合并历史日志
合并日志从多个历史服务器收集数据，并将其存储在单个位置。
这为查看和报告提供了一个公共历史存储库。
（每台服务器的总大值为300000，大值为50000。）
1条。
100个合并历史记录，800xA 5.1 3BSE061328R1
1000个合并历史记录，800xA 5.1 3BSE061329R1
15000份合并历史记录，800xA 5.1 3BSE061330R1
历史记录显示和报告选项
1条。
MDI显示生成器-附加客户端，800xA 5.1
提供为创建MDI信息显示的功能
桌面应用程序。
3BSE061331R1
多显示接口（MDI）-附加客户端，800xA 5.1
（每个服务器多64个）。提供查看MDI信息的功能
显示桌面应用程序。
3BSE061332R1
桌面趋势-附加客户端，800xA 5.1
为桌面应用程序提供趋势查看。包括网络
启用长期和短期历史和股票的趋势显示
它就像一个观众。（每个服务器多64个）。
3BSE061333R1
历史数据访问选项
通过SQL从三方应用程序访问历史数据。
具有趋势的批量报告需要ODBC服务器（3BSE061335R1）和ODBC客户端
（3BSE061336R1）选项。此选项提供连接Oracle数据库所需的链接
（PDL）以及数字日志和过程数据。
使用商业三方报告工具的应用程序还应包括ODBC服务器
（3BSE061335R1）和ODBC客户端（3BSE06336R1）选项。客户端连接数为
基于应用程序是直接还是间接利用连接。如果连接是
如果是间接创建的（使用Oracle），则客户端连接只需要一个。如果客户端连接
则客户端的数量应等于并发用户的数量。
1条。
Excel数据访问，800xA 5.1
从三方通过SQL访问历史数据
应用。用于从以下位置访问Excel中的历史数据：
非800xA PC。对于800xA客户端PC的Excel数据访问：
包括。（每个服务器多64个）。
3BSE061334R1
ODBC历史数据服务器，800xA 5.1
ODBC，包括三方代码。（每台服务器一个。）
3BSE061335R1
ODBC客户端连接，800xA 5.1
ODBC客户端与ODBC服务器分开购买。
（每个ODBC服务器多10个。）
3BSE061336R1
信息管理
18软件|系统800xA产品目录
800xA历史信号-日志
历史信号能够存储从800xA、Heritage检索的实际值和历史值
ABB DCS系统和OPC源。信号包括测井、趋势、计算和
存档。（每个服务器节点多75000个，每个服务器多可存储6个数据源的信号）。
1条。
800xA历史信号-基本100信号
注：在价格手册发布时，该项目需要TSA
命令。请在TSA中检查TSA的当前需求
订购前的数据库。
3BSE067077R1
800xA历史信号-基本1000信号
注：在价格手册发布时，该项目需要TSA
命令。请在TSA中检查TSA的当前需求
订购前的数据库。
3BSE067077R10
800xA历史信号-基本15000信号
注：在价格手册发布时，该项目需要TSA
命令。请在TSA中检查TSA的当前需求
订购前的数据库。
3BSE067077R150
800xA双历史信号-日志
两个历史服务器中并行记录的历史信号。
双历史信号的数量应与历史信号数量相匹配
1条。
800xA双历史信号-100个信号
注：在价格手册发布时，此项目需要TSA。
请检查TSA数据库中当前对TSA的需求
在订购之前。
3BSE073477R1
PM633 3BSE008062R1 PM 633 CPU处理器模块 ABB
PM633 3BSE008062R1 PM 633 CPU处理器模块 ABB
Consolidated History Logs
Consolidated logs collect data from multiple History Servers and store it in a single location.
This provides a common history repository for viewing and reporting.
(Total max 300,000 and max 50,000/Server.)
Article no.
100 Consolidated History Logs, 800xA 5.1 3BSE061328R1
1,000 Consolidated History Logs, 800xA 5.1 3BSE061329R1
15,000 Consolidated History Logs, 800xA 5.1 3BSE061330R1
Historian Display and Reporting Options
Article no.
Display Builder for MDI - Additional Client, 800xA 5.1
Provides the ability to create MDI information displays for
desktop applications.
3BSE061331R1
Multi-Display Interface (MDI) - Additional Client, 800xA 5.1
(Max 64 per Server). Provides the ability to view MDI information
displays for desktop applications.
3BSE061332R1
Desktop Trends - Additional Client, 800xA 5.1
Provides trend viewing for desktop applications. Includes web
enabled trend display for long and short term history and stock
ticker like viewer. (Max 64 per Server).
3BSE061333R1
Historian Data Access Options
To access historical data through SQL from third party applications.
Batch Reports with trending requires the ODBC Server (3BSE061335R1) and ODBC Client
(3BSE061336R1) option. This option provides the links necessary to connect the Oracle database
(PDL) and the numeric log and process data.
Applications which utilize commercial third party reporting tools should also include the ODBC Server
(3BSE061335R1) and ODBC Client (3BSE061336R1) option. The number of client connection is
based on whether the applications utilizes the connection directly or indirectly. If the connection is
made indirectly (using Oracle), then the client connection requires is only one. If the client connections
are direct, then the number of clients should equal the number of concurrent users.
Article no.
Excel Data Access, 800xA 5.1
To access historical data through SQL from third party
applications. Used to access historical data in Excel from
non 800xA PC’s. For 800xA Client PC’s Excel Data Access is
included. (Max 64 per Server).
3BSE061334R1
ODBC Historical Data Server, 800xA 5.1
ODBC, includes third party code. (One per server.)
3BSE061335R1
ODBC Client Connection, 800xA 5.1
ODBC Clients are purchased separately from the ODBC server.
(Max 10 per ODBC Server.)
3BSE061336R1
Information Management
18 Software | System 800xA Product Catalog
800xA History Signals - Logs
History signals capable of storing actual and historic values retrieved from 800xA, Heritage
ABB DCS systems and OPC sources. The signals include logging, trending, calculations and
archiving. (Max 75,000 per Server node, signal storage for up to 6 data sources per Server).
Article no.
800xA History Signals - Basic 100 signals
Note: At pricebook release this item required a TSA to be
ordered. Please, check current need of a TSA in the TSA
Database before ordering.
3BSE067077R1
800xA History Signals - Basic 1000 signals
Note: At pricebook release this item required a TSA to be
ordered. Please, check current need of a TSA in the TSA
Database before ordering.
3BSE067077R10
800xA History Signals - Basic 15000 signals
Note: At pricebook release this item required a TSA to be
ordered. Please, check current need of a TSA in the TSA
Database before ordering.
3BSE067077R150
800xA Dual History Signals - Logs
History signals for parallel logging in two history servers.
The number of dual history signals should match the number of history signals
Article no.
800xA Dual History Signals - 100 signals
Note: At pricebook release a TSA was NEEDED for this item.
Please, check current need of a TSA in the TSA Database
before ordering.
3BSE073477R1
