MSK061C-0300-NN-S1-UP0-NNNN模块现货

MSK061C-0300-NN-S1-UP0-NNNN

博世力士乐股份公司|电气驱动和控制
同步伺服电机
IndraDyn S n MSK–所有要求
电气驱动和控制装置，PDF版本，状态2014-05-26，©博世力士乐股份有限公司，如有变更
文档
•项目规划
手册
•潜在的应用说明
爆炸区
紧凑有力
•大扭矩高达495 Nm
•高转速敢达9000 rpm
•编码器系统，适用于广泛多样的应用
•高防护等级IP65
•冷却系统的选择
MSK系列电机的突出特点是功率谱宽，尺寸增量小。高扭矩密度
这些同步伺服电机允许特别紧凑的设计，大扭矩高达495 Nm。
根据所需的精度水平，我们可以为电机提供标准或高精度要求的编码器系统。两种编码器版本都有单圈和多圈配置。减少了许多其他选项，如轴键槽、保持制动器
跳动和高防护等级IP65意味着它们可以与风扇、液体冷却和ATEX一起使用。
在具有高水平连续功率的应用中，可采用轴向或径向安装的鼓风机装置进行改造。本质安全IP65鼓风机
电机（UL热保护F）确保单相风机装置的可靠性，无需外部断路器。可选择的
液体冷却可用于非常高功率的应用。
技术数据
电气数据
类型：大速度、静止扭矩、大扭矩、静止电流、大电流、力矩
缺乏活力
nMax M0 MMax I
0 I
马克斯J
[1/分钟][Nm][Nm][A][A][kgm²]
MSK030B-0900
9000
0.4 1.8
1.5
6.8
0.000013
MSK030C-0900 0.8 4 0.00003
MSK040B-0450 6000
1.7 5.1
6.
0.0001 MSK040B-0600 7500 2 8
MSK040C-0450 6000
2.7
8.1
2.4 9.6
0.00014 MSK040C-0600
7500
3.1 12.4
MSK043C-0600 12.5 3.6 18.5 0.000083
MSK050B-03004300
3 9
1.8 7.2
MSK050B-0450 0.00028
6000
2.8 11.2
MSK050B-0600 3.7 14.8
MSK050C-0300 4700
5 15
3.1 12.4
MSK050C-0450 0.00033
6000
4.7 18.8
MSK050C-0600 6.2 24.8
MSK060B-03004800 3 12
0.00048 MSK060B-0600 6000 6.1 24.4
LSA控制有限公司www.LSA-Control。通用域名格式comercial@lsa-control.com (+34) 960 62 43 01
电气驱动和控制|博世力士乐公司3
同步伺服电机
IndraDyn S n MSK–所有要求
电气驱动和控制装置，PDF版本，状态2014-05-26，©博世力士乐股份有限公司，如有变更
电气数据
类型：大速度、静止扭矩、大扭矩、静止电流、大电流、力矩
缺乏活力
nMax M0 MMax I
0 I
马克斯J
[1/分钟][Nm][Nm][A][A][kgm²]
MSK060C-03004900
8 24
4.8 19.2
0.0008 MSK060C-0600 6000 9.5 38
MSK061B-0300 4200 3.5 14 1.9 8.6 0.00044
MSK061C-02003100
8 32
3.2 14.4
MSK061C-0300 4200 4.3 19.4 0.000752
MSK061C-0600 6000 7.7 34.7
MSK070C-0150 2500
13 33
4.1 16.4
MSK070C-0300 5500 8.2 32.8 0.00291
MSK070C-0450 6000 12.3 36.9
MSK070D-0150 2700
17.5 52.5
6.2 24.8
MSK070D-0300 4900 11 33 0.00375
MSK070D-0450 6000 16.6 49.8
MSK070E-0150 2200
23
70 6.4 25.6
MSK070E-0300 5300 65 15.4 49.3 0.00458
MSK070E-0450 6000 60 19.3 57.9
MSK071C-0200 3500
12 44
5.2 23.4
MSK071C-0300 5000 7.3 32.9 0.00173
MSK071C-0450 5800 8.9 40.1
MSK071D-02003200
十七点五六六
7.3 32.8
MSK071D-0300 3800 9.1 40.5 0.00255
MSK071D-0450 6000 15.4 69.3
MSK071E-02003400
23 84
10.1 45.5
MSK071E-0300 4200 12.5 56.3 0.0029
MSK071E-0450 6000 20 90.1
MSK075C-02004100
12 44
6.3 28.4
MSK075C-0300 5000 8.4 37.8 0.00352
MSK075C-0450 6000 12.6 56.7
MSK075D-02003800
17
64 8.3 37.4
MSK075D-0300 4800 66 11.7 52.7 0.0049
MSK075D-0450 6000 64 16.5 74.3
MSK075E-02003850
21
88
10.2 45.9
MSK075E-0300 5200 14.2 63.9 0.00613
MSK075E-0450 6000 86 18.6 86
MSK076C-03004700
12 43.5
7.2 32.4
0.0043 MSK076C-0450 5000 12.2 54.9
MSK100A-02004400
15 54
9.2 41.4
MSK100A-0300 5200 10.2 45.9 0.011
MSK100A-0450 6000 12 54
LSA控制有限公司www.LSA-Control。通用域名格式comercial@lsa-control.com (+34) 960 62 43 01
4博世力士乐股份公司|电气驱动和控制
同步伺服电机
IndraDyn S n MSK–所有要求
电气驱动和控制装置，PDF版本，状态2014-05-26，©博世力士乐股份有限公司，如有变更
所有信息均基于带编码器S1的电机的基本版本，无需制动。
750 V中间电路电压下的值

