140CFX00210模块现货

140CFX00210

两个、三个位置的滑动开关位于CPU的前部。左派
当处于顶部位置且无内存时，开关用于内存保护
中间和底部位置的保护。上的三位滑动开关
右侧用于选择Modbus（RS232）端口的通信参数设置。
下图显示了CPU11302可用的三个选项。
将滑动开关设置到顶部位置将ASCII功能分配给端口；这个
以下通信参数已设置且无法更改。
将滑动开关设置到中间位置将分配远程终端单元（RTU）
端口的功能；设置了以下通信参数，但无法：
被改变。
注：当前面板开关处于以下状态时，CPU硬件默认为桥接模式
设置为RTU或ASCII模式。连接控制器时，面板设备连接
到CPU，Modbus端口可以与控制器通信
连接，以及登录Modbus Plus网络上的任何节点。
ASCII通信端口参数
波特率2400
奇偶
数据位7
停止位1
设备地址后面板旋转开关设置
RTU通信端口参数
波特率9600
奇偶
数据位8
停止位1
设备地址后面板旋转开关设置
ASCII码
RTU
不使用mem
关
记忆
prt
CPU模块
128 840使用100 00 2002年9月
将滑动开关设置为底部位置可使您能够分配：
软件中端口的通信参数；以下参数为：
有效的
有效通信端口参数
波特率19200 1200
9,600 600
7,200 300
4,800 150
3,600 134.5
2,400 110
2,000 75
1,800 50
数据位7/8
停止位1/2
奇偶校验启用/禁用奇数/偶数
设备地址1…247
CPU模块
840使用100 00 2002年9月129
后面板
开关
两个旋转开关位于CPU的后面板上。它们是用来
设置Modbus Plus节点和Modbus端口地址。
SW1（顶部开关）设置地址的位（十位）；SW2（底部
开关）设置地址的低位数字。下图显示了
示例地址11的正确设置。
下图显示了SW1和SW2。
下表显示了SW1和SW2地址设置。
注：这些开关可设置的地址为64。
SW1和SW2地址设置
节点地址SW1和SW2
1 ... 9 0 1 ... 9
10 ... 19 1 0 ... 9
20 ... 29 2 0 ... 9
30 ... 39 3 0 ... 9
40 ... 49 4 0 ... 9
50 ... 59 5 0 ... 9
60 ... 64 6 0 ... 4
注：如果选择“0”或大于64的地址，Modbus+LED将
“on”稳定，表示选择了无效地址。
SW 1（顶部）
SW 2（底部）
CPU模块
130 840使用100 00 2002年9月
Modbus
连接器
皮诺特
所有Quantum CPU均配备九针RS-232C连接器，支持：
Modicon的专有Modbus通信协议。以下是Modbus：
九针和25针连接的端口引脚连接。
Modbus端口
皮诺特
连接
下图显示了九针和25针的Modbus端口引脚连接-
引脚连接。
注：尽管Modbus端口在电气上支持现有的Modbus电缆，但
建议使用Modbus编程电缆（零件号990NAA2620或
990NAA26350）。该电缆设计用于安装在
量子CPU或NOM模块。
5.
IBM-AT
9针内螺纹
量子
9针公头
量子
9针公头
IBM-XT
25针内螺纹
光盘
处方药
德克萨斯州
DTR
格兰德
DSR
实时战略
CTS
德克萨斯州
DTR 20
CPU模块
840使用100 00 2002年9月131
Modbus端口
皮诺特
连接
便携式的
计算机
下图显示了九针便携式Modbus端口引脚连接
（笔记本电脑）电脑。
以下是上述数字的缩写键。
TX：传输数据DTR：数据终端就绪
接收：接收数据CTS：清除发送
RTS：请求发送NC：无连接
DSR：数据集就绪CD：载波检测
光盘
处方药
德克萨斯州
DTR
格兰德
DSR
实时战略
CTS，CTS
实时战略
DSR
格兰德
DTR
德克萨斯州
处方药
什叶

