在“打印”对话框中，单击“打印”按钮打印作业。
从信封进纸器附件打印信封
1.从软件程序中选择打印选项。
2.从打印机列表中选择打印机，然后单击或点击属性或项按钮
打开打印驱动程序。
注：按钮的名称因不同软件程序而异。
要从Windows 8或8.1开始屏幕访问这些功能，请选择设备，选择打印，然后选择
打印机。
3.单击或轻触纸张/质量选项卡。
4.完成以下步骤之一：
32第2章纸盘ENWW
● 在纸张尺寸下拉列表中，选择信封的正确尺寸。
● 在“纸张类型”下拉列表中，选择“信封”。
● 在“纸张来源”下拉列表中，选择纸盘3或纸盘4-与
信封进纸器。
5.单击“确定”按钮关闭“文档属性”对话框。
6.在“打印”对话框中，单击“确定”按钮打印作业。
包络定向
托盘信封大小如何加载
托盘1信封#9，信封35; 10，信封
君主，信封B5，信封C5，
包络C6，包络DL
面朝下
顶部边缘朝向打印机前部
信封馈送器附件信封9、信封10、信封
君主，信封B5，信封C5，
包络C6，包络DL
正视
顶部边缘朝向打印机前部
ENWW加载和打印信封33
加载和打印标签
介绍
以下信息描述了如何加载和打印标签。
要在标签纸上打印，请使用托盘2或550张可选托盘之一。
注意：托盘1不支持标签。
要使用手动进纸选项打印标签，请按照以下步骤选择打印驱动程序中的正确设置，
然后在将打印作业发送到打印机之后将标签装载到托盘中。当使用手动进给时
打印机等待打印作业，直到检测到托盘已打开和关闭。
手动馈送标签
1.从软件程序中选择打印选项。
2.从打印机列表中选择打印机，然后单击或点击属性或项按钮
打开打印驱动程序。
注：按钮的名称因不同软件程序而异。
注意：要从Windows 8或8.1开始屏幕访问这些功能，请选择设备，选择打印，然后
然后选择打印机。
3.单击纸张/质量选项卡。
4.在纸张尺寸下拉列表中，为标签页选择正确的尺寸。
5.在纸张类型下拉列表中，选择标签。
6.在纸张来源下拉列表中，选择手动进纸。
注意：当使用手动进纸时，打印机将从低编号的纸盘打印
正确的纸张尺寸，因此无需指定特定的纸盘。例如，如果托盘2是
为标签配置，打印机将从纸盘2打印。如果安装了纸盘3并为标签配置了，但
托盘2未配置标签，打印机将从托盘3打印。
7.单击“确定”按钮关闭“文档属性”对话框。
8.在“打印”对话框中，单击“打印”按钮打印作业。
34第2章纸盘ENWW
标签方向
托盘：如何加载标签
托盘2-5面朝上
托盘右侧的上边缘
ENWW加载和打印标签35
配置装订邮箱附件
以下信息描述了如何加载订书钉和配置订书钉邮箱的选项
附件
装订邮箱附件可以在左上角或右上角装订文档，并且可以堆叠
到三个输出箱中的1000张纸。输出仓具有三种模式配置选项：
堆叠模式、邮箱模式或功能分隔模式。
● 配置默认缝钉位置
● 配置操作模式
配置默认缝钉位置
1.在打印机控制面板的主屏幕上，轻扫，直到显示设置菜单。触摸
设置图标打开菜单。
2.打开以下菜单：
● 复制/打印
● 默认打印选项
● 装订
3.从选项列表中选择订书钉位置，然后触摸保存按钮。以下选项是：
可用：
● 无：无订书钉
● 左上角或右上角：如果文档具有纵向方向，则订书钉位于
纸的短边。如果文档具有横向方向，则订书钉位于右上角
纸张长边的角。
● 左上角：订书钉位于纸张短边的左上角。
● 右上角：订书钉位于纸张长边的右上角。
1.
2.
1.纸张短边的左上角
2.纸张长边的右上角
36第2章纸盘ENWW
配置操作模式
使用此过程可以配置打印机如何将作业分类到输出箱中。
1.在打印机控制面板的主屏幕上，轻扫，直到显示设置菜单。触摸
设置图标打开菜单。
2.打开以下菜单：
● 管理订书机/堆垛机
● 操作模式
3.Sel
R43GEBA-TS-NS-NV-00 应用于伺服电机 Pacific Scientific

R43GEBA-TS-NS-NV-00 应用于伺服电机 Pacific Scientific
In the Print dialog box, click the Print button to print the job.
Print envelopes from the envelope feeder accessory
1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click or tap the Properties or Preferences button to
open the print driver.
NOTE: The name of the button varies for diƫerent software programs.
To access these features from a Windows 8 or 8.1 Start screen, select Devices, select Print, and then select
the printer.
3. Click or tap the Paper/Quality tab.
4. Complete one of the following steps:
32 Chapter 2 Paper trays ENWW
● In the Paper size drop-down list, select the correct size for the envelopes.
● In the Paper type drop-down list, select Envelope.
