Step 5: Conduct Analyses in Support of Architecture Objectives. Architectural data
analysis determines the level of adherence to process owner requirements. This step may
also identify additional process steps and data collection requirements needed to complete
the Architectural Description and better facilitate its intended use. Validation applies the
guiding principles, goals, and objectives to the process requirement, as defined by the
process owner, along with the published performance measures (metrics), to determine the
achieved level of success in the Architectural Description effort. Completion of this step
prepares the Architectural Description for approval by the process owner. Changes required
from the validation process, result in iteration of the architecture process (repeat steps 3
through 5 as necessary).
Step 6: Document Results in Accordance with Decision-Maker Needs. The final step
in the architecture development process involves creation of architectural views based on
queries of the underlying data. Presenting the architectural data to varied audiences requires
transforming the architectural data into meaningful presentations for decision-makers. This is
facilitated by the data requirements determined in Step 3, and the data collection methods
employed during Step 4.
DoDAF V2.0 provides for models and views. DoDAF-described Models are those models that
enable an architect and development team whose data has already been defined and
described consistent with the DM2. The models become views when they are populated with
architectural data. These models include those previously described in earlier versions of
DoDAF, along with new models incorporated from the MODAF, the NATO NAF, and TOGAF
that have relevance to DoD architecture development efforts.
Fit-for-Purpose Views are user-defined views that an architect and development team can
create to provide information necessary for decision-making in a format customarily used in
an agency. These views should be developed consistent with the DM2, but can be in formats
(e.g., dashboards, charts, graphical representations) that are normally used in an agency for
briefing and decision purposes. An Architectural Description development effort can result in
an Architectural Description that is a combination of DoDAF-described Models and Fit-forPurpose Views.
DoDAF does not require specific models or views, but suggests that local organizational
presentation types that can utilize DoDAF-created data are preferred for management
14
DoDAF Architecture Development - 6 Step Process
http://cio-nii.defense.gov/sites/dodaf20/arch_development.html[3/3/2011 3:33:54 PM]
presentation. A number of available architecture tools support the creation of views
described in this step. The PES provides the format for data sharing.
NOTE: DoDAF V2.0 does NOT prescribe a Physical Data Model, leaving that task to the
software developers who will implement the principles and practices of DoDAF in their
own software offerings.
Scoping Architectures to be "Fit-for-Purpose"
Establishing the scope of an architecture is critical to ensuring that its purpose and use are
consistent with specific project goals and objectives. The term “Fit-for-Purpose” is used in
DoDAF to describe an architecture (and its views) that is appropriately focused (i.e.,
responds to the stated goals and objectives of process owner, is useful in the decisionmaking process, and responds to internal and external stakeholder concerns. Meeting
intended objectives means those actions that either directly support customer needs or
improve the overall process undergoing change. The architect is the technical expert who
translates the decision-maker’s requirements into a set of data that can be used by
engineers to design possible solutions. At each tier of the DoD, goals and objectives, along
with corresponding issues that may exist should be addressed according to the established
scope and purpose, (e.g., Departmental, Capability, SE, and Operational), as shown in the
notional diagram in the figure below.
Establishing the Scope for Architecture Development
Establishing a scope for an architecture effort at any tier is similarly critical in determining
the architecture boundaries (Purpose and Use expected), along with establishing the data
categories needed for analysis and management decision-making. Scope also defines the
key players whose input, advice, and consensus is needed to successfully architect and
implement change (i.e., Stakeholders, both internal and external). Importantly, scope also
determines the goals and objectives of the effort, consistent with both boundaries and
15
DoDAF Architecture Development - 6 Step Process
http://cio-nii.defense.gov/sites/dodaf20/arch_development.html[3/3/2011 3:33:54 PM]
stakeholders; since goals and objectives define both the purpose for architecture creation
and the level of the architecture. Establishing the scope of an effort also determines the level
of complexity for data collection and information presentation.
Architecture development also requires an understanding of external
