关于本手册
本手册描述了称重传感器PFTL 101A、PFTL 100AE、PFTL101AER、PFTL101 B、PFTL
101BE和PFTL 101BER在Pressductor®张力测量系统中。
本手册旨在描述称重传感器的一般功能和设计，以及
为安装、调试、预防性维护和故障跟踪提供指导。
1.2网络安全免责声明
本产品设计用于通过
应连接到安络的网络接口。这是以下人员的责任：
负责网络管理的人员或实体，以确保与
并采取必要措施（例如但不限于安装firew@KKs
应用身份验证措施、数据加密、安装防病毒程序等）
保护产品和网络，包括其系统和接口，防止任何类型的
安全漏洞、未经授权的访问、干扰、入侵、泄露和/或数据盗窃，或
信息ABB不对任何此类损害和/或损失负责。
1.3处置和回收
1.3.1环境政策
ABB致力于其环境政策。通过应用可回收性和生命周期分析的结果，我们不断努力使我们的产品更加环保。产品、制造过程和物流的设计考虑了环境因素。
我们的环境管理体系通过ISO 14001认证，是执行我们
环境政策。但是，客户有责任确保当地法律：
跟着。
压力导管枕式称重传感器，水平测量PFTL 101，用户手册
1导言
3BSE009965R0401 en第5版
1.3.2回收电气和电子设备，WEEE
产品和/或随附文件上的划线轮式垃圾箱符号
指使用过的电气和电子设备（WEEE）不应与一般设备混合
家庭垃圾。
如果您希望在欧盟丢弃电气和电子设备（EEE），请
有关更多信息，请联系您的经销商或供应商。
在欧盟以外的地区，请联系当地当局或经销商，询问正确的信息
处置方法。
正确处置本产品将有助于节约宝贵资源，并防止对人类健康和环境产生任何潜在的负面影响，而这些负面影响可能是由不当使用引起的
废物处理。
1.3.3运输材料的回收
ABB将所有运输材料设计为可回收的。运输工具的回收
材料取决于材料类型和当地回收计划的可用性。
接收系统进入现场后，包装和运输锁定必须
远离的。根据当地法规回收运输材料。
1.3.4产品的处置
在处置产品时，应将其拆除并回收组件
根据当地法规。
1.3.4.1产品的拆卸和回收
根据当地法规拆卸和回收产品的部件。
注意安全
有些部件很重！执行拆卸的人员
系统必须具备必要的知识和技能来处理重型设备
避免发生事故和伤害风险的部件。
•称重传感器：这些部件由结构钢制成，可根据
本地说明。所有辅助
