1. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail
on page 65 and Installing the PM86x/TP830 Processor Unit in Single
Configuration on page 78.
2. Connect the Ethernet twisted pair cable to the COM1 connector on the
baseplate (COM2 is not used for connection to INSUM).
3. Connect the other end of the Ethernet cable to the INSUM equipment via
Ethernet/LON Gateway.
Ethernet Twisted Pair Connection
The Ethernet twisted pair is connected via the 10BaseT RJ45 connector located on
TP853. For a description of the connector see Table 5 on page 84.
Note that there is no unit redundancy for the CI857 unit.
Installing the DriveBus Interface, CI858/TP858 Section 2 Installation
122 3BSE036351-510 A
Installing the DriveBus Interface, CI858/TP858
The CI858 is powered from the processor unit via the CEX bus and requires
therefore no additional external power source. The unit is mounted onto a horizontal
DIN rail.
Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on
page 65, Installing the PM86x/TP830 Processor Unit in Single Configuration on
page 78 and CI858 and TP858 – DriveBus Interface on page 313.
Optical Connectors
The CI858 board connects to the drive system via three optical receiver/transmitter
pairs. HP/Agilent Technologies Versatile Link Series (HFBR family) optical
transmitter/receivers are used. Transmission speed of the optical fibres is 4 Mbit/s.
Table 16. Optical Connectors
Connector Designation Description
DriveBus TxD Transmit data
DriveBus RxD Receive data
I/O Bus TxD Transmit data
I/O Bus RxD Receive data
PC Tools TxD Transmit data
PC Tools RxD Receive data
Note that there is no unit redundancy for the CI858 unit.
Section 2 Installation Installing the FOUNDATION Fieldbus High Speed Ethernet Interface,
3BSE036351-510 A 123
Installing the FOUNDATION Fieldbus High Speed Ethernet
Interface, CI860/TP860
The CI860 is powered from the processor unit via the CEX-Bus and requires
therefore no additional external power source.
Use the following procedure to install the CI860/TP860:
1. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail
on page 65 and Installing the PM86x/TP830 Processor Unit in Single
Configuration on page 78.
2. Connect the Ethernet twisted pair cable to the COM connector on the
baseplate.
3. Connect the other end of the Ethernet cable to Ethernet network via standard
Ethernet components.
4. Please make sure to meet the FOUNDATION Fieldbus High Speed Ethernet
specification of the network and the network devices.
Ethernet Twisted Pair Connection
The Ethernet twisted pair is connected via the RJ45 connector located on TP860.
For a description of the connector see Table 5 on page 84.
