140AIO33000模块现货

140AIO33000

140DRA84000
离散输出模块Modicon Quantum-16 O
中止
主要的
产品范围Modicon量子自动化平台
产品或组件型继电器离散输出模块
离散输出数16
互补的
触点类型和组成1个
联系表格A
离散输出电压20…250伏交流
30…150伏直流电
5…30伏直流电
寻址要求1输出字
20…250 V交流时的小负载50 mA
50毫安，5…30伏直流电
大负载电流1 A 250/30 V AC/DC 1/8 hp cosφ=0.4
1 A 250/30 V交流/直流钨
60°C时250/30 V交流/直流电阻性2 A
300 mA 30…50 V直流电阻性
浪涌电流10 A，10 ms电容
以VA为单位的开关容量500 VA电阻性
输入时的大响应时间
打开
从状态0到状态1的10ms
从状态1到状态0的20毫秒
机械耐久性10000000次循环
电气耐用性100000次循环100 mA 30…150 V DC L/R=10 ms
100000次循环2 A 30 V直流电阻性
100000周期30…150 V直流插入式继电器
100000次循环300 mA 30…150 V直流电阻
200000次循环2 A 250 V交流电阻
50000次循环500 mA 30…150 V直流电阻
变阻器内部输出过压保护，275 V
通道1780 Vrms AC之间隔离1分钟
通道和总线1780 Vrms AC之间隔离1分钟
2500伏直流电持续1分钟
免责声明：本文件不作为替代，也不用于确定这些产品对特定用户应用的适用性或可靠性
11 24, 20
1.
功耗：5.5W+（0.5X点的数量）
标记CE
总线通信的本地信号1 LED（绿色）存在（激活）
检测到外部故障的1个LED（红色）（F）
16个LED（绿色）用于输入状态
母线电流要求1100 mA
模块格式标准
净重：0.41公斤
环境
产品认证FM 1级2部分
C-Tick
戈斯特
防抱死制动系统
UL 508标准
CSA C22.2142号
静电放电电阻：符合IEC 801-2的4kV触点
符合IEC 801-2的8kV空气
符合IEC 801-3的10 V/m 80…2000 MHz电磁场电阻
运行环境空气温度0…60°C
储存环境空气温度-40…85°C
相对湿度95%，无冷凝
工作高度<=5000米
包装单元
包装单位类型：1件
包1中的单元数1
包装1重量538克
包装1高度5厘米
包装1宽16.5厘米
包装1长度31厘米
包装2重量3.766公斤
提供可持续性
绿色质产品的可持续供应状况
欧盟RoHS指令主动遵守（产品超出欧盟RoHS法律范围）
欧盟RoHS声明
无汞，是的
RoHS豁免信息是
中国RoHS法规和中国RoHS声明
环境披露产品环境概况
圆形轮廓寿命结束信息
WEEE：产品必须在特定废物收集后在欧盟市场上处置，并且
永远不要被扔进垃圾箱
合同保证
保修期18个月
2.
产品数据表
图纸尺寸
140DRA84000
模块安装支架
模块和机架的尺寸

140AIO33000

140AIO33000

140DRA84000
discrete output module Modicon Quantum - 16 O
Discontinued
Main
Range of product Modicon Quantum automation platform
Product or component type Relay discrete output module
Discrete output number 16
Complementary
Contacts type and composition 1 NO
Contact form Form A
Discrete output voltage 20...250 V AC
30...150 V DC
5...30 V DC
Addressing requirement 1 output word
Minimum load 50 mA at 20...250 V AC
50 mA at 5...30 V DC
Maximum load current 1 A 250/30 V AC/DC 1/8 hp cos phi = 0.4
1 A 250/30 V AC/DC tungsten
2 A 250/30 V AC/DC resistive at 60 °C
300 mA 30...50 V DC resistive
Surge current 10 A for 10 ms capacitive
Switching capacity in VA 500 VA resistive
Maximum response time on input
open
10 ms at state 0 to state 1
20 ms at state 1 to state 0
Mechanical durability 10000000 cycles
Electrical durability 100000 cycles 100 mA 30...150 V DC L/R = 10 ms
100000 cycles 2 A 30 V DC resistive
100000 cycles 30...150 V DC interposing relay
100000 cycles 300 mA 30...150 V DC resistive
200000 cycles 2 A 250 V AC resistive
50000 cycles 500 mA 30...150 V DC resistive
Output overvoltage protection Internal by varistor, 275 V
Isolation between channels 1780 Vrms AC for 1 minute
Isolation between channels and bus 1780 Vrms AC for 1 minute
2500 V DC for 1 minute
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
11 24, 20
1
Power dissipation 5.5 W + (0.5 x the number of points on)
Marking CE
Local signalling 1 LED (green) for bus communication is present (Active)
1 LED (red) for external fault detected (F)
16 LEDs (green) for input status
Bus current requirement 1100 mA
Module format Standard
Net weight 0.41 kg
Environment
Product certifications FM Class 1 Division 2
C-Tick
GOST
ABS
Standards UL 508
CSA C22.2 No 142
Resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields 10 V/m 80…2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0…60 °C
Ambient air temperature for storage -40…85 °C
Relative humidity 95 % without condensation
Operating altitude <= 5000 m
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Weight 538 g
Package 1 Height 5 cm
Package 1 width 16.5 cm
Package 1 Length 31 cm
Package 2 Weight 3.766 kg
Offer Sustainability
Sustainable offer status Green Premium product
EU RoHS Directive Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free Yes
RoHS exemption information Yes
China RoHS Regulation China RoHS declaration
Environmental Disclosure Product Environmental Profile
Circularity Profile End of Life Information
WEEE The product must be disposed on European Union markets following specific waste collection and
never end up in rubbish bins
Contractual warranty
Warranty 18 months
2
Product data sheet
Dimensions Drawings
140DRA84000
Racks for Modules Mounting
Dimensions of Modules and Racks
