Connecting the PD pin low disables the amplifier and places the output in a high-impedance state. When the
amplifier is configured as a noninverting amplifier, the feedback (RF) and gain (RG) resistor network form a
parallel load to the output of the amplifier. To protect the input stage of the amplifier, the OPA858 uses internal,
back-to-back protection diodes between the inverting and noninverting input pins as Figure 48 shows. When the
differential voltage between the input pins of the amplifier exceeds a diode voltage drop, an additional lowimpedance path is created between the inputs.
+
±
GND
+
±
RF
CF
OPA858
5 V
GND
3.4 V
100 V
20
OPA858
SBOS629A –APRIL 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: OPA858
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
10 Application and Implementation
NOTE
Information in the following applications sections is not part of the TI component
specification, and TI does not warrant its accuracy or completeness. TI’s customers are
responsible for determining suitability of components for their purposes. Customers should
validate and test their design implementation to confirm system functionality.
10.1 Application Information
10.1.1 Using the OPA858 as a Transimpedance Amplifier
The OPA858 design has been optimized to meet the industry's growing demand for wideband, low-noise
photodiode amplifiers. The closed-loop bandwidth of a transimpedance amplifier is a function of the following:
1. The total input capacitance. This includes the photodiode capacitance, input capacitance of the amplifier
(common-mode and differential capacitance) and any stray capacitance from the PCB.
2. The op amp gain bandwidth product (GBWP), and,
3. The transimpedance gain RF.
Figure 56. Transimpedance Amplifier Circuit
Figure 56 shows the OPA858 configured as a TIA with the avalanche photodiode (APD) reverse biased such that
its cathode is tied to a large positive bias voltage. In this configuration the APD sources current into the op amp
feedback loop so that the output swings in a negative direction relative to the input common-mode voltage. To
maximize the output swing in the negative direction, the OPA858 common-mode is set close to the positive limit,
1.6 V from the positive supply rail.
The feedback resistance RF and the input capacitance form a zero in the noise gain that results in instability if left
unchecked. To counteract the effect of the zero, a pole is inserted by adding the feedback capacitor (CF.) into the
noise gain transfer function. The Transimpedance Considerations for High-Speed Amplifiers application report
discusses theories and equations that show how to compensate a transimpedance amplifier for a particular gain
and input capacitance. The bandwidth and compensation equations from the application report are available in a
Microsoft Excel ™ calculator. What You Need To Know About Transimpedance Amplifiers – Part 1 provides a
link to the calculator.
