直接安装在处理器单元基板上的CEX总线上，或
至CEX总线互连单元BC810。通信接口为
然后安装到SM810上的CEX总线。参见100页的图31
配置示例参见101页的图32。
数字I/O连接
SM810有一个带有两个数字输入和三个数字输出的连接器，可以：
用于与高完整性相关的数字I/O（非过程I/O）。见表10。
输入信号用于系统功能，参见AC 800M高完整性
文档
在冗余配置中
SM810必须连接到公共数字输入开关。
例如，两个SM810的I2必须连接到公共开关。如果
使用单独的源时，将源连接到公共交换机，然后
从交换机导出到两个SM810的连接。
表10.SM810数字输入/输出连接器
引脚名称描述
1通公共I/O电源
2 I1数字输入1（重置所有力）
3 I2数字输入2（访问启用）
4 I3数字输入3
5 O1数字输出1（任何力激活）
6氧气数字输出2（系统报警）
7 ZP通用输入/输出回路
2节安装安装SM810/TP855
3BSE036351-510 A 105
输入信号与SM810的连接
图35输入信号与冗余SM810的连接。
0V B 0V A
24V A
24V B
I1：重置所有力
I2：访问启用
安装SM810/TP8552节安装
106 3BSE036351-510 A
输出信号与SM810的连接
图36冗余SM810输出信号的连接。
24V B 24V A
O1：任何有效力
O2：系统报警
0V
2节安装安装SM811/TP868
3BSE036351-510 A 107
安装SM811/TP868
SM811直接安装在处理器单元基板上的CEX总线上，或
至CEX总线互连单元BC810。通信接口为
然后安装到SM811上的CEX总线。参见100页的图31
配置示例参见101页的图32。使用封闭电缆
TK852V010在冗余情况下连接两个SM811的SM链路
配置
数字I/O连接
SM811有一个带有三个数字输入和两个数字输出的连接器，可以：
用于与高完整性相关的数字I/O（非过程I/O）。见表11。
访问启用输入（I2）必须连接到操作员的钥匙开关
面板复位所有力输入（I1）和热插入输入（I3）必须连接到
脉冲式面板（如果使用）。
输入信号用于系统功能，参见AC 800M高完整性
文档
在冗余配置中
SM811必须连接到公共数字输入开关。
例如，两个SM811的I3必须连接到公共开关。如果
使用单独的源时，将源连接到公共交换机，然后
从交换机到两个SM811的连接。
表11.SM811数字输入/输出连接器
引脚名称描述
1通公共I/O电源
2 I1数字输入1（重置所有力）
3 I2数字输入2（访问启用）
4 I3数字输入3（SM热插入）
5 O1数字输出1（任何力激活）
安装SM811/TP8682节安装
108 3BSE036351-510 A
6氧气数字输出2（系统报警）
7 ZP通用输入/输出回路
表11.SM811数字输入/输出连接器
引脚名称描述
2节安装安装SM811/TP868
3BSE036351-510 A 109
输入信号与SM811的连接
图37.输入信号与冗余SM811的连接
0V B 0V A
24V A
24V B
I1：重置所有力
I2：访问启用
I3：SM的热插入
安装SM811/TP8682节安装
110 3BSE036351-510 A
输出信号与SM811的连接
图38冗余SM811输出信号的连接
24V B 24V A
O1：任何有效力
O2：系统报警
0V
2节安装安装PROFIBUS DP接口，CI851/TP851
3BSE036351-510 A 111
安装PROFIBUS DP接口，CI851/TP851
CI851由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
使用以下步骤安装CI851/TP851：
1.将装置安装到DIN导轨上，请参阅将AC 800M装置安装在DIN导轨上
在65页，将PM86x/TP830处理器单元安装在单个
配置见78页。
2.在PROFIBUS DP电缆上安装连接器。将电缆屏蔽连接到
连接器内的接地端子通过CI581将屏幕接地。
建议使用带有可切换内置总线终端的连接器。
3.将PROFIBUS DP电缆连接至底板上的触点。
4.如果这是PROFIBUS DP电缆的末端，则打开总线终端。
否则，关闭总线终端。
PROFIBUS DP连接
PROFIBUS DP电缆通过9-p连接