140CFX00210

140CFX00210

Two, three-position slide switches are located on the front of the CPU. The left
switch is used for memory protection when in the top position and no memory
protection in the middle and bottom positions. The three-position slide switch on the
right is used to select the communication parameter settings for the Modbus (RS232) ports.
The following figure shows the three options that are available for the CPU11302.
Setting the slide switch to the top position assigns ASCII functionality to the port; the
following communication parameters are set and cannot be changed.
Setting the slide switch to the middle position assigns remote terminal unit (RTU)
functionality to the port; the following communication parameters are set and cannot
be changed.
Note: The CPU hardware defaults to bridge mode when the front panel switch is
set to RTU or ASCII mode. When networking controllers, a panel device connected
to the CPU Modbus port can communicate with the controller to which it is
connected, as well as log into any nodes on the Modbus Plus network.
ASCII Communication Port Parameters
Baud 2,400
Parity Even
Data Bits 7
Stop Bits 1
Device Address Rear panel rotary switch setting
RTU Communication Port Parameters
Baud 9,600
Parity Even
Data Bits 8
Stop Bits 1
Device Address Rear panel rotary switch setting
ASCII
RTU
not used mem
off
mem
prt
CPU Modules
128 840 USE 100 00 September 2002
Setting the slide switch to the bottom position gives you the ability to assign
communication parameters to the port in software; the following parameters are
valid.
Valid Communication Port Parameters
Baud 19,200 1,200
9,600 600
7,200 300
4,800 150
3,600 134.5
2,400 110
2,000 75
1,800 50
Data Bits 7 / 8
Stop Bits 1 / 2
Parity Enable/Disable Odd/Even
Device Address 1 ... 247
CPU Modules
840 USE 100 00 September 2002 129
Rear Panel
Switches
Two rotary switches are located on the rear panel of the CPU. They are used for
setting the Modbus Plus node and Modbus port addresses.
SW1 (the top switch) sets the upper digit (tens) of the address; SW2 (the bottom
switch) sets the lower digit (ones) of the address. The illustration below shows the
correct setting for an example address of 11.
The following figure shows SW1 and SW2.
The following table shows the SW1 and SW2 address settings.
Note: The highest address that may be set with these switches is 64.
SW1 and SW2 Address Settings
Node Address SW1 SW2
1 ... 9 0 1 ... 9
10 ... 19 1 0 ... 9
20 ... 29 2 0 ... 9
30 ... 39 3 0 ... 9
40 ... 49 4 0 ... 9
50 ... 59 5 0 ... 9
60 ... 64 6 0 ... 4
Note: If "0" or an address greater than 64 is selected, the Modbus + LED will be
"on" steady, to indicate the selection of an invalid address.
SW 1 (TOP)
SW 2 (BOTTOM)
CPU Modules
130 840 USE 100 00 September 2002
Modbus
Connector
Pinouts
All Quantum CPUs are equipped with a nine-pin RS-232C connector that supports
Modicon’s proprietary Modbus communication protocol. The following is the Modbus
port pinout connections for nine-pin and 25-pin connections.
Modbus Ports
Pinout
Connections
The following figure shows the Modbus port pinout connections for nine-pin and 25-
pin connections.
Note: Although the Modbus ports electrically support existing Modbus cables, it is
recommended that a Modbus programming cable (Part # 990NAA2620 or
990NAA26350) be used. This cable has been designed to fit under the door of a
Quantum CPU or NOM module.
5
IBM-AT
9-Pin Female
Quantum
9-Pin Male
Quantum
9-Pin Male
IBM-XT
25-Pin Female
CD
RX
TX
DTR
GRND
DSR
RTS
CTS
TX
DTR 20
CPU Modules
840 USE 100 00 September 2002 131
Modbus Ports
Pinout
Connections for
Portable
Computers
The following figure shows the Modbus port pinout connections for nine-pin portable
(laptop) computers.
The following is the abbreviation key for the above figures.
TX: Transmitted Data DTR: Data Terminal Ready
RX: Received Data CTS: Clear to Send
RTS: Request to Send NC: No Connection
DSR: Data Set Ready CD: Carrier Detect
CD
RX
TX
DTR
GRND
DSR
RTS
CTS CTS
RTS
DSR
GRND
DTR
TX
RX
SHIE