MSK061C-0300-NN-S1-UP0-NNNN

MSK061C-0300-NN-S1-UP0-NNNN

Bosch Rexroth AG | Electric Drives and Controls
Synchronous servo motors
IndraDyn S n MSK – for all requirements
Electric Drives and Controls, PDF version, status 2014-05-26, © Bosch Rexroth AG, subject to changes
Documentation
•    Project planning
manual
•    Application description for potentially
explosive areas
Compact and powerful
•    Maximum torques up to 495 Nm
•    Maximum speeds up to 9,000 rpm
•    Encoder systems for a wide and diverse range of applications
•    High degree of protection IP65
•    Choice of cooling systems
The particularly outstanding features of the MSK range of motors are its wide power spectrum and narrow size increments. The high torque density of
these synchronous servo motors allows a particularly compact design with maximum torques of up to 495 Nm.
Depending on the level of precision required, we can supply the motors with encoder systems for standard or high-precision requirements. Both encoder versions are available in a single-turn and multi-turn configuration. A number of further options, such as the shaft keyway, holding brake, reduced
runout and the high protection class IP65 mean that they can be used with fan, liquid cooling and ATEX.
On applications with high levels of continuous power, blower units for axial or radial mounting are available for retrofit. Intrinsically safe IP65 blower
motors (UL thermally protected F) ensure the reliability of the single-phase blower units, eliminating the need for an external circuit breaker. Optional
liquid cooling is available for very high power applications.
Technical data
Electrical data
Type Maximum speed Standstill torque Maximum torque Standstill current Maximum current Moment of
inertia
nMax M0 MMax I
0 I
Max J
[1/min] [Nm] [Nm] [A] [A] [kgm²]
MSK030B-0900
9000
0.4 1.8
1.5
6.8
0.000013
MSK030C-0900 0.8 4 0.00003
MSK040B-0450 6000
1.7 5.1
6
0.0001 MSK040B-0600 7500 2 8
MSK040C-0450 6000
2.7
8.1
2.4 9.6
0.00014 MSK040C-0600
7500
3.1 12.4
MSK043C-0600 12.5 3.6 18.5 0.000083
MSK050B-0300 4300
3 9
1.8 7.2
MSK050B-0450 0.00028
6000
2.8 11.2
MSK050B-0600 3.7 14.8
MSK050C-0300 4700
5 15
3.1 12.4
MSK050C-0450 0.00033
6000
4.7 18.8
MSK050C-0600 6.2 24.8
MSK060B-0300 4800 3 12
0.00048 MSK060B-0600 6000 6.1 24.4
LSA Control S.L. www.lsa-control.com comercial@lsa-control.com (+34) 960 62 43 01
Electric Drives and Controls | Bosch Rexroth AG 3
Synchronous servo motors
IndraDyn S n MSK – for all requirements
Electric Drives and Controls, PDF version, status 2014-05-26, © Bosch Rexroth AG, subject to changes
Electrical data
Type Maximum speed Standstill torque Maximum torque Standstill current Maximum current Moment of
inertia
nMax M0 MMax I
0 I
Max J
[1/min] [Nm] [Nm] [A] [A] [kgm²]
MSK060C-0300 4900
8 24
4.8 19.2
0.0008 MSK060C-0600 6000 9.5 38
MSK061B-0300 4200 3.5 14 1.9 8.6 0.00044
MSK061C-0200 3100
8 32
3.2 14.4
MSK061C-0300 4200 4.3 19.4 0.000752
MSK061C-0600 6000 7.7 34.7
MSK070C-0150 2500
13 33
4.1 16.4
MSK070C-0300 5500 8.2 32.8 0.00291
MSK070C-0450 6000 12.3 36.9
MSK070D-0150 2700
17.5 52.5
6.2 24.8
MSK070D-0300 4900 11 33 0.00375
MSK070D-0450 6000 16.6 49.8
MSK070E-0150 2200
23
70 6.4 25.6
MSK070E-0300 5300 65 15.4 49.3 0.00458
MSK070E-0450 6000 60 19.3 57.9
MSK071C-0200 3500
12 44
5.2 23.4
MSK071C-0300 5000 7.3 32.9 0.00173
MSK071C-0450 5800 8.9 40.1
MSK071D-0200 3200
17.5 66
7.3 32.8
MSK071D-0300 3800 9.1 40.5 0.00255
MSK071D-0450 6000 15.4 69.3
MSK071E-0200 3400
23 84
10.1 45.5
MSK071E-0300 4200 12.5 56.3 0.0029
MSK071E-0450 6000 20 90.1
MSK075C-0200 4100
12 44
6.3 28.4
MSK075C-0300 5000 8.4 37.8 0.00352
MSK075C-0450 6000 12.6 56.7
MSK075D-0200 3800
17
64 8.3 37.4
MSK075D-0300 4800 66 11.7 52.7 0.0049
MSK075D-0450 6000 64 16.5 74.3
MSK075E-0200 3850
21
88
10.2 45.9
MSK075E-0300 5200 14.2 63.9 0.00613
MSK075E-0450 6000 86 18.6 86
MSK076C-0300 4700
12 43.5
7.2 32.4
0.0043 MSK076C-0450 5000 12.2 54.9
MSK100A-0200 4400
15 54
9.2 41.4
MSK100A-0300 5200 10.2 45.9 0.011
MSK100A-0450 6000 12 54
LSA Control S.L. www.lsa-control.com comercial@lsa-control.com (+34) 960 62 43 01
4 Bosch Rexroth AG | Electric Drives and Controls
Synchronous servo motors
IndraDyn S n MSK – for all requirements
Electric Drives and Controls, PDF version, status 2014-05-26, © Bosch Rexroth AG, subject to changes
All information is based on the basic version of the motor with encoder S1, without holding brake.
Values at 750 V intermediate circuit voltage
