Disconnect the RCU Link Cable and optical ModuleBus cable from the
processor unit to be exchanged.
3. Disconnect the Control Network cables.
4. Rotate the locking device to the SLIDE position (2) on the unit baseplate,
see Figure 17 on page 69.
During synchronization, the new processor unit inherits the IP address from the
running processor unit.
Reuse of CPU modules replaced from redundant configurations within the
same control network, might cause control network problems due to the MAC
and IP address handling. See MAC and IP Address Handling in Redundant
Configuration on page 49. Such reuse should not be fulfilled unless both the
replaced module and the module previously acting together with it in redundant
configuration are known to be restored from the previous mutual address swap.
It is recommended to set up an IP-config session and use the “Restore factory
settings” option subsequently followed by reassignment of the IP address or
assignment of a new IP address.
Before replacing, the new CPU must be loaded with the correct firmware as in the
existing CPU.
Do not, under any circumstances, remove the RCU Link Cable from the
primary CPU now running in a single state. Removing the cable might cause
the CPU to stop.
Section 5 Maintenance Exchange of CPU in Redundant Configuration with BC810
3BSE036351-510 A 201
5. Gently ease the unit/baseplate sideways in order to release the contacts of the
unit.
6. Turn the locking device anti-clockwise to the OPEN position (1) and ease the
unit baseplate outward and upward at the base. Lift the unit to remove it from
the DIN-rail.
7. Mount the new unit (which already has the correct firmware installed). See
Mounting AC 800M Units onto DIN-Rail on page 65. Fit the unit to BC810
CEX-Bus.
8. Reconnect the Power Supply Socket to the new processor unit.
9. Reconnect the optical ModuleBus and the RCU Link Cable.
10. Reconnect the Control Network cables.
11. Press the INIT push button on the replaced processor unit.
12. Observe the startup procedure and make sure that Dual mode is reached, that is,
the Dual LED is lit on both processor units.
The unit baseplates are easily disconnected from each other by gently prying
them apart with a blade screwdriver (see Figure 23 on page 74).
The F(ault) LED of the new processor unit is temporarily lit when the power
supply is connected. This is not an indication of fault.
Pressing the INIT button initiates the restart that is required to keep the new
processor unit in redundant mode.
During synchronization, the new processor unit inherits the IP address from the
running processor unit.
Reuse of CPU modules replaced from redundant configurations within the
same control network, might cause control network problems due to the MAC
and IP address handling. See MAC and IP Address Handling in Redundant
Configuration on page 49. Such reuse should not be fulfilled unless both the
replaced module and the module previously acting together with it in redundant
configuration are known to be restored from the previous mutual address swap.
It is recommended to set up an IP-config session and use the “Restore factory
settings” option subsequently followed by reassignment of the IP address or
assignment of a new IP address.
Exchanging a Defect RCU Link Cables Online Section 5 Maintenance
202 3BSE036351-510 A
Exchanging a Defect RCU Link Cables Online
In Configuration with BC810
If online change proves to be supported, after the caution above has been
considered, and the BC810s are externally supplied with 24V the same steps as in
configuration without BC810 can be followed.
In Configuration without BC810
To exchange a RCU link cable in a redundant CPU configuration, perform the
following steps:
1. Switch OFF the Power for the backup CPU. (Power on the primary CPU must
still be On.)
2. Disconnect the RCU link cable from the backup CPU.
3. Disconnect the RCU link cable from the primary CPU.
4. Attach the new RCU link cable to the primary CPU, note the UPPER
orientation on the cable.
5. Attach the other end of RCU link cable to the backup CPU.
6. Switch ON the Power to the backup CPU.
Do not replace the RCU link cable online in a previous version than 5.0. The
support for online replacement also depends on hardware Product Revision
levels. Please consult Release Notes (3BSE021377*) for detailed information.
Do not leave the primary CPU with the RCU link cable disconnected for a
prolonged time. If a power fail occurs while the cable is disconnected, the
primary CPU cannot perform a startup when the power come back.
The new cable-ends must be connected to the redundant CPUs (exactly) in the
same way as the replaced cable was. Thus, the UPPER mark on the cable-end
must be located to the same CPU as before the exchange.
