lthough not shown in the above list, each Motorola
Computer Group manual publication number is suffixed
with characters which represent the revision level of the
document, such as "/D2" (the second revision of a manual);
a supplement bears the same number as a manual but has a
suffix such as "/D2A1" (the first supplement to the second
edition of the manual).
The MVME1x7 Data Sheet Package is composed of vendorsupplied data sheets and manuals for the peripheral
controllers used on the MVME162 and other boards.
Document Title
Motorola
Publication
Number
M68040 Microprocessors User’s Manual M68040UM
MVME162 Embedded Controller Support Information (Refer to
the Support Information section in this chapter)
SIMVME162
MVME162Bug Debugging Package User’s Manual MVME162BUG
Debugging Package for Motorola 68K CISC CPUs User’s
Manual, Parts 1 and 2
68KBUG1/2
Single Board Computers SCSI Software User’s Manual SBCSCSI
MVME162 Embedded Controller Programmer’s Reference
Guide
MVME162PG
MVME712-12, MVME712-13, MVME712A, MVME712AM, and
MVME712B Transition Modules and LCP2 Adapter Board
User’s Manual
MVME712A
MVME712M Transition Module and P2 Adapter Board User’s
Manual
MVME712M
MVME1x7 Data Sheet Package (for use with the MVME162[LX]
and the MVME166/MVME167/MVME187)
68-1X7DS
Support Information
MVME162/D2 1-11
1
The following publications are available from the sources indicated.
Versatile Backplane Bus: VMEbus, ANSI/IEEE Std 1014-1987, The Institute of
Electrical and Electronics Engineers, Inc., 345 East 47th Street, New York, NY
10017 (VMEbus Specification). This is also available as Microprocessor system
bus for 1 to 4 byte data, IEC 821 BUS, Bureau Central de la Commission
Electrotechnique Internationale; 3, rue de Varembé, Geneva, Switzerland.
ANSI Small Computer System Interface-2 (SCSI-2), Draft Document X3.131-198X,
Revision 10c; Global Engineering Documents, P.O. Box 19539, Irvine, CA 92714.
IndustryPack Logic Interface Specification, Revision 1.0; GreenSpring Computers,
Inc., 1204 O’Brien Drive, Menlo Park, CA 94025.
82596CA Local Area Network Coprocessor data sheet, order number 290218; and
82596 User’s Manual, order number 296853; Intel Corporation, Literature
Sales, P.O. Box 58130, Santa Clara, CA 95052-8130.
NCR 53C710 SCSI I/O Processor Data Manual, order number NCR53C710DM;
and NCR 53C710 SCSI I/O Processor Programmer’s Guide, order number
NCR53C710PG; NCR Corporation, Microelectronics Products Division,
Colorado Springs, CO.
MK48T08(B) Timekeeper™ and 8Kx8 Zeropower™ RAM data sheet in Static
RAMs Databook, Order Code DBSRAM71; SGS-THOMPSON Microelectronics
Group; North & South American Marketing Headquarters, 1000 East Bell
Road, Phoenix, AZ 85022-2699.
Z85230 Serial Communications Controller data sheet, Zilog Inc., 210 Hacienda
Ave., Campbell, CA 95008-6609.
28F008SA Flash Memory Data Sheet, Order Number 290435-001; Intel Literature
Sales, P.O. Box 7641, Mt. Prospect, IL 60056-7641.
28F020 Flash Memory Data Sheet, Order Number 290245-003; Intel Literature
Sales, P.O. Box 7641, Mt. Prospect, IL 60056-7641.
Support Information
You can obtain connector interconnect signal information, parts lists, and
schematics for the MVME162 free of charge by contacting your local Motorola
sales office.
General Information
1-12 MVME162 Embedded Controller User’s Manual
1
Manual Terminology
Throughout this manual, a convention is used which precedes data and
address parameters by a character identifying the numeric format as follows:
 $ dollar specifies a hexadecimal character
% percent specifies a binary number
& ampersand specifies a decimal number
Unless otherwise specified, all address references are in hexadecimal.
An asterisk (*) following the signal name for signals which are level-significant
denotes that the signal is true or valid when the signal is low.
An asterisk (*) following the signal name for signals which are edge-significant
denotes that the actions initiated by that signal occur on high-to-low
transition.
In this manual, assertion and negation are used to specify forcing a signal to a
particular state. In particular, assertion and assert refer to a signal that is active
or true; negation and negate indicate a signal that is inactive or false. These
terms are used independently of the voltage level (high or low) that they
represent.
In this manual, MVME712 series transition
