确定每个数据实体和属性要捕获的详细程度
通过分析步骤中范围界定期间进行的审查过程
2.这包括执行过程所需的数据和其他数据
在当前流程中实施变更所需的数据（例如
记录架构描述工作的组织）。这些考虑确定：
步骤4中收集的数据类型，与建筑结构和深度有关
所需的细节。
要收集的体系结构数据内容的初始类型由确定的
体系结构描述的范围，并记录为属性、关联和概念
如DM2中所述。从DM2概念、关联和属性到
架构模型建议建筑师可以开发的相关架构视图（使用
相关体系结构技术）在更全面和一致的数据
收集步骤4。此步骤通常与步骤4一起完成，即自下而上
有组织的数据收集和体系结构描述开发方法
重复这两个步骤。随着初始数据内容的范围化，附加数据范围可能是
建议采用更全面的建筑视图内容
演示或决策目的。
这一步骤通常可以通过重用其他人以前收集的数据来简化，但是
与当前工作相关。访问适当的COI数据和其他架构
可通过DAR和DMR发现的信息可提供数据和其他信息
可以在当前工作中提供有用的架构视图。
该部目前正在开展工作，以确保
架构建模中的相同语义内容称为架构建模原语。
架构建模原语（以下简称为原语）将成为标准
映射到DM2概念并应用于
建模技术。使用原语支持架构内容的收集
与PES合作，将有助于形成共识，并
建筑师之间关于建筑视图的沟通。作为基本概念
应用于更多建模技术，将在DoDAF期刊上更新
DoDAF后续版本中提供了详细信息。在业务中创建OV-6c时
过程建模符号（BPMN），可以使用原语符号。国防部已经创建
这个符号在DoDAF期刊上。视图的全部基本体，如
当前的BPMN原语将被架构工具供应商协调采用。
步骤4：收集、组织、关联和存储架构数据。建筑师通常
通过使用设计为使用视图的架构技术收集和组织数据
（例如，作为视图的活动、流程、组织和数据模型）用于表示和
13
DoDAF体系结构开发-6步流程
http://cio-nii.defense.gov/sites/dodaf20/arch_development.html[2011年3月3日下午3:33:54]
决策目的。架构数据应以可识别的方式存储
商业或政府架构工具。记录的术语和定义涉及：
（DM2）的元素。
为架构描述工作指定数据结构涉及创建
分类法来组织收集的数据。这项工作可以通过以下方式大大简化：
利用在DAR中注册的现有已注册工件，包括数据分类法和
数据集。每个COI直接或通过
联合方法。此外，一些组织，如美国联合部队司令部
（JFCOM）开发了模板，为可定制的解决方案提供了基础
常见问题或要求，包括已描述的数据集，以及
在DMR中注册。这种基于模板的方法的示例见DoDAF期刊。
DARS提供了更多具体的信息，以及检索所需数据的指南
通过发现过程。一旦发现注册数据，就可以对数据进行编目
并在集中的分类法中进行组织，便于确定新数据
是必需的。定义新数据，在DARS中注册，并将其纳入分类法
结构创建所需数据的完整定义列表。数据被安排上传
以允许后续分析和重用。发现元数据
（即，标识特定体系结构描述、其数据、视图和
使用）应在DARS中注册，以支持发现和
启用联合。架构师和数据管理人员应使用DoD EA业务参考
作为sta的模型（国防部EA BRM）分类要素

SNAT632PAC 61049428D SNAT632 PAC 脉冲放大器板

SNAT632PAC 61049428D SNAT632 PAC 脉冲放大器板

level of detail to be captured for each of the data entities and attributes is determined
through the analysis of the process undergoing review conducted during the scoping in Step
2. This includes the data identified as needed for execution of the process, and other data
required to effect change in the current process, (e.g., administrative data required by the
organization to document the Architectural Description effort). These considerations establish
the type of data collected in Step 4, which relate to the architectural structure, and the depth
of detail required.
The initial type of architectural data content to be collected is determined by the established
scope of the Architectural Description, and recorded as attributes, associations, and concepts
as described in the DM2. A mapping from DM2 concepts, associations, and attributes to
architecture models suggests relevant architectural views the architect may develop (using
associated architecture techniques) during the more comprehensive and coherent data
collection of Step 4. This step is normally completed in conjunction with Step 4, a bottom-up
approach to organized data collection, and Architectural Description development typically
iterates over these two steps. As initial data content is scoped, additional data scope may be
suggested by the more comprehensive content of Architectural Views desired for
presentation or decision-making purposes.
This step can often be simplified through reuse of data previously collected by others, but
relevant to the current effort. Access to appropriate COI data and other architecture
information, discoverable via DARS and the DMR, can provide information on data and other
architectural views that may provide useful in a current effort.
Work is presently underway within the Department to ensure uniform representation for the
same semantic content within architecture modeling, called Architecture Modeling Primitives.
The Architecture Modeling Primitives, hereafter referred to as Primitives, will be a standard
set of modeling elements, and associated symbols mapped to DM2 concepts and applied to
modeling techniques. Using the Primitives to support the collection of architecture content
and, in concert with the PES, will aid in generating common understanding and
communication among architects in regard to architectural views. As the Primitives concepts
are applied to more modeling techniques, they will be updated in the DoDAF Journal and
details provided in subsequent releases of DoDAF. When creating an OV-6c in Business
Process Modeling Notation (BPMN), the Primitives notation may be used. DoD has created
the notation and it is in the DoDAF Journal. The full range of Primitives for views, as with the
current BPMN Primitives, will be coordinated for adoption by architecture tool vendors.
Step 4: Collect, Organize, Correlate, and Store Architectural Data. Architects typically
collect and organize data through the use of architecture techniques designed to use views
(e.g., activity, process, organization, and data models as views) for presentation and
13
DoDAF Architecture Development - 6 Step Process
http://cio-nii.defense.gov/sites/dodaf20/arch_development.html[3/3/2011 3:33:54 PM]
decision-making purposes. The architectural data should be stored in a recognized
commercial or government architecture tool. Terms and definitions recorded are related to
elements of the (DM2).
Designation of a data structure for the Architectural Description effort involves creation of a
taxonomy to organize the collected data. This effort can be made considerably simpler by
leveraging existing, registered artifacts registered in DARS, to include data taxonomies and
data sets. Each COI maintains its registered data on DARS, either directly or through a
federated approach. In addition, some organizations, such as U.S. Joint Forces Command
(JFCOM), have developed templates, which provide the basis of a customizable solution to
common problems, or requirements, which includes datasets already described and
registered in the DMR. Examples of this template-based approach are in the DoDAF Journal.
DARS provides more information that is specific, and guidance on retrieving needed data
through a discovery process. Once registered data is discovered, the data can be cataloged
and organized within a focused taxonomy, facilitating a means to determine what new data
is required. New data is defined, registered in DARS, and incorporated into the taxonomy
structure to create a complete defined list of required data. The data is arranged for upload
to an automated repository to permit subsequent analysis and reuse. Discovery metadata
(i.e., the metadata that identifies a specific Architectural Description, its data, views, and
usage) should be registered in DARS as soon as it is available to support discovery and
enable federation. Architects and data managers should use the DoD EA Business Reference
Model (DoD EA BRM) taxonomy elements as the starting point for their registration efforts.
Additional discovery metadata, such as processes and services may be required later, and
should follow the same registration process.
Step 5: Conduct Analyses in Support of
