在冗余配置中，安装了两个PM861/PM864/PM865/PM866单元
安装在两个单独的DIN导轨上。如果有足够的空间，单元可以
安装在同一DIN导轨上
使用以下步骤沿DIN导轨安装处理器单元：
1.安装处理器单元。
2.将通信接口安装在CEX总线左侧
处理器单元。如果使用BC810，则段的配置应为
考虑过的。如果未使用BC810，则接口可在
以任何优选方式提供两个CPU。
3.轻轻地将单元压在一起，确保CEX总线正确
通过基板上的连接器连接。
4.如果使用BC810，将TK851电缆连接到两个BC810（图31
100页）。如果未使用BC810，则安装CEX总线延长电缆TK850
到离处理器单元远的单元，或者，如果没有单元
直接安装到处理器单元上的CEX总线。CEX巴士
无论是否有任何CPU，扩展电缆必须连接到两个CPU
其他CEX总线单元（93页图29）。
本主题不适用于冗余PM891装置的安装
配置请参阅以冗余方式安装PM891处理器单元
配置见94页。
注意，在冗余CPU配置中，COM3和电气模块总线
底板上不能使用。
2节安装：在冗余配置中安装PM86x/TP830处理器单元
3BSE036351-510 A 91
5.将RCU链路电缆TK851连接到两个CPU。请注意，在冗余
CPU配置、COM3和底板can上的电气模块总线
不使用。
6.底板电缆连接：
a、 将电源引线连接到CPU和电源监控信号
从SS8xx到螺钉端子SA和SB（参见83页图28）。
b、 将控制网络电缆连接至CN1（单总线连接），或
CN1+CN2（冗余总线连接）。控制网络是
连接到两个CPU。
c、 使用主电源的电缆TK212将控制生成器连接到COM4
CPU（如果需要更改IP地址等）。否则，连接
控制网络的控制生成器。
7.将光学模块总线连接到处理器单元上的光学触点
（参见32页图2和131页图40）。关于
S800 I/O中提供了光缆选择和电缆长度
文档
请注意，必须使用RCU链路电缆TK851，不能用
类似于电缆。使用其他电缆将禁用中CPU的标识
CB和操作员站。在单一配置下运行时，RCU
链路电缆TK851可临时用于执行
终端插头。
连接到标有“上部”的RCU链路电缆连接器的CPU将
在控制生成器和操作员站中定义为“上位”。标记
与CPU的物理位置无关。任何CPU都可以成为
主CPU。
两个CPU应由同一电源供电（单个或冗余）。对于
冗余电源，参见140页图46。
光学模块总线的连接与处理器单元的连接相同
对于S800 I/O中的FCI（161页图55）。

064829-003 2-064828-002 操作界面电路板

064829-003 2-064828-002 操作界面电路板

In redundant configuration two PM861/PM864/PM865/PM866 units are mounted
onto two separate DIN-rails. If sufficient space is available, the units can be
mounted onto the same DIN-rail
Use the following procedure to install the processor units along the DIN-rail:
1. Mount the processor units.
2. Mount the communication interfaces on the CEX-Bus to the left of the
processor unit. If BC810s are used, the configuration of the segments should be
considered. If no BC810s are used, the interfaces can be divided between the
two CPUs in any preferred way.
3. Press the units gently together and make sure that the CEX-Bus is correctly
connected, via the connectors on the baseplates.
4. If BC810s are used, connect the TK851 cable to the two BC810s (Figure 31 on
page 100). If no BC810s are used, mount the CEX-Bus extension cable TK850
to the units at farthest away from the processor units or, if no units are
mounted, directly to the CEX-Bus on the processor unit. The CEX-Bus
extension cable must be connected to both CPUs whether or not there are any
other CEX-Bus units (Figure 29 on page 93).
This topic does not apply to the installation of PM891 unit in redundant
configuration. See Installing the PM891 Processor Unit in Redundant
Configuration on page 94.
Note that in redundant CPU configuration, COM3 and the electrical ModuleBus
on the baseplate can not be used.
Section 2 Installation Installing the PM86x/TP830 Processor Unit in Redundant Configuration
3BSE036351-510 A 91
5. Connect the RCU Link Cable TK851 to both CPUs. Note that in redundant
CPU configuration, COM3 and the electrical ModuleBus on the baseplate can
not be used.
6. Baseplates cable connections:
a. Connect the power leads to both CPUs and the power supervision signals
from SS8xx to screw terminals SA and SB (see Figure 28 on page 83).
b. Connect the Control Network cables to CN1 (single bus connection) or
CN1 + CN2 (redundant bus connection). The Control Network is
connected to both CPUs.
c. Connect the Control Builder to COM4 with cable TK212 of the Primary
CPU (if required for changing an IP address etc.). Otherwise connect the
Control Builder to the Control Network.
7. Connect the optical ModuleBus to the optical contacts on the processor units
(see Figure 2 on page 32 and Figure 40 on page 131). Information regarding
optical cable selection and cable length is provided in the S800 I/O
documentation.
Note that the RCU Link Cable TK851 must be used and can not be replaced by a
similar cable. Using another cable will disable the identification of the CPUs in
the CB and Operator Station. When running in single configuration the RCU
Link Cable TK851 might temporarily be used to perform the function of a
termination plug.
The CPU connected to the RCU Link Cable connector marked “UPPER” will be
defined as “UPPER” in the Control Builder and Operator Station. The marking
has no relevance to the physical placement of the CPUs. Any CPU can become
the Primary CPU.
Both CPUs should be powered from the same supply (single or redundant). For
redundant power supply, see Figure 46 on page 140.
Connection to the optical ModuleBus is identical to that for the processor unit
and for the FCI in S800 I/O (Figure 55 on page 161).
