CI858由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。该装置安装在水平面上
铁路上的嘈杂声。
将装置安装到DIN导轨上，请参阅将AC 800M装置安装在DIN导轨上
第65页，在单个配置中安装PM86x/TP830处理器单元
第78页和第313页的CI858和TP858–驱动总线接口。
光纤接口
CI858板通过三个光接收器/发射器连接到驱动系统
对。HP/Agilent Technologies通用链路系列（HFBR系列）光纤
使用发射器/接收器。光纤的传输速度为4Mbit/s。
表16.光连接器
连接器名称和说明
驱动总线TxD传输数据
驱动总线RxD接收数据
I/O总线TxD传输数据
I/O总线RxD接收数据
PC工具TxD传输数据
PC工具RxD接收数据
请注意，CI858单元没有单元冗余。
第2节安装安装基金会现场总线高速以太网接口，
3BSE036351-510 A 123
安装基金会现场总线高速以太网
接口，CI860/TP860
CI860由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
使用以下步骤安装CI860/TP860：
1.将装置安装到DIN导轨上，请参阅将AC 800M装置安装在DIN导轨上
在第65页，将PM86x/TP830处理器单元安装在单个
配置见第78页。
2.将以太网双绞线连接到
底板。
3.通过标准将以太网电缆的另一端连接到以太网
以太网组件。
4.请确保满足基金会现场总线高速以太网
网络和网络设备的规范。
以太网双绞线连接
以太网双绞线通过位于TP860上的RJ45连接器连接。
有关连接器的说明，请参见第84页的表5。
安装TRIO现场总线接口CI862第2节安装
124 3BSE036351-510 A
安装TRIO现场总线接口CI862
CI862由处理器单元通过CEX总线供电，无需
额外的外部电源。没有现场设备由CI862供电。
使用以下步骤安装CI862：
1.将装置安装到DIN导轨上。
2.将现场总线电缆连接至LAN连接器（右侧连接器）。看见
CI862 TRIO现场总线指南、电缆类型和安装手册
长
手持式显示器（如使用）连接至HHM连接器。
装置至基板阿尔法密码锁
由于
装置内电子设备的位置。电子设备不允许CI862
装置安装在任何带有锁定装置的底板上。然而，其他单位
可插入CI862基板。
总线终端
适当的端接电阻器必须连接到起点和终点
公共汽车的。表142中列出了每种类型电缆的特性阻抗。
如果CI862位于总线两端，则特性电阻由开关设置
在现场总线接口模块上，表17。如果一个TRIO模块在开始
或总线的末端，总线可通过电阻器或终端
电阻插头，6202FP00150用于150 W或6202FP00075用于75 W。BSM短截线
不应终止。
CI862基板没有锁定装置。仅将CI862装置插入此
底板。插入其他装置类型可能会损坏设备。

HITE303527R1 IDB772AR1 模拟量输入输出终端

HITE303527R1 IDB772AR1 模拟量输入输出终端

The CI858 is powered from the processor unit via the CEX bus and requires
therefore no additional external power source. The unit is mounted onto a horizontal
DIN rail.
Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail on
page 65, Installing the PM86x/TP830 Processor Unit in Single Configuration on
page 78 and CI858 and TP858 – DriveBus Interface on page 313.
Optical Connectors
The CI858 board connects to the drive system via three optical receiver/transmitter
pairs. HP/Agilent Technologies Versatile Link Series (HFBR family) optical
transmitter/receivers are used. Transmission speed of the optical fibres is 4 Mbit/s.
Table 16. Optical Connectors
Connector Designation Description
DriveBus TxD Transmit data
DriveBus RxD Receive data
I/O Bus TxD Transmit data
I/O Bus RxD Receive data
PC Tools TxD Transmit data
PC Tools RxD Receive data
Note that there is no unit redundancy for the CI858 unit.
Section 2 Installation Installing the FOUNDATION Fieldbus High Speed Ethernet Interface,
3BSE036351-510 A 123
Installing the FOUNDATION Fieldbus High Speed Ethernet
Interface, CI860/TP860
The CI860 is powered from the processor unit via the CEX-Bus and requires
therefore no additional external power source.
Use the following procedure to install the CI860/TP860:
1. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail
on page 65 and Installing the PM86x/TP830 Processor Unit in Single
Configuration on page 78.
2. Connect the Ethernet twisted pair cable to the COM connector on the
baseplate.
3. Connect the other end of the Ethernet cable to Ethernet network via standard
Ethernet components.
4. Please make sure to meet the FOUNDATION Fieldbus High Speed Ethernet
specification of the network and the network devices.
Ethernet Twisted Pair Connection
The Ethernet twisted pair is connected via the RJ45 connector located on TP860.
For a description of the connector see Table 5 on page 84.
Installing the TRIO Fieldbus Interface CI862 Section 2 Installation
124 3BSE036351-510 A
Installing the TRIO Fieldbus Interface CI862
The CI862 is powered from the processor unit via the CEX-Bus and requires no
additional external power source. No field device is powered from the CI862.
Use the following procedure to install the CI862:
1. Mount the unit onto the DIN-rail.
2. Connect the field bus cable to the LAN connector (right most connector). See
the CI862 Installation book for TRIO field bus guidelines, cable types and
length.
The Hand-Held Monitor, if used, is connected to the HHM connector.
Unit to Baseplate Alpha Code Lock
The CI862 unit and baseplate have the locking device removed because of the
placement of the electronics inside the unit. The electronics will not allow the CI862
unit to be installed in any baseplate with a locking device. However, other units
could be inserted into the CI862 baseplate.
Bus Termination
The appropriate terminating resistor must be attached to both the beginning and end
of the bus. The characteristic impedance for each type of cable is listed in Table 142.
If the CI862 is at either end of the bus, the characteristic resistance is set by a switch
on the Field Bus Interface Module, Table 17. If a TRIO module is at the beginning
or end of the bus, the bus can be terminated with a resistor or a terminating
resistance plug, 6202FP00150 for 150 W or 6202FP00075 for 75 W. BSM stubs
should not be terminated.
The CI862 baseplate has no locking device. Insert only the CI862 unit into this
baseplate. Insertion of other unit types may cause damage to the equipment.
