Where are the process bottlenecks?
2. Are the activities and procedures interoperable?
3. Identify new and emerging systems interoperability requirements.
4. Uncover unnecessary or inefficient operational activities and information flows.
5. Evaluate alternative architectures with different connectivity and Resource Flow
to maximize capability and minimize automation complexity.
6. Identify critical connectivity needs and interfaces (or Key Interface Profiles
(KIPs) between activities and their performers (organizations and personnel
types).
7. Critical Interfaces are generally documented in formal interface documentation
signed by the responsible authorities (both information supplier and information
consumer) in charge of each end of the interface. This type of interface may be
annotated as a Key Interface (KI). A KI is defined as an interface where one or
more of the following criteria are met:
8. Support Analysis of Alternatives (AoA) and other Systems Engineering Analysis.
b. DAS
1. The interface spans organizational boundaries (may be across instances of the
same system, but utilized by different organizations).
2. Support the development of test sequences and procedures.
3. The Details of Resource Flow (materiel, personnel, or data) are generally
documented in Interface Control Documents (ICDs), Interface Requirements
Specifications (IRSs) and Interface Description Documents (IDDs). This data is
typically provided to DoD Investment Review Board (IRB) registry systems for
48
DM2 - Resource Flows
http://cio-nii.defense.gov/sites/dodaf20/resource_flows.html[3/3/2011 3:43:08 PM]
the purpose of milestone reviews and support of acquisition decisions points.
c. PPBE
1. Ensure FYDP provides flows needed for operations and missions
2. Ensure consumption requirements are met by producers
d. SE
1. Identify new system or service, functions (activities), components and
modifications required.
2. Identify new Resource Flow and system integration requirements.
3. Identification of the need for Application of new standards.
4. Clearly identify the relationship and information flow between systems and
system/services in an SoS or between services in a Service Oriented
Architecture (SOA) including definition of publish or subscribe requirements
5. Interface Identification and Definition including interoperability analysis and
standardization.
6. Support configuration management of interfaces. Interfaces are generally
documented in interface documentation representing the agreements of the
responsible parties in charge of each end of the interface (both information
supplier and information consumer). This, in no way implies a point-to-point
interface. Interfaces implemented with an enterprise service bus, for example,
are defined with appropriate publish/subscribe documentation formalized, if
necessary, with contractual agreements between information supplier and
consumer.
7. Critical interfaces are generally documented in formal interface documentation
signed by the responsible authorities (both information supplier and information
consumer) in charge of each end of the interface. For legacy point-to-point
interfaces this may be in the form of Interface Control Drawings (ICDs),
Interface Requirement Documents (IRSs), Interface Design Documents (IDDs),
etc. In multiple access or common connectivity (radio communications or bus
type connectivity) implementations may be in the form of formal agreements
(defined herein as a consent among parties regarding the terms and conditions
of activities that said parties participate in) detailing the specific set of
implementations (e.g., Tactical Digital Information Links [TADILs]) data
elements implementation tables or in the case of a SOA, a publish/subscribe
implementation document. These agreements are, in general, managed and
controlled by the SoS or System Project manager. In new systems, and where
possible the interface should be managed and configuration controlled using a
common precision data model. Figure 4 illustrates the evolution from
configuration control of legacy point-to-point interfaces to a net-centric,
distributed processing means of connectivity using carefully managed publish
and subscribe agreements and documentation based on
