800xA基本系统800xA 5.1
包括一个操作员工作场所、一个工程工作场所、AC 800M连接，
冗余方面服务器、工厂资源管理器、拓扑状态查看器、软点服务器、调度器、，
主要历史记录（操作员趋势信号记录长达3个月），10资产
监视器和诊断收集。用户的快速登录。
1条。
800xA基础系统，800xA 5.1 3BSE061234R1
标签
所有具有操作员交互面板的流程对象都算作标记。
（总计大120000。不能与冗余标签混合）。
注：在pricebook版本中，超过60000个标签的系统需要TSA。
订购前，请在TSA数据库中检查当前对TSA的需求。
非冗余标签物品编号。
100个标签，非冗余，800xA 5.1 3BSE061235R1
1000个标签，非冗余，800xA 5.1 3BSE061235R2
10000个标签，非冗余，800xA 5.1 3BSE061235R3
具有操作员面板的所有流程对象都算作标记。
（总计大120000。不能与非冗余标签混合）。
（通过冗余连接服务器启用标记访问。）
冗余标签文章编号。
100个标签，冗余，800xA 5.1 3BSE061236R1
1000个冗余标签，800xA 5.1 3BSE061236R2
10000个冗余标签，800xA 5.1 3BSE061236R3
多系统集成
多系统集成配置中用户系统中的标签。这些标签是对象
具有从提供者系统收集数据的面板。
请注意，非冗余多系统订户标签不能与多系统混合
订户冗余标签。
多系统集成配置中用户系统中的标签。
注：在价格手册发布时，该项目需要订购TSA。
订购前，请在TSA数据库中检查当前对TSA的需求。
多系统订户标签文章编号。
100多系统用户标签3BSE072204R1
1000多系统用户标签3BSE072204R2
10000多系统用户标签3BSE072204R3
多系统订户冗余标签文章编号。
100多系统用户冗余标签3BSE072205R1
1000多系统用户冗余标签3BSE072205R2
10000多系统用户冗余标签3BSE072205R3
系统800xA产品目录|软件9
连通性
连通性
请注意，某些特定OCS可能不支持800xA价目表选项
控制器。请参阅中的表“每个控制器连接的可用功能”
系统指南“技术数据和配置信息”。
要检查哪些连接组合有效，请使用项目向导或参考
系统800xA系统指南。
1条。
800xA用于Advant Master，800xA 5.1
（每个系统一个。）
RTA硬件需要单独订购。请参阅
价格手册3BSE001706，Advant OCS和主软件，用于
RTA硬件。
3BSE061237R1
Advant Master中央备份，800xA 5.1
Advant Master应用程序的备份和恢复
控制器（AC410、AC450、MP200/1、SG400）每个
系统Advant Master需要800xA。
注：在价格手册发布时，该项目需要TSA
命令。订购前，请在TSA数据库中检查当前对TSA的需求。
3BSE070712R1
800xA适用于300型，800xA 5.1
（每个系统一个。）
RTA硬件需要单独订购。请参阅
价格手册3BSE001709，带300型软件的Advant OCS，用于
RTA硬件。
3BSE061238R1
800xA用于和声，800xA 5.1
（每个系统一个。）
3BSE061239R1
用于DCI的800xA，800xA 5.1
与和谐分布式控制单元（HDCU）的连接，
包括：批量连接、VB6和PG2面板、HDCU
维护功能。
3BSE064196R1
800xA用于AC 870P/旋律，800xA 5.1
（不包括面板）。（每个系统一个。）
3BSE061240R1
PLC连接，800xA 5.1
（每个系统一个。）
3BSE061242R1
PLC连接拨号，800xA 5.1
（拨号时使用的每个串行通信信道一个
表达需要PLC连接。按数量缩放
系统中的拨号线路）。
3BSE061243R1
800xA用于防护，800xA 5.1
（每个系统一个）对于Advant Master也需要800xA。
3BSE061244R1
800xA用于AC 100
AC 100连接封装，包括图形元素，
面板，OPC服务器需要使用AC 100控制器
800xA。
3BSE064565R1
HEIE421331R0001 UT374C-E UT374C-ER0001 自动化控制卡 ABB
HEIE421331R0001 UT374C-E UT374C-ER0001 自动化控制卡 ABB
800xA Base System 800xA 5.1
Includes one Operator Workplace, one Engineering Workplace, AC 800M Connectivity,
Redundant Aspect Server, Plant Explorer, Topology Status Viewer, Softpoint Server, Scheduler,
Primary History Logs (logging of signals for operator trends for up to 3 months), 10 Asset
Monitors and Diagnostics Collection. Fast log-over of users.
