（PCB）parasitThe equations and calculators in the application report and blog posts referenced above are used to model the
bandwidth (f-3dB) and noise (IRN) performance of the OPA858 configured as a TIA. The resultant performance is
shown in Figure 57 and Figure 58. The left side Y-axis shows the closed-loop bandwidth performance, while the
right side of the graph shows the integrated input referred noise. The noise bandwidth to calculate IRN, for a fixed
RF and CPD is set equal to the f–3dB frequency.
Figure 57 shows the amplifier performance as a function of photodiode capacitance (CPD) for RF = 10 kΩ and 20
kΩ. Increasing CPD decreases the closed-loop bandwidth. It is vital to reduce any stray parasitic capacitance from
the PCB to maximize bandwidth. The OPA858 is designed with 0.8 pF of total input capacitance to minimize the
effect on system performance.
Figure 58 shows the amplifier performance as a function of RF for CPD = 1 pF and 2 pF. Increasing RF results in
lower bandwidth. To maximize the signal-to-noise ratio (SNR) in an optical front-end system, maximize the gain
in the TIA stage. Increasing RF by a factor of "X" increases the signal level by "X", but only increases the resistor
noise contribution by "√X", thereby improving SNR.
 
1 453 Noise Gain = = 1 2.79 V/V 5.04 dB
SBOS629A –APRIL 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: OPA858
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
10.2 Typical Application
The high GBWP, low input voltage noise and high slew rate of the OPA858 makes the device a viable wideband,
high input impedance voltage amplifier.
Figure 59. OPA858 in a Gain of –2V/V (No Noise Gain Shaping)
Figure 60. OPA858 in a Gain of –2V/V (With Noise Gain Shaping)
10.2.1 Design Requirements
Design a high-bandwidth, high-gain, voltage amplifier with the design requirements listed in Table 1. An inverting
amplifier configuration is chosen here; however, the theory is applicable to a noninverting configuration as well.
In an inverting configuration the signal gain and noise gain transfer functions are not equal, unlike the
noninverting configuration.
Table 1. Design Requirements
TARGET BANDWIDTH
(MHz) SIGNAL GAIN (V/V) FEEDBACK RESISTANCE
(Ω)
FREQUENCY
PEAKING (dB)
> 750 –2 453 < 2
10.2.2 Detailed Design Procedure
The OPA858 is compensated to have less than 1 dB of peaking in a gain of 7 V/V. Using the device in lower
gains results in increased peaking and potential instability. Figure 59 shows the OPA858 configured in a signal
gain of –2 V/V. The DC noise gain (1/β) of the amplifier is affected by the 62-Ω termination resistor and the 50-Ω
source resistor and is given by Equation 1. At higher frequencies the noise gain is affected by reactive elements
such as inductors and capacitors. These include both discrete board components as well as printed circuit board
(PCB) parasit
