将通信接口安装在CEX总线的左侧
处理器单元。如果使用BC810，则段的配置应为
考虑过的。如果未使用BC810，则接口可在
以任何优选方式提供两个CPU。
3.轻轻地将单元压在一起，确保CEX总线正确
通过单元上的连接器连接。
4.如果使用BC810，将TK851电缆连接到两个BC810。如果没有BC810s
使用时，将CEX总线延长电缆TK850安装到远的单元
远离处理器单元，或者如果没有安装单元，则直接连接到处理器单元上的CEXBus。CEX总线延长电缆必须连接到：
两个CPU，无论是否有任何其他CEX总线单元（图29
93页）。
5.连接RCU数据链路电缆（TK855）和RCU控制链路电缆
（TK856）连接到两个CPU。
RCU数据链路电缆（TK855）和RCU控制链路电缆（DK856）
不得用类似电缆代替。使用其他电缆将禁用
控制构建器和操作员站中CPU的标识。
CPU连接到RCU控制链路电缆（TK856）连接器，标记为
“上限”将在控件生成器和运算符中定义为“上限”
火车站标记与CPU的物理位置无关。
任何CPU都可以成为主CPU。
2节安装：在冗余配置中安装PM891处理器单元
3BSE036351-510 A 95
6.提供电源和网络连接：
a、 将电源线连接到两个CPU的螺钉端子L+和L-，以及
来自SS8xx的电源监控信号发送到螺钉端子SA和SB。
b、 将控制网络电缆连接至CN1（单总线连接），或
CN1+CN2（冗余总线连接）。控制网络是
连接到两个CPU。
c、 使用主电源的电缆TK212将控制生成器连接到COM4
CPU（如果需要更改IP地址等）。否则，连接
控制网络的控制生成器。
7.将光学模块总线连接到处理器单元上的光学触点
（参见32页图2和131页图40）。关于
S800 I/O中提供了光缆选择和电缆长度
文档
8.通过将CPU连接到外部SB822电池提供电池备用
单位。按照安装SB822中的说明进行安装
144页的可充电外部电池单元。
两个CPU应由同一电源供电（单个或冗余）。对于
冗余电源，参见140页图46。
光学模块总线的连接与处理器单元的连接相同
对于S800 I/O中的FCI（161页图55）。
