256kbit x 8；512kbit x 8；1Mbit x 8）组织为512Kbit x 8设备。A.
跳线允许从闪存或从
EPROM。
IndustryPack模块
MVME162上多可安装四个IndustryPack（IP）模块
IPs和MVME162之间的接口为IndustryPack接口
控制器（IPIC）ASIC。通过四个3M连接器提供对IPs的访问
位于MVME162前面板后面。
可选SCSI接口
NCR 53C710协处理器为MVME162提供SCSI接口。
可选LAN以太网收发器接口
Intel 82596CA控制器提供LAN以太网收发器接口
对于MVME162。
所需设备
完成MVME162系统需要以下设备：
❏ 系统控制台终端
❏ 磁盘驱动器和控制器
❏ 操作系统
❏ MVME712系列转换模块，
MVME712A、MVME712AM、MVME72B或MVME712M）；P2适配器
板或LCP2适配器板；和电缆
注：MVME712B是与MVME712一起使用的可选设备-
MVME712-13、MVME712A和MVME712AM模块
只有
MVME162Bug固件
162Bug包MVME162BUG是一个强大的评估和调试
用于围绕基于MVME162 CISC的微型计算机构建的系统的工具。
可以使用以下工具加载和执行用户程序：
完成系统评估的操作员控制。162Bug包括命令
为了显示和修改存储器、断点和跟踪能力，
一个强大的汇编/反汇编程序，用于修补程序-
所需设备
MVME162/D2 1-9
1.
通电测试功能，验证系统的完整性。各种各样的
162处理I/O、数据转换和字符串函数的错误例程包括
可通过陷阱#15系统调用供用户程序使用。
注：MVME162Bug占用闪存的前半部分（512KB）
记忆力
MVME712系列转换模块
MVME712系列转换模块提供了
MVME162和外围设备，如EIA-232-D串行设备、SCSI
以及LAN以太网设备。P2适配器板或LCP2适配器
需要板和电缆。
注意：将外围设备连接到MVME712串行端口2和
仅4个。（串行端口2是终端或错误接口。）
不将外围设备连接到串行端口1和3，或
打印机端口。
I/O设备可以连接到上的串行端口1（或2）
MVME162或MVME712上的串行端口2（或4），但不
到两个端口。（即，如果I/O设备连接到
MVME162端口1，不应连接其他I/O设备
至MVME712端口2；它们在功能上是相同的端口。）
可用软件
MVME162的可用软件包括车载软件
调试器/监视器固件、VMEexec驱动程序包
用于MC680x0的IndustryPack模块和大量第三方应用程序-
基于系统。有关更多信息，请联系当地的摩托罗拉销售办事处

MSK100C-0300-NN-M1-AG0-NNNN

MSK100C-0300-NN-M1-AG0-NNNN

256 Kbit x 8; 512 Kbit x 8; 1 Mbit x 8) organized as a 512Kbit x 8 device. A
jumper allows reset code to be fetched either from Flash memory or from the
EPROM.
IndustryPack Modules
Up to four IndustryPack (IP) modules may be installed on the MVME162. The
interface between the IPs and MVME162 is the IndustryPack Interface
Controller (IPIC) ASIC. Access to the IPs is provided by four 3M connectors
located behind the MVME162 front panel.
Optional SCSI Interface
An NCR 53C710 coprocessor provides the SCSI interface for the MVME162.
Optional LAN Ethernet Transceiver Interface
An Intel 82596CA controller provides the LAN Ethernet transceiver interface
for the MVME162.
Required Equipment
The following equipment is required to complete an MVME162 system:
❏ System console terminal
❏ Disk drives and controllers
❏ Operating system
❏ MVME712 series transition module (MVME712-12, MVME712-13,
MVME712A, MVME712AM, MVME712B, or MVME712M); P2 Adapter
Board or LCP2 Adapter Board; and cable
Note The MVME712B is an optional device used with MVME712-
12, MVME712-13, MVME712A, and MVME712AM modules
only.
MVME162Bug Firmware
The 162Bug package, MVME162BUG, is a powerful evaluation and debugging
tool for systems built around the MVME162 CISC-based microcomputers.
Facilities are available for loading and executing user programs under
complete operator control for system evaluation. 162Bug includes commands
for display and modification of memory, breakpoint and tracing capabilities,
a powerful assembler/disassembler useful for patching programs, and a self-
Required Equipment
MVME162/D2 1-9
1
test at power-up feature which verifies the integrity of the system. Various
162Bug routines that handle I/O, data conversion, and string functions are
available to user programs through the TRAP #15 system calls.
Note MVME162Bug occupies the first half (512KB) of Flash
memory.
MVME712 Series Transition Modules
The MVME712 series transition modules provide an interface between the
MVME162 and peripheral devices such as EIA-232-D serial devices, SCSI
devices, and LAN Ethernet devices. A P2 Adapter Board or LCP2 Adapter
Board and cable are required.
Caution Connect peripheral devices to MVME712 serial ports 2 and
4 only. (Serial port 2 is the terminal or bug interface.) Do
not connect peripheral devices to serial ports 1 and 3, or to
the printer port.
An I/O device may be connected to serial port 1 (or 2) on the
MVME162 or to serial port 2 (or 4) on the MVME712, but not
to both ports. (That is, if an I/O device is connected to
MVME162 port 1, no other I/O device should be connected
to MVME712 port 2; they are functionally the same port.)
Available Software
Available software for the MVME162 includes the on-board
debugger/monitor firmware, VMEexec driver packages for various
IndustryPack modules, and numerous third-party applications for MC680x0-
based systems. Contact your local Motorola sales office for more information
