ME712系列转换模块，请参阅中列出的手册
1章中的相关文档（MVME162嵌入式控制器
程序员参考指南提供了一些连接图）。
注：如果您打算在EIA-530中使用带有端口B的MVME162
配置，不安装P2或LCP2适配器板
以及MVME712系列转换模块。它们与EIA-530接口不兼容（参见MVME162
4章，功能描述中的串行端口2）。
9.将适当的电缆连接至EIA-232的面板连接器-
D串行端口、SCSI端口和LAN以太网端口。
–请注意，MVME712系列未提供某些电缆
模块，并且必须由用户制造或购买。（摩托罗拉
建议所有外围连接使用屏蔽电缆，以尽量减少
辐射。）
10.将外围设备连接到电缆。附录A提供详细信息
支持的EIA-232-D信号信息。附录B描述：
以太网LAN（局域网）端口连接。附录C
描述SCSI（小型计算机系统接口）I/O总线连接。
11.在系统中安装任何其他所需的VMEmodules。
12.更换机箱盖。
13.将电源线连接到交流电源，然后转动设备
接通电源。
硬件准备和安装
2-12 MVME162嵌入式控制器用户手册
2.系统考虑
MVME162从VMEbus背板连接器P1和P2汲取电力。
P2也用于32位传输中的高16位数据
扩展寻址模式下的8条地址线。MVME162可能无法工作
主板未正确连接到VMEbus背板连接器
P1和P2。
无论MVME162是作为VMEbus主设备还是作为VMEbus从设备运行，它
被配置用于32位地址和32位数据（A32/D32）。然而
处理3章D8所示地址范围内的A16或A24设备
和/或系统中的D16设备必须由MC68040处理/
MC68LC040软件。请参阅3章中的内存映射。
MVME162包含共享板载DRAM，其基址为
软件可选。车载处理器和非车载VMEbus
设备在基本物理地址$00000000处看到本地DRAM，如
由MVME162Bug固件编程。这可以通过以下方式进行更改：
软件到任何其他基地址。请参阅MVME162嵌入式控制器
更多信息，请参阅程序员参考指南。
如果MVME162试图访问不存在位置的非车载资源，并且
如果系统没有全局总线超时，
MVME162永远等待VMEbus循环完成。这将导致
系统锁定。只有一种情况，系统可能：
缺少此全局总线超时：当MVME162不是系统控制器时
并且在系统的其他地方没有全局总线超时。
多个MVME162可安装在单个VME机箱中。一般来说
支持硬件多处理器功能。
注意：如果要在MVME945中安装多个MVME162
机箱，不要在插槽12中安装MVME162。高度
IP模块可能会在该插槽中造成间隙困难
位置
VMEbus上的其他MPU可以中断、禁用、与通信，以及
确定处理器的运行状态。GCSR的一个寄存器
（全局控制/状态寄存器）集合包括四位，用作位置
监视器允许一个MVME162处理器向任何其他处理器广播信号
MVME162处理器。所有八个寄存器都可以从任何本地访问
处理器以及来自VMEbus。
