Temperature Control System of Cold Storage
Ting Lu 1 and Zeliang Liu 2
School of Electronic Engineering, Jiujiang University, Jiujiang, Jiangxi, China
1
luting524@163.com, 2aptblaze@163.com
Keywords: IOT; Sensor; Temperature detection
Abstract. This design is a temperature detection and automatic control system based on STC89S52
micro controller for the cold storage. Mainly consists of a power supply, a temperature detection
circuit, a system control circuit , actuator, the temperature display circuit, alarm circuit and other
parts, using DS18B20 temperature sensor detects the current temperature of cold storage through the
STC89S52 controller and auxiliary circuit to calculate the output, and the LCD display the
temperature value; if the measurement value is upper or lower limit value, the system will alarm, and
at the same time to start or stop the actuator, making the temperature quickly reached the preset range.
Introduction
Cold storage is using cooling facilities to create the proper humidity and temperature conditions of
warehouse, also known as cold storage, processing and storage of agricultural and livestock products.
It can get rid of the influence of climate, prolong the period of storage preservation of agricultural and
livestock products, in order to regulate market supply. At present, if you want to speed up the
refrigerator industry to safe, normative, environmental protection, energy saving, convenient
operation, simple structure of the direction of development, we must to improve the automatic
management level of the cold storage and management to be further strengthened, and the operation
cost is greatly cut down. This paper design temperature control system is a simple operation, and is
low-cost, easy to run. This system is DS18B20 digital sensor to detect temperature, STC89S52
microcontroller to control the cold storage temperature, with temperature, alarm and control
temperature and other functions.
Determination of the programme
For cold storage temperature control system, and the following three schemes: 1. Selection of FPGA
programmable logic device, by using FPGA device can greatly shorten the design time of the system
and make the products to market faster, and then to enhance the competition ability of the product. 2
PLC programmable logic device, the PLC as the control system, it is characterized by the processing
of the signal time is short, the progress is fast, and timely. All the I/O input and output signal are
selected photoelectric isolation, with good self identification function. 3 STC STC89S52
microcontroller, which is characterized by low power consumption, high performance, the price is
cheaper, and and the traditional 8051 microcontroller are compatible. Using this design scheme,
considering the practicality and price, the chips and devices are common components, the cheap price
for the whole system construction, and the prospect of this system is good.
This design to STC89S52 SCM as the mastermind, DS18B20 temperature sensor range - 50 DEG
to 120 DEG C, the measured temperature is sent to STC89S52 SCM, the MCU, the temperature in the
display circuit is displayed in real time, the system recovery is 1602 LCD module display. This
system can not only display the temperature can also be used to a specific temperature value is set out,
to measure the temperature real-time monitoring and control, when the temperature is higher than the
set temperature, it will immediately make corresponding temperature equipment work rapidly adjust
the cold storage temperature, so as to achieve the constant temperature state, then the control system
is stable operation, the control automation.
International Conference on Electromechanical Control Technology and Transportation (ICECTT 2015) © 2015. The authors - Published by Atlantis Press
