g环境
在AC 800M控制器系统联机之前，调查
环境条件适用。特别注意到：
以下是：
•控制器不得暴露在超过给定值的条件下
在相关技术规范中。
•控制器不得在强电环境中使用
干扰电机会产生超过水平的干扰
允许用于设备，例如在维修工作期间。
•处理所有产品时，必须采取以下适当预防措施：
静电损坏。
•控制器不得直接暴露在阳光下。
重要软件检查
•使用系统的故障监测设施防止事故或事故。
•如有疑问，在执行更改之前，始终进行检查。
重要硬件注意事项
•在任何情况下，不得断开
正常运行的系统。始终使用正确的系统关机
断开电源前的步骤。
电缆引起的信号噪声
可能导致电气干扰的电缆（例如电源电缆）
不得安装在传输快速数字信号的总线电缆附近。确保
安装在内部的电缆之间的小距离为10厘米（4英寸）
橱柜。
危险电源
人员可能进入的操作和维护程序
接触高压时，只能由受过充分培训的人员进行
这些环境中电气设备的维护，以及
充分意识到所涉及的所有风险。
18 3BSE036351-510 A
安全摘要
静电敏感器件
标有此符号的设备需要特殊处理注意事项，如：
如安装部分所述。
将军
警告
设备环境
所有部件，无论是在运输、操作或储存过程中，必须
在非腐蚀性环境中。
维护期间的触电危险
断开电源或采取预防措施，以确保维修时避免接触带电部件。
具体的
警告
第67页：安装在DIN导轨上时，AC 800M控制器和相关装置必须断电并断开连接！
第68页：不允许在通电状态下操作CEX总线基板
以及运行系统。在更换或拆除底板之前，所有CEX
必须移除该段上的模块。
第72页：AC 800M装置必须与电源断开连接
在将其从DIN导轨上移除之前！
第72页：不允许在通电状态下操作CEX总线基板
以及运行系统。在更换或拆除底板之前，所有CEX
必须移除该段上的模块。
第78页：对于PM861/PM864/PM865/PM866，将RCU链路终端插头TB852插入RCU链路连接器。终端插头必须：
单独运行时，始终用于PM861/PM864/PM865/PM866
配置当冗余处理器在单个配置中运行时，如果RCU链路终端插头
TB852不可用。
500RI011 1MRB150026M1 自动驱动控制器

500RI011 1MRB150026M1 自动驱动控制器

g Environment
Before the AC 800M Controller system is brought online, investigate which
environmental conditions are applicable. Take note in particular of the
following:
• The controller must not be exposed to conditions that exceed the values given
in the relevant technical specifications.
• The controller must not be used in an environment exposed to strong electrical
interference. Electrical machines can produce interference that exceeds levels
permitted for the equipment, for example during repair work.
• All products must be handled with appropriate precautions with regard to
electrostatic damage.
• The controller must not be exposed to direct sunlight.
Important Software Check
• Use the system’s fault-monitoring facilities to prevent accidents or mishaps.
• When in doubt, ALWAYS CHECK before executing changes.
Important Hardware Notice
• DO NOT, under any circumstances, disconnect the power supply to a
normally functioning system. Always use the correct system shut-down
procedure prior to disconnecting the power supply.
Signal Noise Due to Cables
Cables which may cause electrical interference (for example, power supply cables)
must not be installed adjacent to bus cables carrying fast digital signals. Ensure that
a minimum distance of 10 cm (4 in.) is provided between cables installed inside
cabinets.
Hazardous Electrical Supplies
Operational and maintenance procedures, during which personnel may come into
contact with high voltage, should only be carried out by personnel fully trained in
the maintenance of electrical equipment within those environments, and who are
fully aware of all risks involved.
18 3BSE036351-510 A
Safety Summary
Electrostatic Sensitive Device
Devices labeled with this symbol require special handling precautions as
described in the installation section.
GENERAL
 WARNINGS
Equipment Environment
All components, whether in transportation, operation or storage, must be
in a noncorrosive environment.
Electrical Shock Hazard During Maintenance
Disconnect power or take precautions to insure that contact with energized parts is avoided when servicing.
SPECIFIC
WARNINGS
Page 67: The AC 800M Controller and associated units must be unpowered and disconnected when being mounted onto a DIN-rail!
Page 68: It is not allowed to manipulate CEX bus baseplates in a powered
and running system. Before changing or removing a baseplate, all CEX
modules on that segment must be removed.
Page 72: AC 800M units must be disconnected from the power source
before removing them from a DIN-rail!
Page 72: It is not allowed to manipulate CEX bus baseplates in a powered
and running system. Before changing or removing a baseplate, all CEX
modules on that segment must be removed.
Page 78: For PM861/PM864/PM865/PM866 insert the RCU Link Termination plug TB852, at the RCU Link connector. The termination plug must
always be used for PM861/PM864/PM865/PM866 when running in single
configuration. When a redundant processor is running in a single configuration use the RCU Link Cable TK851, if the RCU Link Termination plug
TB852 is not available.
