SPECIFIC
WARNINGS
(continued)
Page 124: The CI862 baseplate has no locking device. Insert only the
CI862 unit into this baseplate. Insertion of other unit types may cause
damage to the equipment.
Page 191: Before attempting maintenance or troubleshooting, read the
Safety Summary on page 13. Failure to do so could lead to personal
injury or damage to equipment.
Page 198: It is not allowed to manipulate CEX bus baseplates in a powered and running system. Before changing or removing a baseplate, all
CEX modules on that segment must be removed.
Page 429: Explosion hazard - Substitution of components may impair
suitability for Class I, Zone 2.
Page 429: Explosion hazard - Do not replace batteries unless the power
has been switched off or the area is known to be non-hazardous.
Page 430: Explosion hazard - Do not disconnect equipment unless the
power has been switched off or the area is known to be non-hazardous.
SPECIFIC
 CAUTIONS
Page 68: To prevent damage to the pins, be sure the baseplate plugs and
sockets are fully aligned as the units interconnect. Under no circumstances use excessive force!
Page 68: It is essential that the locking device be placed in the LOCKED
position to avoid possible problems caused by vibration and/or intermittent
grounding.
Page 73: In order to provide adequate access and removal space, note
that the SLIDE sequence must be carried out on the unit baseplates adjacent to the unit that is to be removed.
Page 73: The unit baseplates are easily disconnected from each other by
gently prying them apart with a blade screwdriver (see Figure 23 on page
74).
20 3BSE036351-510 A
Safety Summary
SPECIFIC
 CAUTIONS
(continued)
Page 76: Do not manipulate the locking device. ABB will take no responsibility for errors caused by manipulating locking devices.
-79 and Page 92: Do not place the internal back-up battery in the battery
holder until the AC 800M Controller has been powered-up normally and
the memory back-up function has been activated, that is, the B(attery)
LED flashes. If no normal power supply is connected to the processor unit
with the battery in place, then the CPU memory will immediately start to
consume battery power.
Page 90: Note that in redundant CPU configuration, COM3 and the electrical ModuleBus on the baseplate can not be used.
Page 91: Note that the RCU Link Cable TK851 must be used and can not
be replaced by a similar cable. Using another cable will disable the identification of the CPUs in the CB and Operator Station. When running in single configuration the RCU Link Cable TK851 might temporarily be used to
perform the function of a termination plug.
Page 98: Do not connect the two CEX-Bus segments, separated with
BC810, to each other with CEX-Bus extension cable TK850.
Page 98: In AC 800M High Integrity Controllers it is required that the external supply input of BC810 is connected and that the power supply is
strictly configured either according to Figure 33 or according to Figure 34
and nor is it allowed to change the configuration by way of for instance
individual circuit breakers between modules.
Page 99: Hot swap of the BC810 located next to a primary or single controller CPU, otherwise called “direct BC810”, might jeopardize the whole
controller and should not be performed unless every module on the
CEX-Bus are in a non-operating state. Note: In an AC 800M HI controller
this is unconditionally and intentionally leading to a shutdown of the controller.
Page 112: It is not possible to change the CI851 unit via hot swap and it is
not allowed to perform an online upgrade of firmware in a system containing CI851
