SM810直接安装在处理器单元基板上的CEX总线上，或
至CEX总线互连单元BC810。通信接口为
然后安装到SM810上的CEX总线。参见100页的图31
配置示例参见101页的图32。
数字I/O连接
SM810有一个带有两个数字输入和三个数字输出的连接器，可以：
用于与高完整性相关的数字I/O（非过程I/O）。见表10。
输入信号用于系统功能，参见AC 800M高完整性
文档
在冗余配置中
SM810必须连接到公共数字输入开关。
例如，两个SM810的I2必须连接到公共开关。如果
使用单独的源时，将源连接到公共交换机，然后
从交换机导出到两个SM810的连接。
表10.SM810数字输入/输出连接器
引脚名称描述
1通公共I/O电源
2 I1数字输入1（重置所有力）
3 I2数字输入2（访问启用）
4 I3数字输入3
5 O1数字输出1（任何力激活）
6氧气数字输出2（系统报警）
7 ZP通用输入/输出回路
2节安装安装SM810/TP855
3BSE036351-510 A 105
输入信号与SM810的连接
图35输入信号与冗余SM810的连接。
0V B 0V A
24V A
24V B
I1：重置所有力
I2：访问启用
安装SM810/TP8552节安装
106 3BSE036351-510 A
输出信号与SM810的连接
图36冗余SM810输出信号的连接。
24V B 24V A
O1：任何有效力
O2：系统报警
0V
2节安装安装SM811/TP868
3BSE036351-510 A 107
安装SM811/TP868
SM811直接安装在处理器单元基板上的CEX总线上，或
至CEX总线互连单元BC810。通信接口为
然后安装到SM811上的CEX总线。参见100页的图31
配置示例参见101页的图32。使用封闭电缆
TK852V010在冗余情况下连接两个SM811的SM链路
配置
数字I/O连接
SM811有一个带有三个数字输入和两个数字输出的连接器，可以：
用于与高完整性相关的数字I/O（非过程I/O）。见表11。
访问启用输入（I2）必须连接到操作员的钥匙开关
面板复位所有力输入（I1）和热插入输入（I3）必须连接到
脉冲式面板（如果使用）。
输入信号用于系统功能，参见AC 800M高完整性
文档
在冗余配置中
SM811必须连接到公共数字输入开关。
例如，两个SM811的I3必须连接到公共开关。如果
使用单独的源时，将源连接到公共交换机，然后
从交换机到两个SM811的连接。

ECS086329-004 086329-004 驱动控制电路主板

ECS086329-004 086329-004 驱动控制电路主板

The SM810 is mounted directly to the CEX-Bus on the processor unit base plate or
to the CEX-Bus interconnection unit BC810. The communication interfaces are
then mounted to the CEX-Bus on the SM810. See Figure 31 on page 100 and
Figure 32 on page 101 for configuration examples.
Digital I/O Connection
The SM810 has a connector with two digital inputs and three digital outputs that can
be used for High Integrity related digital I/O (not process I/O). See Table 10.
The input signals are used for system function, see AC 800M High Integrity
documentation.
In a redundant configuration, the corresponding digital inputs to both the
SM810’s must be connected to common digital input switches.
For example, the I2’s of both SM810’s must be connected to a common switch. If
separate sources are used, connect the sources to a common switch, and then
derive connections from the switch to both the SM810’s.
Table 10. SM810 Digital I/O Connector
PIN Designation Description
1 UP Common I/O power
2 I1 Digital input 1 (Reset all forces)
3 I2 Digital input 2 (Access enable)
4 I3 Digital input 3
5 O1 Digital output 1 (Any force active)
6 O2 Digital output 2 (System alarm)
7 ZP Common I/O return
Section 2 Installation Installing SM810/TP855
3BSE036351-510 A 105
Connection of Input Signals to SM810
Figure 35. Connection of input signals to redundant SM810.
0V B 0V A
24V A
24V B
I1: Reset all forces
I2: Access enable
Installing SM810/TP855 Section 2 Installation
106 3BSE036351-510 A
Connection of Output Signals to SM810
Figure 36. Connection of output signals from redundant SM810.
24V B 24V A
O1: Any force active
O2: System alarm
0V
Section 2 Installation Installing SM811/TP868
3BSE036351-510 A 107
Installing SM811/TP868
The SM811 is mounted directly to the CEX-Bus on the processor unit base plate or
to the CEX-Bus interconnection unit BC810. The communication interfaces are
then mounted to the CEX-Bus on the SM811. See Figure 31 on page 100 and
Figure 32 on page 101 for configuration examples. Use the enclosed cable
TK852V010 to connect the SM Link of the two SM811s in case of redundant
configuration.
Digital I/O Connection
The SM811 has a connector with three digital inputs and two digital outputs that can
be used for High Integrity related digital I/O (not process I/O). See Table 11.
The Access Enable input (I2) must be connected to a key switch in the operator’s
panel. The Reset all Forces input (I1) and Hot-insert input (I3) must be connected to
impulse type panel if they are used.
The input signals are used for system function, see AC 800M High Integrity
documentation.
In a redundant configuration, the corresponding digital inputs to both the
SM811’s must be connected to common digital input switches.
For example, the I3’s of both SM811’s must be connected to a common switch. If
separate sources are used, connect the sources to a common switch, and then
derive connections from the switch to both the SM811’s.
