help system.
7 Current time Displays the current time.
8 Start Copy button Touch the Start Copy button to start a copy job.
9 Copy count The copy count indicates the number of copies that the printer is set to make.
10 Home-screen page
indicator
Indicates the number of pages on the Home screen or in an application. The current page is
highlighted. Swipe the screen sideways to scroll between pages.
11 Keyboard
(Flow models only)
Flow models include a physical keyboard. The keys are mapped to a language in the same way the
virtual keyboard on the printer touchscreen is mapped. Whenever the keyboard layout for the virtual
keyboard changes, the keys on the physical keyboard are remapped to match the new settings.
NOTE: In some locations, the printer comes with adhesive keyboard overlays to customize the keys
for diƫerent languages.
12 Easy-access USB port Insert a USB flash drive for printing or scanning without a computer or to update the printer ƭrmware.
NOTE: An administrator must enable this port before use.
13 Hardware integration
pocket (HIP)
For connecting accessory and third-party devices.
ENWW Printer views 7
How to use the touchscreen control panel
Use the following actions to use the printer touchscreen control panel.
Action Description Example
Touch Touch an item on the screen to select that item
or open that menu. Also, when scrolling through
menus, briefly touch the screen to stop the
scrolling.
Touch the Settings icon to open the Settings app.
Swipe Touch the screen and then move your ƭnger
horizontally to scroll the screen sideways.
Swipe until the Settings app displays.
Scroll Touch the screen and then move your ƭnger
vertically to scroll the screen up and down. When
scrolling through menus, briefly touch the screen
to stop the scrolling.
Scroll through the Settings app.
8 Chapter 1 Printer overview ENWW
Printer speciƭcations
IMPORTANT: The following speciƭcations are correct at the time of publication, but they are subject to change.
For current information, see www.hp.com/support/ljM631MFP, www.hp.com/support/ljM632MFP, or
www.hp.com/support/ljM633MFP.
● Technical speciƭcations
● Supported operating systems
● Mobile printing solutions
● Printer dimensions
● Power consumption, electrical speciƭcations, and acoustic emissions
● Operating environment range
Technical speciƭcations
Model name
Product number
M631dn, M632h
K0Q14A, K0Q17A
M631h, M632fht,
M633fh
K0Q15A, K0Q18A,
K0Q21A
M631z, M632z, M633z
K0Q19A, K0Q22A
Paper handling Tray 1 (100-sheet capacity)
Tray 2 (550-sheet capacity)
1x550-sheet paper feeder
NOTE: The printer supports as
many as six input trays.
Optional Optional Optional (not available
for M631z)
1x550-sheet feeder plus 2,100-
sheet high-capacity feeder
Optional Optional Included with the
M632z and M633z
Automatic duplex printing
Envelope feeder cassette for
printing up to 75 envelopes
Optional Optional Optional
HP Stapling Mailbox Not supported Not supported
Connectivity 10/100/1000 Ethernet LAN
connection with IPv4 and IPv6
Hi-Speed USB 2.0
Easy-access USB port for printing
and scanning without a computer
and upgrading the ƭrmware
Hardware integration pocket (HIP)
for connecting accessories and
third-party devices
HP Internal USB ports Optional Optional Optional
HP Jetdirect 3000w NFC/Wireless
Accessory for printing from mobile
devices
Optional Optional Optional
ENWW Printer speciƭcations 9
Model name
Product number
M631dn, M632h
K0Q14A, K0Q17A
M631h, M632fht,
M633fh
K0Q15A, K0Q18A,
K0Q21A
M631z, M632z, M633z
K0Q19A, K0Q22A
Integrated HP Wi-Fi Direct
accessory for printing from mobile
devices
Not supported Not supported M631z and M633z
HP Jetdirect 2900nw Print Server
Accessory for wireless connectivity
Optional Optional Optional
Internal Storage 16 GB eMMC hard drive M631dn Not supported Not supported
320 GB HP High-Performance
Secure Hard Disk
Included with the
M632h; optional for
the M631dn
Memory 1.75 GB base memory, expandable
to 2.5 GB
Not supported
2.25 GB base memory, expandable
to 3 GB
Not supported Not supported
Security HP Trusted Platform Module for
encrypting all data that passes
through the printer
Optional Optional Optional
Control-panel display and input Touchscreen control panel
Retractable keyboard Not supported Not supported
Print Prints 52 pages per minute (ppm)
on A4 and 55 ppm on letter-size
paper
M631dn M631h M631z
Prints 61 ppm on A4 and 65 ppm on
letter-size paper
M632h M632fht M632z
Prints 71 ppm on A4 and 75 ppm on
letter-size paper
Not supported M633fh M633z
Easy-access USB printing (no
computer required)
Fax Optional Included with M632fht,
M633fh; optional for
the M631h
Copy and scan
NOTE: Copy and scan speeds are
subject to change. For the most
current information, go to
www.hp.com/support/ljM631MFP,
www.hp.com/support/ljM632MFP,
or www.hp.com/support/
ljM633MFP
Copies 52 pages per minute (ppm)
on A4 and 55 ppm on letter-size
paper
M631dn M631h M631z
Copies 61 ppm on A4 and 65 ppm
on letter-size paper
M632h M632fht M632z
Copies 71 ppm on A4 and 75 ppm
on letter-size paper
M633fh M633z
10 Chapter 1 Printer overview ENWW
Model name
Product number
M631dn, M632h
K0Q14A, K0Q17A
M631h, M632fht,
M633fh
K0Q15A, K0Q18A,
K0Q21A
M631z, M632z, M633z
K0Q19A, K0Q22A
Scans at 75 images per minute
(ipm) (monochrome or color).
Scans at 120 ipm (monochrome
and color).
Easy-access USB copying and
scanning (no computer required)
150-page document feeder with
electronic duplex copying and
scanning
HP EveryPage Technologies
including ultrasonic multi-feed
detection
Not supported Not supported
Embedded optical character
recognition (OCR) provides the
ability to convert printed pages into
text that can be edited or searched
using a computer.
Not supported Not supported
SMART Label feature provides
paper-edge detection for automatic
page cropping
Not supported Not supported
Automatic page orientation for
pages that have at least 100
characters of text.
Not supported Not supported
Automatic tone adjustment sets
contrast, brightness, and
background removal for each page.
Not supported Not supported
Digital Send Send to E-mail, Save to USB, and
Save to Network Folder
Send documents to SharePoint® Not supported Not supported
Supported operating systems
The following information applies to the printer-speciƭc Windows PCL 6 and HP print drivers for OS X and to the
software installer.
Windows: The HP Software Installer installs the “HP PCL.6” version 3 print driver, the “HP PCL 6” version 3 print
driver, or the “HP PCL-6” version 4 print driver, depending on the Windows operating system, along with
optional software when using the software installer. Download the "HP PCL.6" version 3 print driver, the
"HP PCL 6" version 3 print driver, and the "HP PCL-6" version 4 print dri
