140DAI34000模块现货

140DAI34000

两个、三个位置的滑动开关位于CPU的前部。左派
当处于顶部位置且无内存时，开关用于内存保护
中间和底部位置的保护。上的三位滑动开关
右侧用于选择Modbus（RS-232）端口的通信参数设置。
下图显示了CPU42402可用的三个选项
单元
将滑动开关设置到顶部位置将ASCII功能分配给端口；这个
以下通信参数已设置且无法更改。
将滑动开关设置到中间位置将分配远程终端单元（RTU）
端口的功能；以下通信参数已设置，不能
改变。
注：当前面板开关处于以下状态时，CPU硬件默认为桥接模式
设置为RTU或ASCII模式。连接控制器时，面板设备连接
到CPU，Modbus端口可以与控制器通信
连接，以及登录Modbus Plus网络上的任何节点。
ASCII通信端口参数
波特率2400
奇偶
数据位7
停止位1
设备地址后面板旋转开关设置
RTU通信端口参数
波特率9600
奇偶
数据位8
停止位1
设备地址后面板旋转开关设置
ASCII码
RTU
不使用mem
关
记忆
prt
CPU模块
840使用100 00 2002年9月161
将滑动开关设置到底部位置，可以分配通信
软件中端口的参数；以下参数有效。
有效的通信端口参数
波特率19200 1200
9,600 600
7,200 300
4,800 150
3,600 134.5
2,400 110
2,000 75
1,800 50
奇偶校验启用/禁用奇数/偶数
数据位7/8
停止位1/2
设备地址1…247
CPU模块
162 840使用100 00 2002年9月
后面板
开关
两个旋转开关（参见下图）位于后面板上
CPU的。它们用于设置Modbus Plus节点和Modbus端口
地址。
SW1（顶部开关）设置地址的高位（十位）；SW2（底部
开关）设置地址的低位数字。下图显示了
示例地址11的正确设置。
下图显示了SW1和SW2。
下表显示了SW1和SW2地址设置。
注：这些开关可设置的高地址为64。
SW1和SW2地址设置
节点地址SW1和SW2
注：如果选择“0”或大于64的地址，Modbus+LED将
“on”稳定，表示选择了无效地址。
SW1（顶部）
SW2（底部）
CPU模块
840使用100 00 2002年9月163
Modbus
连接器
皮诺特
所有Quantum CPU均配备九针RS-232C连接器，支持：
Modicon的专有Modbus通信协议。以下是Modbus：
九针和25针连接的端口引脚连接。
Modbus端口
皮诺特
连接
下图显示了九针和25针的Modbus端口引脚连接-
引脚连接。
注：尽管Modbus端口在电气上支持现有的Modbus电缆，但
建议使用Modbus编程电缆（零件号990NAA26320或
990NAA26350）。该电缆设计用于安装在
量子CPU或NOM模块。

140DAI34000

140DAI34000

Two and three position slide switches are located on the front of the CPU. left
When in the top position and there is no memory, the switch is used for memory protection
Protection in the middle and bottom positions. Three position sliding switch on
The right side is used to select the communication parameter settings of Modbus (RS-232) port.
The following figure shows the three options available to cpu42402:
unit
Set the slide switch to the top position to assign ASCII functions to ports; this
The following communication parameters have been set and cannot be changed.
Setting the slide switch to the middle position will assign a remote terminal unit (RTU)
Functions of ports; The following communication parameters have been set and cannot
Change.
Note: when the current panel switch is in the following states, the CPU hardware defaults to the bridge mode
Set to RTU or ASCII mode. When connecting the controller, the panel device is connected
To CPU, MODBUS port can communicate with controller
Connect, and log in to any node on the Modbus Plus network.
ASCII communication port parameters
Baud rate 2400
Parity
Data bit 7
Stop bit 1
Device address: rear panel rotary switch setting
RTU communication port parameters
Baud rate: 9600
Parity
Data bit 8
Stop bit 1
Equipment address: rear panel rotary switch setting
ASCII code
RTU
Do not use mem
shut
memory
prt
CPU module
840 use 100 00 September 2002 161
Communication can be assigned by setting the slide switch to the bottom position
Parameters of ports in software; The following parameters are valid.
Valid communication port parameters
Baud rate 19200 1200
9,600 600
7,200 300
4,800 150
3,600 134.5
2,400 110
2,000 75
1,800 50
Parity enable / disable odd / even
Data bit 7 / 8
Stop bit 1 / 2
Device address 1... 247
CPU module
162 840 use 100 00 September 2002
Rear panel
switch
Two rotary switches (see figure below) are located on the rear panel
CPU. They are used to set up Modbus Plus nodes and MODBUS ports
Address.
SW1 (top switch) sets the high (ten) bits of the address; SW2 (bottom
Switch) to set the lower digit of the address. The following figure shows:
The correct setting of the example address 11.
The following figure shows SW1 and SW2.
The following table shows the SW1 and SW2 address settings.
Note: the maximum address that these switches can set is 64.
SW1 and SW2 address settings
Node addresses SW1 and SW2
Note: if "0" or an address greater than 64 is selected, MODBUS + LED will
"On" is stable, indicating that an invalid address is selected.
SW1 (top)
SW2 (bottom)
CPU module
840 use 100 00 September 2002 163
Modbus
Connector
pinault
All quantum CPUs are equipped with a nine pin RS-232C connector, which supports:
Modicon's proprietary Modbus communication protocol. The following is MODBUS:
Nine pin and 25 pin port pin connections.
Modbus port
pinault
connect
The following figure shows the nine pin and 25 pin MODBUS port pin connections-
Pin connection.
Note: Although the Modbus port electrically supports the existing MODBUS cable
Modbus programming cable (Part No. 990naa26320 or
990NAA26350）。 This cable is designed for installation in
Quantum CPU or NOM module.