Article no.
800xA Base System, 800xA 5.1 3BSE061234R1
Tags
All process objects with faceplate for operator interactions counts as a tag.
(Total max 120,000. Can not be mixed with redundant tags).
NOTE: At pricebook release a TSA was NEEDED for a system with more than 60,000 tags.
Please, check current need of a TSA in the TSA Database before ordering.
Non-redundant Tags Article no.
100 tags, non-redundant, 800xA 5.1 3BSE061235R1
1,000 tags, non-redundant, 800xA 5.1 3BSE061235R2
10,000 tags, non-redundant, 800xA 5.1 3BSE061235R3
All process objects with an operator faceplate counts as a tag.
(Total max 120,000. Can not be mixed with non-redundant tags).
(Enables tag access through redundant Connectivity Servers.)
Redundant Tags Article no.
100 tags, redundant, 800xA 5.1 3BSE061236R1
1,000 tags, redundant, 800xA 5.1 3BSE061236R2
10,000 tags, redundant, 800xA 5.1 3BSE061236R3
Multisystem Integration
Tags in the subscriber system in a Multisystem Integration configuration. These tags are Object
with a faceplate that collects data from a provider system.
Note that non-redundant Multisystem Subscriber Tags can not be mixed with Multisystem
Subscriber Redundant Tags.
Tags in the subscriber system in a Multisystem Integration configuration.
Note: At pricebook release this item required a TSA to be ordered.
Please, check current need of a TSA in the TSA Database before ordering.
Multisystem Subscriber Tags Article no.
100 Multisystem Subscriber Tags 3BSE072204R1
1,000 Multisystem Subscriber Tags 3BSE072204R2
10,000 Multisystem Subscriber Tags 3BSE072204R3
Multisystem Subscriber Redundant Tags Article no.
100 Multisystem Subscriber Redundant Tags 3BSE072205R1
1,000 Multisystem Subscriber Redundant Tags 3BSE072205R2
10,000 Multisystem Subscriber Redundant Tags 3BSE072205R3
System 800xA Product Catalog | Software 9
Connectivity
Connectivity
Note that there may be 800xA price list options that are not supported with a particular OCS
controller. Please refer to the table “Available functions per Controller Connectivity” in the
System Guide “Technical Data and Configuration Information”.
To check what connectivity combinations that are valid, use the Project Wizard or refer to the
System 800xA System Guide for information.
Article no.
800xA for Advant Master, 800xA 5.1
(One per system.)
RTA hardware needs to be ordered separately. Please refer to
pricebook 3BSE001706, Advant OCS with Master Software, for
RTA hardware.
3BSE061237R1
Advant Master Central Backup, 800xA 5.1
Backup and restore of applications for Advant Master
controllers (AC410, AC450, MP200/1, SG400) One license per
system. Requires 800xA for Advant Master.
Note: At pricebook release this item required a TSA to be
ordered. Please, check current need of a TSA in the TSA Database before ordering.
3BSE070712R1
800xA for MOD 300, 800xA 5.1
(One per system.)
RTA hardware needs to be ordered separately. Please refer to
pricebook 3BSE001709, Advant OCS with MOD 300 SW, for
RTA hardware.
3BSE061238R1
800xA for Harmony, 800xA 5.1
(One per system.)
3BSE061239R1
800xA for DCI, 800xA 5.1
Connectivity to Harmony Distributed Control Unit (HDCU),
includes: Batch connectivity, VB6 and PG2 faceplates, HDCU
maintenance functions.
3BSE064196R1
800xA for AC 870P / Melody, 800xA 5.1
(Faceplates not included). (One per system.)
3BSE061240R1
PLC Connect, 800xA 5.1
(One per system.)
3BSE061242R1
PLC Connect Dial-Up, 800xA 5.1
(One per serial communication channel used with dialed
communication. PLC Connect is required. Scaled on number of
dial up lines in a system).
3BSE061243R1
800xA for Safeguard, 800xA 5.1
(One per system.) Requires also 800xA for Advant Master.
3BSE061244R1
800xA for AC 100
AC 100 conect package including Graphics Elements,
Faceplates, OPC server required to use AC 100 controllers in
800xA.
3BSE064565R1
