MSK071D-0300-NN-M1-UG1-NNNN模块现货

MSK071D-0300-NN-M1-UG1-NNNN

通电测试功能，验证系统的完整性。各种各样的
162处理I/O、数据转换和字符串函数的错误例程包括
可通过陷阱#15系统调用供用户程序使用。
注：MVME162Bug占用闪存的前半部分（512KB）
记忆力
MVME712系列转换模块
MVME712系列转换模块提供了
MVME162和外围设备，如EIA-232-D串行设备、SCSI
以及LAN以太网设备。P2适配器板或LCP2适配器
需要板和电缆。
注意：将外围设备连接到MVME712串行端口2和
仅4个。（串行端口2是终端或错误接口。）
不将外围设备连接到串行端口1和3，或
打印机端口。
I/O设备可以连接到上的串行端口1（或2）
MVME162或MVME712上的串行端口2（或4），但不
到两个端口。（即，如果I/O设备连接到
MVME162端口1，不应连接其他I/O设备
至MVME712端口2；它们在功能上是相同的端口。）
可用软件
MVME162的可用软件包括车载软件
调试器/监视器固件、VMEexec驱动程序包
用于MC680x0的IndustryPack模块和大量三方应用程序-
基于系统。有关更多信息，请联系当地的摩托罗拉销售办事处。
一般资料
1-10 MVME162嵌入式控制器用户手册
1.
相关文件
以下出版物适用于MVME162，并可提供：
其他有用信息。如果本产品未随附，则可能是
请联系您当地的摩托罗拉销售办事处购买。非摩托罗拉
文件可从所列来源购买。
注：尽管上述列表中未显示，但每个摩托罗拉
计算机组手册出版物编号带有后缀
包含表示的修订级别的字符
文件，如“/D2”（手册的二次修订）；
附录与手册编号相同，但有
后缀，如“/D2A1”（二个的一个补充
手册的版本）。
MVME1x7数据表包由供应商提供的外围设备数据表和手册组成
MVME162和其他板上使用的控制器。
文件标题
摩托罗拉
出版
数字
M68040微处理器用户手册M68040UM
MVME162嵌入式控制器支持信息（请参阅
（本章中的支持信息部分）
SIMVME162
MVME162Bug调试包用户手册MVME162Bug
摩托罗拉68K CISC CPU用户调试包
手册，1部分和2部分
68KBUG1/2
单板计算机SCSI软件用户手册SBCSCSSI
MVME162嵌入式控制器程序员参考
指导
MVME162PG
MVME712-12、MVME711-13、MVME71 2A、MVME7 12AM和
MVME712B转换模块和LCP2适配器板
用户手册
MVME712A
MVME712M转换模块和P2适配器板用户
手册
MVME712M
MVME1x7数据表包（用于MVME162[LX]
以及MVME166/MVME167/MVME187）
68-1X7DS
支持信息
MVME162/D2 1-11
1.
以下出版物可从指定来源获得。
通用背板总线：VMEbus，ANSI/IEEE标准1014-1987
电气和电子工程师有限公司，纽约州纽约市东47街345号
10017（VMEbus规范）。这也可用作微处理器系统
1至4字节数据总线，IEC 821总线，中央委员会局
国际电工技术；瑞士日内瓦瓦伦贝街3号。
ANSI小型计算机系统接口-2（SCSI-2），
10c版；全球工程文件，邮政信箱19539，加州欧文，92714。
IndustryPack逻辑接口规范，1.0版；GreenSpring计算机，
宾夕法尼亚州门罗奥布莱恩大道1204号

MSK071D-0300-NN-M1-UG1-NNNN

MSK071D-0300-NN-M1-UG1-NNNN

test at power-up feature which verifies the integrity of the system. Various
162Bug routines that handle I/O, data conversion, and string functions are
available to user programs through the TRAP #15 system calls.
Note MVME162Bug occupies the first half (512KB) of Flash
memory.
MVME712 Series Transition Modules
The MVME712 series transition modules provide an interface between the
MVME162 and peripheral devices such as EIA-232-D serial devices, SCSI
devices, and LAN Ethernet devices. A P2 Adapter Board or LCP2 Adapter
Board and cable are required.
Caution Connect peripheral devices to MVME712 serial ports 2 and
4 only. (Serial port 2 is the terminal or bug interface.) Do
not connect peripheral devices to serial ports 1 and 3, or to
the printer port.
An I/O device may be connected to serial port 1 (or 2) on the
MVME162 or to serial port 2 (or 4) on the MVME712, but not
to both ports. (That is, if an I/O device is connected to
MVME162 port 1, no other I/O device should be connected
to MVME712 port 2; they are functionally the same port.)
Available Software
Available software for the MVME162 includes the on-board
debugger/monitor firmware, VMEexec driver packages for various
IndustryPack modules, and numerous third-party applications for MC680x0-
based systems. Contact your local Motorola sales office for more information.
General Information
1-10 MVME162 Embedded Controller User’s Manual
1
Related Documentation
The following publications are applicable to the MVME162 and may provide
additional helpful information. If not shipped with this product, they may be
purchased by contacting your local Motorola sales office. Non-Motorola
documents may be purchased from the sources listed.
Notes Although not shown in the above list, each Motorola
Computer Group manual publication number is suffixed
with characters which represent the revision level of the
document, such as "/D2" (the second revision of a manual);
a supplement bears the same number as a manual but has a
suffix such as "/D2A1" (the first supplement to the second
edition of the manual).
The MVME1x7 Data Sheet Package is composed of vendorsupplied data sheets and manuals for the peripheral
controllers used on the MVME162 and other boards.
Document Title
Motorola
Publication
Number
M68040 Microprocessors User’s Manual M68040UM
MVME162 Embedded Controller Support Information (Refer to
the Support Information section in this chapter)
SIMVME162
MVME162Bug Debugging Package User’s Manual MVME162BUG
Debugging Package for Motorola 68K CISC CPUs User’s
Manual, Parts 1 and 2
68KBUG1/2
Single Board Computers SCSI Software User’s Manual SBCSCSI
MVME162 Embedded Controller Programmer’s Reference
Guide
MVME162PG
MVME712-12, MVME712-13, MVME712A, MVME712AM, and
MVME712B Transition Modules and LCP2 Adapter Board
User’s Manual
MVME712A
MVME712M Transition Module and P2 Adapter Board User’s
Manual
MVME712M
MVME1x7 Data Sheet Package (for use with the MVME162[LX]
and the MVME166/MVME167/MVME187)
68-1X7DS
Support Information
MVME162/D2 1-11
1
The following publications are available from the sources indicated.
Versatile Backplane Bus: VMEbus, ANSI/IEEE Std 1014-1987, The Institute of
Electrical and Electronics Engineers, Inc., 345 East 47th Street, New York, NY
10017 (VMEbus Specification). This is also available as Microprocessor system
bus for 1 to 4 byte data, IEC 821 BUS, Bureau Central de la Commission
Electrotechnique Internationale; 3, rue de Varembé, Geneva, Switzerland.
ANSI Small Computer System Interface-2 (SCSI-2), Draft Document X3.131-198X,
Revision 10c; Global Engineering Documents, P.O. Box 19539, Irvine, CA 92714.
IndustryPack Logic Interface Specification, Revision 1.0; GreenSpring Computers,
Inc., 1204 O’Brien Drive, Menlo Pa
