CI855由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
底板TP853提供两个以太网端口，用于连接冗余
主总线300的以太网网络。
使用以下步骤安装CI855/TP853：
1.将装置安装在DIN导轨上，参见将AC 800M装置安装到DIN导轨上
在第65页，将PM86x/TP830处理器单元安装在单个
配置见第78页。
2.将以太网双绞线连接至底板上的触点。
3.将以太网电缆的另一端连接到以太网交换机。
以太网双绞线连接
以太网双绞线通过位于的10BaseT RJ45连接器连接
TP853.有关连接器的说明，请参见第84页的表5。
如果需要AUI接口，则需要10BaseT到AUI的转换器。
通信单元CI855不能向收发器供电，因此
必须使用单独的电源。
请注意，CI855单元没有单元冗余。
安装S100 I/O接口，CI856/TP856第2节安装
120 3BSE036351-510 A
安装S100 I/O接口，CI856/TP856
CI856由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
使用以下步骤安装CI856/TP856：
1.将装置安装在DIN导轨上，参见将AC 800M装置安装到DIN导轨上
在第65页，将PM86x/TP830处理器单元安装在单个
配置见第78页。
2.将S100输入/输出电缆TK575/TK580连接至基板上的触点。A.
必须使用总线扩展器DSBC174/DSBC176/DSBC173A。
S100 I/O连接和安装
将S100 I/O机架电缆TK575/TK580连接至“I/O标签”36引脚
中心线微型带状连接器位于TP856上。
S100 I/O的安装
有关S100 I/O相关组件的安装，请参阅S100 I/O文档。
请注意，CI856单元没有单元冗余。
第2节安装安装INSUM接口，CI857/TP853
3BSE036351-510 A 121
安装INSUM接口，CI857/TP853
CI857由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
使用以下步骤安装CI857/TP853：
1.将装置安装到DIN导轨上，请参阅将AC 800M装置安装在DIN导轨上
在第65页，将PM86x/TP830处理器单元安装在单个
配置见第78页。
2.将以太网双绞线连接到
底板（COM2不用于连接INSUM）。
3.通过以下方式将以太网电缆的另一端连接到INSUM设备
以太网/LON网关。
以太网双绞线连接
以太网双绞线通过位于的10BaseT RJ45连接器连接
TP853.有关连接器的说明，请参见第84页的表5。
请注意，CI857单元没有单元冗余。
