AC 800M控制器可由外部+24V直流电源供电。这
对于许多不同类型的工厂设备，源通常是常见的，导致
连接AC 800M控制器的长电源电缆。此外，重载变化可以
导致控制器电源电压变化，因此需要采取预防措施
以防止控制器故障。
如果PM8XX电源端子处存在+24 V电压下降的风险
低于19.2 V持续1 ms以上，则必须使用储能器
动力装置。
ABB要求在以下情况下使用DC/DC转换器和额外的储能器：
使用电缆长度超过10m的外部直流电源。
对于AC 800M控制器和相关单元的冗余电源，
始终从SS8xx投票设备导出连接。参见第页的图61
177
第3节配置：从外部电源供电
3BSE036351-510 A 177
图61.AC 800M装置的电源选项
单位
供应
设备8xx
补给
权力
干线
24伏直流电
分配
SD投票
冗余电源
冗余电源
终端
24伏直流电
分配
终端
24伏直流电
分配
终端
8xx
供给
权力
SD
8xx
SD
8xx
SD
8xx
党卫军
装置
投票
8xx
党卫军
8xx电源SD
干线1
干线2
单位
供应
单位
供应
电源断路器
电源断路器
电源断路器
电源断路器
单电源
权力
补给
从外部电源供电第3节配置
178 3BSE036351-510 A
图62.为现场设备供电
领域
设备
8xx
SD
8xx
SD
单位
供应
供应
24伏直流电
分配
24伏直流电
分配
独立的
8xx
SD电源
电源断路器
电源断路器
供应
单位
24伏直流电
分配
24伏直流电
分配
独立的
电源
独立电源
断路器单元
电源断路器
干线
终端
终端
终端
终端
电源
领域
设备
供应
8xx
SD
为现场设备供电
3BSE036351-510 A 179
第4节操作
本节描述了AC 800M控制器的操作，包括
PM8xx（单或冗余配置）处理器单元，以及各种
可选单元。有关可选装置的更多技术信息，请参见附录
A、 硬件单元。
AC 800M控制器（PM8xx）
配备控制软件的基本PM8xx/TP830或PM891硬件单元
安装在AC 800M硬件平台上，构成AC 800M控制器。
LED指示灯
有关放置的说明，请参见第32页的图2。
表20.PM8xx–LED指示灯
标记颜色函数
F（故障）红色正常状态-关闭
重新启动（初始化）临时点亮F（故障）。
也可以由软件程序操作。
R（un）绿色正常状态-开启
重新启动（初始化）暂时熄灭
R（联合国）。重启时，按下（初始化）按钮
直到R（un）闪烁。
也可以由软件程序操作。
AC 800M控制器（PM8xx）第4节操作
180 3BSE036351-510 A
P（电源）绿色正常状态–开启
点亮时，表示CPU DC/DC
转换器正在生成有效的+5 V和+3.3 V
直流电源电压。
没有软件控制。
B（蓄电池）绿色正常状态–开启
当内部或外部蓄电池电压为
高于3.1 V。LED由
软件电池电压测试（1）。
Tx黄色
绿色（2）
数据传输（4），
CN1+CN2和COM3（3）+COM4
与Tx流量同步闪烁
Rx黄色
绿色（2）
数据接收（4），
CN1+CN2和COM3（3）+COM4
与接收流量同步闪烁
适用于PM861/PM864/PM865/PM866/PM891
单一和冗余配置中的主（ary）黄灯亮起。
表示主CPU处于冗余状态
配置由软件控制。
当CPU以冗余方式运行时，双黄灯亮起
配置和同步状态。
（1） 软件通过专用LED控制输入执行循环电池电压电平测试。这个
电池为应用程序内存和实时时钟提供备用电源
断电。电池可通过PM8xx盖板或外部连接
连接到外部电池连接器。通过软件检查蓄电池电压。电压是公共的
用于内部和外部电池。因此，应拆下内部电池
使用外部电池时，由于两个电池并联会导致
大大降低了容量。
（2） 仅适用于PM891
（3） 对PM891无效
（4） PM851/PM851A仅为CN1。不要连接到CN2。

