。x是一个“不在乎”

140MSC10100

140MSC10100

el Calibration
This section provides field calibration procedures for low level,
high level, and resistance. To calibrate each channel in the
module:
1. Configure the point in the system.
2. Disable the channel.
3. Calibrate the channel with two calibration points.
4. Enable the channel.
This example shows the values to tune the FC 217 specifications for a low level voltage range calibration for channel one
on the ASI module referenced by the FC 215 at block address
100. S4 of FC 216 must also be set to any of the thermocouple
or millivolt types.
This example shows the values to tune the specifications to in
order to reset the channel field calibration data to the original
factory settings for an ASI module at address one. This is
needed only if the field calibration is unsuccessful.
The following steps field calibrate channel one for the low level
voltage range of -100 to +100 millivolt. Change specification S4
Function FC 217 Specifications
S1 S2 S3 S4 S5 S6
Disable point 1 100 1 x1 x1 x1
Point calibration2 2 100 1 0 value x1
Enable point 3 100 1 x1 x1 x1
NOTES:
1. x is a do not care value.
2. Repeat this entry at least 2 times making specification 5 equal to the low voltage value applied
to the input terminals. For maximum accuracy, up to 11 points may be identified for adjustment of
input channel nonlinearities, resulting in 10 linear segments for correction.
Function FC 217 Specifications
S1 S2 S3 S4 S5 S6
Reset factory
calibration
11 100 x1 x1 x1 x1
NOTE:
1. x is a do not care value. It may be left at the previous value.
Field Calibration
WBPEEUI240774A0 4 - 9
and use these steps to configure high level, or resistance
inputs. Also S4 of FC 216 must be consistent with the type of
calibration being performed.
1. Locate the block address in the controller of FC 217.
2. Verify that the I/O expander bus dipshunts are in place to
allow ASI module bus communications.
3. On the ASI module, for each input channel, place the
jumpers as shown in Figure 3-3.
4. Set S2 of FC 217 to the block address of the FC 215 which
references the ASI module.
5. Insert the ASI module into a powered slot. The green LED
will be solid indicating the module is linked to a FC 215 in the
configuration.
6. Allow the ASI module to warm up for at least 15 minutes.
7. Put the controller in execute mode.
8. Set FC 217 for the required specifications. After each calibration command is issued by performing a tune operation,
monitor the calibration command status to determine if any
errors have occurred during the field calibration.
This example calibrates channel one on the ASI module which
is referenced by the FC 215 at block address 100. For low level
voltage, disable the desired channel by tuning these values
into the specifications.
a. Disable point (S1 = 1).
b. ASI module referenced by FC 215 at block address 100
(S2 = 100).
c. ASI module channel one (S3 = 1).
9. Verify that the low level voltage source is connected to
channel one of the ASI module to be calibrated and the source
voltage is set to the full scale value (+100 millivolt).
NOTE: Each time the source voltage is changed, at least 15 seconds settling
time is required before the point field calibration takes place. If the source itself
has a measurable settling time, add this to the 15 second requirement.
4 - 10 WBPEEUI240774A0
Field Calibration
10. Tune FC 217, specification S5 to the input voltage or resistance value. For this example, tune these specifications:
a. Perform point calibration (S1 = 2).
b. ASI module referenced by FC 215 at block address 100
(S2 = 100).
c. ASI module channel one (S3 = 1).
d. Calibration type zero (low level) (S4 = 0).
e. Calibration parameter 1 - 100 (millivolts) (S5 = 100).
Successful field calibration operations can be verified by
checking for a zero value in FC 217, output N+1 and N+4. If the
point calibration was unsuccessful, an error code will appear
in the FC 217, outputs N+1 and N+4 which can aid in
troubleshooting.
11. Successful field calibration operations can be verified by
checking for a zero value in FC 217, outputs N+1 and N+4 for a
zero value. If the point calibration was unsuccessful, an error
code will appear in the FC 217, outputs N+1 and N+4 which
can aid in troubleshooting.
At this step, two points have been field calibrated (0 and full
scale) and the enable calibration command can be executed.
The three input ranges are low level, high level, or RTD.
If desired, repeat Steps 7 through 10 for channels 2 through 16
to calibrate all 16 channels on the ASI module.
12. Enable the point. Tune the FC 217, specification S1 to
enable the channel. For this example, tune these
specifications:
a. Enable the channel (S1 = 3).
b. ASI module referencaed by FC 215 at block address 100
(S2=100).
c. ASI module channel one (S3 = 1).
d. Calibration type x (S4 = x). x is a do not care
