以下信息在发布时是正确的。有关当前信息，请参阅www.hp.com/
支持/ljM631MFP，www.hp。com/support/ljM632MFP，或www.hp.com/support/ljM633MFP。
HP针对打印机的全包式帮助包括以下信息：
● 安装和配置
● 学习和使用
● 解决问题
● 下载软件和固件更新
● 加入支持论坛
● 查找保修和监管信息
ENWW 1
打印机视图
● 打印机前视图
● 打印机后视图
● 接口端口
● 控制面板视图
打印机前视图
带彩色触摸屏显示器的4ol面板（向上倾斜以便于查看）
2文档进纸器输入托盘
3文件进纸器输出箱
4.文档进纸器输出扩展（当扫描更长时间时，如法律文件时，扩展此扩展）
5扫描仪组件
21章打印机概述ENWW
19 3x550纸张托盘（随M631z提供；M631dn、M631h、M632h和M633fh可选）
20 HP装订邮箱（包括在M631z、M632z和M633z中）
21硬件集成袋（用于连接附件和三方设备）
22键盘（仅限M632z和M633z。直接拉出键盘即可使用。）
注意：不使用键盘时请关闭键盘。
23订书机门（包括M631z、M632z和M633z
24 1x550纸张托盘和2100纸张高容量输入托盘（包括在M632z和M633z中；M631dn可选，
M631h、M632h和M633fh）
ENWW打印机视图3
打印机后视图
文档进纸器盖释放闩锁
2.文件馈送器盖（清除堵塞的通道）
3弹壳门释放按钮
4墨盒门（调色剂盒的入口）
5序列号和产品编号标签
41章打印机概述ENWW
用于连接外部USB设备的ost USB端口（此端口可能会被覆盖）
注意：为了方便访问USB打印，请使用控制面板附近的USB端口。
2个高速USB 2.0打印端口
3局域网（LAN）以太网（RJ-45）网络端口
4个传真端口（仅限传真型号）
控制面板视图
主屏幕提供对打印机功能的访问，并指示打印机的当前状态。
通过触摸打印机控制面板左侧的主页按钮，随时返回主页屏幕，
或触摸大多数屏幕左上角的主页按钮。
注意：主屏幕上显示的功能可能会有所不同，具体取决于打印机配置。
ENWW打印机视图5
1主页按钮触摸主页按钮返回主页屏幕。
2应用程序区域触摸任何图标以打开应用程序。横向滑动屏幕以访问更多应用程序。
注意：可用的应用程序因打印机而异。管理员可以配置哪些应用程序
以及它们出现的顺序。
3重置按钮触摸重置按钮以清除更改，将打印机从暂停状态释放，重置复印计数
ƭeld，显示隐藏错误，并恢复默认设置（包括语言和键盘
布局）。
4登录或注销按钮触摸登录按钮以访问安全功能。
按注销按钮注销打印机。打印机将所有选项恢复为默认值
设置。
注意：仅当管理员已将打印机配置为需要权限时，才会显示此按钮
用于访问功能。
5.信息按钮：触摸信息
9907-019 负载分配和速度控制 WOODWARD/伍德沃德
9907-019 负载分配和速度控制 WOODWARD/伍德沃德
The following information is correct at the time of publication. For current information, see www.hp.com/
support/ljM631MFP, www.hp.com/support/ljM632MFP, or www.hp.com/support/ljM633MFP.
HP's all-inclusive help for the printer includes the following information:
● Install and conƭgure
● Learn and use
● Solve problems
● Download software and ƭrmware updates
● Join support forums
● Find warranty and regulatory information
ENWW 1
Printer views
● Printer front view
● Printer back view
● Interface ports
● Control-panel view
Printer front view
4ol panel with color touchscreen display (tilts up for easier viewing)
2 Document-feeder input tray
3 Document-feeder output bin
4 Document-feeder output extension (extend this when scanning longer—such as legal—paper)
5 Scanner assembly
2 Chapter 1 Printer overview ENWW
19 3x550-sheet tray (included with the M631z; optional for the M631dn, M631h, M632h, and M633fh)
20 HP Stapling Mailbox (included with the M631z, M632z, and M633z)
21 Hardware integration pocket (for connecting accessories and third-party devices)
22 Keyboard (M632z and M633z only. Pull the keyboard straight out to use it.)
CAUTION: Close the keyboard when it is not in use.
23 Stapler door (included with the M631z, M632z, and M633z
24 1x550-sheet tray and 2,100-sheet high-capacity input tray (included with the M632z and M633z; optional for the M631dn,
M631h, M632h, and M633fh)
ENWW Printer views 3
Printer back view
ocument feeder cover release latch
2 Document-feeder cover (access for clearing jams)
3 Cartridge door release button
4 Cartridge door (access to the toner cartridge)
5 Serial number and product number label
4 Chapter 1 Printer overview ENWW
ost USB port for connecting external USB devices (this port might be covered)
NOTE: For easy-access USB printing, use the USB port near the control panel.
2 Hi-Speed USB 2.0 printing port
3 Local area network (LAN) Ethernet (RJ-45) network port
4 Fax port (fax models only)
Control-panel view
The Home screen provides access to the printer features and indicates the current status of the printer.
Return to the Home screen at any time by touching the Home button on the left side of the printer control panel,
or touch the Home button in the upper-left corner of most screens.
NOTE: The features that appear on the Home screen can vary, depending on the printer conƭguration.
ENWW Printer views 5
1 Home button Touch the Home button to return to the Home screen.
2 Applications area Touch any of the icons to open the application. Swipe the screen sideways to access more applications.
NOTE: The available applications vary by printer. The administrator can conƭgure which applications
appear and the order in which they appear.
3 Reset button Touch the Reset button to clear changes, release the printer from a paused state, reset the copy count
ƭeld, display hidden errors, and restore the default settings (including the language and keyboard
layout).
4 Sign In or Sign Out button Touch the Sign In button to access secured features.
Touch the Sign Out button to sign out of the printer. The printer restores all options to the default
settings.
NOTE: This button displays only if the administrator has conƭgured the printer to require permission
for access to features.
5 Information button Touch the information