88TV01H-E GJR2346500R1041 88TV01E 数字量输出模块

88TV01H-E GJR2346500R1041 88TV01E 数字量输出模块

The AC 800M Controller can be powered from an external +24 V DC source. This
source is often common for many different types of plant equipment, resulting in
long power cables to the AC 800M Controller. Furthermore, heavy load changes can
cause variations in controller supply voltage making it necessary to take precautions
against low voltage in order to prevent controller malfunction.
Should there be a risk that the +24 V at the PM8XX power terminals could drop
below 19.2 V for more than 1 ms, then an energy reservoir must be used for
Powering Units.
ABB requires the use of DC/DC converter and extra energy reservoir in case
external DC-supply with longer cables than 10 m is used.
For redundant power supplies to the AC 800M controller and associated units,
always derive connections from the SS8xx voting device. See Figure 61 on page
177.
Section 3 Configuration Powering from an External Source
3BSE036351-510 A 177
Figure 61. Power Supply Options for AC 800M Units
Units
Supply to
Device 8xx
Supplies
Power
Mains
24 V DC
Distribution
SD Voting
Redundant Power Supplies
Redundant Mains Power Supplies
Terminals
24 V DC
Distribution
Terminals
24 V DC
Distribution
Terminals
8xx
Supply
Power
SD
8xx
SD
8xx
SD
8xx
SS
Device
Voting
8xx
SS
8xx Mains SD
Mains 1
Mains 2
Units
Supply to
Units
Supply to
Mains Breaker
Mains Breaker
Mains Breaker
Mains Breaker
Single Power Supply
Power
Supplies
Powering from an External Source Section 3 Configuration
178 3BSE036351-510 A
Figure 62. Powering Field Equipment
Field
Equipment
8xx
SD
8xx
SD
Units
Supply to
Supply to
24 V DC
Distribution
24 V DC
Distribution
Independent
8xx
SD Mains
Mains Breaker
Mains Breaker
 Supply to
Units
24 V DC
Distribution
24 V DC
Distribution
Independent
Power Supplies
Independent Mains
Breaker Units
Mains Breaker
Mains
Terminals
Terminals
Terminals
Terminals
Power Supplies
Field
Equipment
Supply to
8xx
SD
Powering Field Equipment
3BSE036351-510 A 179
Section 4 Operation
This section describes the operation of the AC 800M Controller, comprising a
PM8xx (single or redundant configuration) processor unit, together with various
optional units. For additional technical information on optional units, see Appendix
A, Hardware Units.
AC 800M Controller (PM8xx)
Equipped with Control Software, the basic PM8xx/TP830 or PM891 hardware units
mounted on the AC 800M hardware platform constitute an AC 800M Controller.
LED Indicators
See Figure 2 on page 32, for description of placement.
Table 20. PM8xx – LED Indicators
Marking Color Function
F(ault) Red Normal state – OFF
Re-start (INIT) temporarily lit F(ault).
May also be operated by software program.
R(un) Green Normal state – ON
Re-start (INIT) temporarily extinguishes
R(un). At restart press the (INIT) push button
(3 sec. or more) until R(un) flashes.
May also be operated by software program.
AC 800M Controller (PM8xx) Section 4 Operation
180 3BSE036351-510 A
P(ower) Green Normal state – ON
When lit, indicates that the CPU DC/DC
converter is generating valid +5 V and +3.3 V
DC supply voltages.
No software control.
B(attery) Green Normal state – ON
Lit when internal or external battery voltage is
above 3.1 V. The LED is controlled by a
software battery voltage test(1).
Tx Yellow
Green(2)
Data Transmission(4),
CN1 + CN2 and COM3(3) + COM4
Flashes in synchronization with Tx traffic
Rx Yellow
Green(2)
Data Reception(4),
CN1 + CN2 and COM3(3) + COM4
Flashes in synchronization with Rx traffic
Valid for PM861/PM864/PM865/PM866/PM891
PRIM(ary) Yellow Lit in single and redundant configuration.
Indicates Primary CPU in redundant
configuration. Controlled by software.
DUAL Yellow Lit when the CPU is running in redundant
configuration and synchronized state.
(1) The software performs cyclic battery voltage level tests via a dedicated LED control input. The
battery provides back-up power for both the application memory and the real time clock during
power down. The battery is either accessible via the PM8xx cover panel or externally connected
to the external battery connector. Battery voltage is checked by the software. Voltage is common
for both the internal and external battery. For this reason the internal battery should be removed
when using the external battery, since having two batteries connected in parallel will result in
greatly reduced capacity.
(2) Only for PM891
(3) Not valid for PM891
(4) Only CN1 for PM851/PM851A. Do not connect to CN2.
