140CFB03200模块现货

140CFB03200

140DRA84000
离散输出模块Modicon Quantum-16
O
主要的
产品范围Modicon量子自动化平台
产品或部件
类型
继电器离散输出模块
离散输出数16
互补的
触点类型和组成1个
联系表格A
离散输出电压5…30 V DC
30…150伏直流电
20…250伏交流电
寻址要求1输出字
小负载>=50 mA 5…30 V直流电
>=50 mA 20…250 V交流
大负载电流300 mA 30…50 V直流电阻
60°C时250/30 V交流/直流电阻性2 A
1 A 250/30 V交流/直流钨
1 A 250/30 V AC/DC 1/8 hp cosφ=0.4
10毫秒电容性浪涌电流<=10 A
以VA为单位的开关容量500 VA电阻性
从状态1到状态0，输入打开的响应时间<=20ms
从状态0到状态1<=10ms
机械耐久性10000000次循环
电气耐用性50000次循环500 mA 30…150 V直流电阻
200000次循环2 A 250 V交流电阻
100000次循环300 mA 30…150 V直流电阻
100000周期30…150 V直流插入式继电器
100000次循环2 A 30 V直流电阻性
100000次循环100 mA 30…150 V直流L/R=10毫秒
变阻器内部输出过压保护，275 V
通道1780 Vrms AC之间隔离1分钟
通道和母线之间隔离2500 V直流电1分钟
1780 Vrms交流1分钟
功耗：5.5W+（0.5X点的数量）
标记CE
本地信号16个LED绿色输入状态
检测到1个红色LED外部故障（F）
1个LED绿色总线通信存在（激活）
母线电流要求1100 mA
模块格式标准
产品重量：0.41公斤
2.
环境
ABS产品认证
C-Tick
FM 1级2区
戈斯特
CSA C22.2142号标准
UL 508
符合IEC 801-2的空气中8 kV静电放电电阻
符合IEC 801-2的4 kV触点
符合IEC 801-3的10 V/m 80…2000 MHz电磁场电阻
运行环境空气温度0…60°C
储存环境空气温度-40…85°C
相对湿度95%，无冷凝
工作高度<=5000米
提供可持续性
绿色质产品的可持续供应状况
符合RoHS-自1001年起-施耐德电气符合性声明
到达参考不包含高于阈值的SVHC
产品环境简介可下载产品环境
产品寿命结束说明不需要具体的回收操作
合同保证
期限：18个月
3.
产品数据表
图纸尺寸
140DRA84000
模块安装支架
模块和机架的尺寸

140CFB03200

140CFB03200

140DRA84000
discrete output module Modicon Quantum - 16
O
Main
Range of product Modicon Quantum automation platform
Product or component
type
Relay discrete output module
Discrete output number 16
Complementary
Contacts type and composition 1 NO
Contact form Form A
Discrete output voltage 5...30 V DC
30...150 V DC
20...250 V AC
Addressing requirement 1 output word
Minimum load >= 50 mA 5...30 V DC
>= 50 mA 20...250 V AC
Maximum load current 300 mA 30...50 V DC resistive
2 A 250/30 V AC/DC resistive at 60 °C
1 A 250/30 V AC/DC tungsten
1 A 250/30 V AC/DC 1/8 hp cos phi = 0.4
Surge current <= 10 A for 10 ms capacitive
Switching capacity in VA 500 VA resistive
Response time on input opening <= 20 ms at state 1 to state 0
<= 10 ms at state 0 to state 1
Mechanical durability 10000000 cycles
Electrical durability 50000 cycles 500 mA 30...150 V DC resistive
200000 cycles 2 A 250 V AC resistive
100000 cycles 300 mA 30...150 V DC resistive
100000 cycles 30...150 V DC interposing relay
100000 cycles 2 A 30 V DC resistive
100000 cycles 100 mA 30...150 V DC L/R = 10 ms
Output overvoltage protection Internal by varistor, 275 V
Isolation between channels 1780 Vrms AC for 1 minute
Isolation between channels and bus 2500 V DC for 1 minute
1780 Vrms AC for 1 minute
Power dissipation 5.5 W + (0.5 x the number of points on)
Marking CE
Local signalling 16 LEDs green input status
1 LED red external fault detected (F)
1 LED green bus communication is present (Active)
Bus current requirement 1100 mA
Module format Standard
Product weight 0.41 kg
2
Environment
Product certifications ABS
C-Tick
FM Class 1 Division 2
GOST
Standards CSA C22.2 No 142
UL 508
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2
4 kV contact conforming to IEC 801-2
Resistance to electromagnetic fields 10 V/m 80...2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0...60 °C
Ambient air temperature for storage -40...85 °C
Relative humidity 95 % without condensation
Operating altitude <= 5000 m
Offer Sustainability
Sustainable offer status Green Premium product
RoHS Compliant - since 1001 - Schneider Electric declaration of conformity
REACh Reference not containing SVHC above the threshold
Product environmental profile Available Download Product Environmental
Product end of life instructions Need no specific recycling operations
Contractual warranty
Period 18 months
3
Product data sheet
Dimensions Drawings
140DRA84000
Racks for Modules Mounting
Dimensions of Modules and Racks
Racks for Modules Mounting
Dimensions of Modules and Racks
