represented by the individual architectural views.
The three major viewpoints of architecture described in previous version (e.g.,
Operational, Technical, and System) have been changed to more specific viewpoints
that relate to the collection of architecture-related data which can be organized as
useful information for the manager in decision-making. To support customer
requirement and re-organization needs:
All the models of data—conceptual, logical, or physical—have been placed into
the Data and Information Viewpoint.
The Technical Standards Viewpoint has been updated to the Standards
Viewpoint and can describe business, commercial, and doctrinal standards, in
addition to technical standards.
The Operational Viewpoint now can describe rules and constraints for any
function (business, intelligence, warfighting, etc.) rather that just those derived
from data relationships.
Due to the emphasis within the Department on Capability PfM and feedback
from the Acquisition community, the Capability Viewpoint and Project Viewpoint
have been added.
8
DoDAF Introduction
http://cio-nii.defense.gov/sites/dodaf20/background.html[3/3/2011 3:33:50 PM]
System has changed from DoDAF V1.5. System is not just computer hardware and
computer software. System is now defined in the general sense of an assemblage of
components - machine, human - that perform activities (since they are subtypes of
Performer) and are interacting or interdependent. This could be anything, i.e.,
anything from small pieces of equipment that have interacting or interdependent
elements, to Family of Systems (FoS) and System of Systems (SoS). Note that
Systems are made up of Materiel (e.g., equipment, aircraft, and vessels) and
Personnel Types.
The Department initiatives for Architecture Federation and Tiered Responsibility have
been incorporated into Version 2.0.
Requirements for sharing of data and derived information in a Federated environment
are described.
Specific types of architecture within the Department have been identified and
described (e.g., Department-level [which includes Department, Capability &
Component architectures] and Solution Architectures).
The DoD Enterprise Architecture is described.
Linkages to the Federal Enterprise Architecture are defined and described.
Architecture constructs originally described in the UK Ministry of Defence Architecture
Framework (MODAF), the NATO Architecture Framework (NAF), and the Open Group
Architecture Framework (TOGAF) are adopted for use within DoDAF.
A DoDAF Meta-model (DM2), containing a Conceptual Data Model (CDM), a Logical
Data Model (LDM), and a Physical Exchange Specification (PES) has been created.
Approaches to SOA development are described and discussed.
For the architect, DoDAF V2.0 changes the focus of the Architecture Development
Process are described in “What Does the Architect Need to Do”? The basis of the
Architecture Development Process is now the Data Meta-model Groups, described in
the LDM.
To align with ISO Standards, where appropriate, the terminology has changed from
Views to Viewpoint (e.g., the Operational View is now the Operational Viewpoint).
DoDAF can capture the security markings and is described in the PES. In addition, a
discussion of the security characteristics mapped to the DoDAF Concepts has been
added.
In DoDAF V1.5 and previous versions, Nodes are logical concepts that caused issues in
the exchange and discussion of architectures. In one architecture that was reviewed,
Operational Nodes mapped to System, Organization, Person Type, Facility, Materiel,
and Installation. Within the same architecture, System Node maps to System,
Materiel, Organization, and Location. The overlap Organizational and System nodes
(System, Organization, Material) illustrates the complexity of trying to define Nodes.
The concrete concepts of Node (including Activities, System, Organization, Person
Type, Facility, Location, Materiel, and Installation) were incorporated into the DoDAF
Meta-model. Since Nodes are logical concepts that could be used to represent the
more concrete concepts of activities, systems, organizations, personnel types,
facilities, locations, materiels, and installations or combinations of those things,
DoDAF V2.0 focuses on those concrete concepts. There will not be a mapping of Node
to the DoDAF V2.0 Meta-model Groups, concepts, classes, or associations. For the
architect, there are some changes in architecture development:
When appropriate, DoDAF V1.0 and V1.5 architectures that use the Node
concept will need to update the architecture to express the concrete concepts in
place of the abstract concept that Node represents. When pre-DoDAF V2.0
architecture is compared with DoDAF V2.0 architecture, the concrete concepts
that Node represents must be defined for the newer architecture.
DoDAF V2.0 architectures will need to express the concrete concepts (activities,
systems, organizations, personnel types, facilities, locations, materiels, and
installations, etc.).
9
DoDAF Introduction
http://cio-nii.defense.gov/sites/dodaf20/background.html[3/3/2011 3:33:50 PM]