● In the Paper source drop-down list, select Tray 3 or Tray 4—whichever tray corresponds to the
envelope feeder.
5. Click the OK button to close the Document Properties dialog box.
6. In the Print dialog box, click the OK button to print the job.
Envelope orientation
Tray Envelope size How to load
Tray 1 Envelope #9, Envelope #10, Envelope
Monarch, Envelope B5, Envelope C5,
Envelope C6, Envelope DL
Face-down
Top edge toward the front of the printer
Envelope feeder accessory Envelope #9, Envelope #10, Envelope
Monarch, Envelope B5, Envelope C5,
Envelope C6, Envelope DL
Face-up
Top edge toward the front of the printer
ENWW Load and print envelopes 33
Load and print labels
Introduction
The following information describes how to load and print labels.
To print on sheets of labels, use Tray 2 or one of the optional 550-sheet trays.
NOTE: Tray 1 does not support labels.
To print labels using the manual feed option, follow these steps to select the correct settings in the print driver,
and then load the labels into the tray after sending the print job to the printer. When using manual feed, the
printer waits to print the job until it detects that the tray has been opened and closed.
Manually feed labels
1. From the software program, select the Print option.
2. Select the printer from the list of printers, and then click or tap the Properties or Preferences button to
open the print driver.
NOTE: The name of the button varies for diƫerent software programs.
NOTE: To access these features from a Windows 8 or 8.1 Start screen, select Devices, select Print, and
then select the printer.
3. Click the Paper/Quality tab.
4. In the Paper size drop-down list, select the correct size for the sheets of labels.
5. In the Paper type drop-down list, select Labels.
6. In the Paper source drop-down list, select Manual feed.
NOTE: When using manual feed, the printer prints from the lowest-numbered tray that is conƭgured for
the correct size of paper, so it is not necessary to specify a particular tray. For example, if Tray 2 is
conƭgured for labels, the printer will print from Tray 2. If Tray 3 is installed and conƭgured for labels, but
Tray 2 is not conƭgured for labels, the printer will print from Tray 3.
7. Click the OK button to close the Document Properties dialog box.
8. In the Print dialog box, click the Print button to print the job.
34 Chapter 2 Paper trays ENWW
Label orientation
Tray How to load labels
Trays 2-5 Face-up
Top edge at the right of the tray
ENWW Load and print labels 35
Conƭgure the stapling mailbox accessory
The following information describes how to load staples and conƭgure the options for the stapling mailbox
accessory.
The stapling mailbox accessory can staple documents in the upper left or upper right corners, and it can stack up
to 1,000 sheets of paper in the three output bins. The output bins have three mode-conƭguration options:
stacker mode, mailbox mode, or function separator mode.
● Conƭgure the default staple location
● Conƭgure the operation mode
Conƭgure the default staple location
1. From the Home screen on the printer control panel, swipe until the Settings menu displays. Touch the
Settings icon to open the menu.
2. Open the following menus:
● Copy/Print
● Default Print Options
● Staple
3. Select a staple location from the list of options, and then touch the Save button. The following options are
available:
● None: No staples
● Top left or right: If the document has portrait orientation, the staple is in the top left corner of the
short edge of the paper. If the document has landscape orientation, the staple is in the top right
corner of the long edge of the paper.
● Top left: The staple is in the top left corner of the short edge of the paper.
● Top right: The staple is in the top right corner of the long edge of the paper.
1
2
1 Top left corner of the short edge of the paper
2 Top right corner of the long edge of the paper
36 Chapter 2 Paper trays ENWW
Conƭgure the operation mode
Use this procedure to conƭgure how the printer sorts jobs into the output bins.
1. From the Home screen on the printer control panel, swipe until the Settings menu displays. Touch the
Settings icon to open the menu.
2. Open the following menus:
● Manage Stapler/Stacker
● Operation Mode
3. Select a mode from the list of options, and then touch the Save button. The following options are available:
● Mailbox: The printer places jobs in diƫerent bins according to the person who sent them.
● Stacker: The printer stacks jobs in the bins from bottom to top.
● Function Separator: The printer places jobs in diƫerent bins according to printer function such as print
jobs, copy jobs, or fax jobs.
To conƭgure the HP print driver for the selected operation mode, complete the following steps:
NOTE: Changing the operation mode causes the printer to restart.
Windows XP and Vista (Server 2003/2008) HP PCL.6 drivers do not support output devices.
Windows®
 7
1. Make sure the printer is turned on and connected tot he computer or a network.
2. Open the Windows®
 Start menu, and then click Devices and Printers.
3. Right-click the name of the printer, and then select Printer Properties.
4. Click the Device Settings tab.
5. Select Update Now. Or, in the drop-down menu next to Automatic Conƭguration, select Update Now.
Windows®
 8.0, 8.1, and 10
1. Right-click on the bottom-left corner of the screen.
2. Select Control Panel. Under Hardware and Sound, select View devices and printers.
3. Right-click the name of the printer, and then select Printer Properties.
4. Click the Device Settings tab.
5. Select Update Now. Or, in the drop-down menu next to Automatic Conƭguration, select Update Now.
NOTE: Newer V4 drivers do not support Up
