An I/O device may be connected to serial port 1 (or 2) on the
MVME162 or to serial port 2 (or 4) on the MVME712, but not
both. (That is, if an I/O device is connected to MVME162
port 1, no other I/O device should be connected to
MVME712 port 2; they are functionally the same port.)
General Description
MVME162/D2 1-7
1
VMEbus Interface
The optional VMEchip2 ASIC is the VMEbus interface for the MVME162.
(This option is a factory build and cannot be added in the field.) VMEchip2
features include:
❏ Two programmable 32-bit tick timers
❏ A programmable watchdog timer
❏ Programmable map decoders for the master and slave interfaces
❏ A VMEbus to/from local bus DMA controller
❏ A VMEbus to/from local bus non-DMA programmed access interface
❏ A VMEbus interrupter
❏ A VMEbus system controller
❏ A VMEbus interrupt handler
❏ A VMEbus requester
Processor-to-VMEbus transfers can be D8, D16, or D32. VMEchip2 DMA
transfers to the VMEbus, however, can be D16, D32, D16/BLT, D32/BLT, or
D64/MBLT.
No-VMEbus-Interface Option
If desired, the MVME162 can function as an embedded controller without a
VMEbus interface (i.e., without the optional VMEchip2). Contact your local
Motorola sales office for ordering information.
MCchip
The Memory Controller (MCchip) ASIC provides four 32-bit programmable
tick timers and an interface to the LAN chip, SCSI chip, serial port chip,
BBRAM, PROM/Flash, SRAM, DRAM, reset control, watchdog timers, access
timers, and interrupter logic.
Flash Memory and EPROM
The MVME162 is equipped with 1MB of Flash memory and an EPROM socket
ready for the installation of the EPROM, which may be ordered separately.
Flash memory is either a single device organized in a 1Mbit x 8 configuration
or four devices organized in a 256Kbit x 8 configuration. The EPROM location
is a standard JEDEC 32-pin PLCC capable of four Mbit densities (128 Kbit x 8;
General Information
1-8 MVME162 Embedded Controller User’s Manual
1
256 Kbit x 8; 512 Kbit x 8; 1 Mbit x 8) organized as a 512Kbit x 8 device. A
jumper allows reset code to be fetched either from Flash memory or from the
EPROM.
IndustryPack Modules
Up to four IndustryPack (IP) modules may be installed on the MVME162. The
interface between the IPs and MVME162 is the IndustryPack Interface
Controller (IPIC) ASIC. Access to the IPs is provided by four 3M connectors
located behind the MVME162 front panel.
Optional SCSI Interface
An NCR 53C710 coprocessor provides the SCSI interface for the MVME162.
Optional LAN Ethernet Transceiver Interface
An Intel 82596CA controller provides the LAN Ethernet transceiver interface
for the MVME162.
Required Equipment
The following equipment is required to complete an MVME162 system:
❏ System console terminal
❏ Disk drives and controllers
❏ Operating system
