Route Two/Heating – Air enters into the heating duct (D). Here the air will pass over a set of heating coils that
heat the passing air. Next it passes over the humidifier. If the relative humidity of the passing air is too low the
humidifier will add moisture to the air and will continue moving through the ductwork towards the mixing box (F).
At the Mixing Box – The mixing box is the location in the ductwork where the heating and cooling ducts
combine. Here the heated air is mixed with cooled air to achieve the desired temperature for the space. The
mixing of air is controlled by a sensor that adjusts dampers on the entering heating or cooling air, opening or
closing them, to ensure that the right mix of air is used to create the desired supply temperature.
After the mixing box, the mixed air continues down the ductwork. The air passes through the diffuser (G) and
enters the space. Eventually the air is drawn back into the return ductwork and pushed through the return fan (I).
From here it will either be exhausted or returned to the start of the system to begin the process again.
Refrigerant/Heating Supply:
The cooling coils are fed from a source of cooling such as chillers, a cooling tower, or DX unit. The refrigerant
enters the cooling coils, absorbs heat from the passing air, and returns to its source to desorb the heat that it took
in.
The heating coils are fed from a heat source such as boiler or electricity. The heat from these coils is transferred to
the air passing over it.
System Variations:
1. An outside air duct can be found either before the cooling coil or before the filters on the air handling unit,
depending on the design.
2. A system may have multiple sets of filters to remove different levels of impurities.
3. If the outside air duct is before the cooling coil the filters may be located before the outside air damper or
cooling coil to treat the new air coming into the system.
4. A system may utilize a bypass setup where the air can be diverted past the coil(s) if it does not need to be
treated.
5. Humidification tubes may not be present in every unit. A humidification coil may also be present after the
cooling coil.
6. A return fan may not be present on every unit if the supply fan creates enough of a draw to pull the air
back through the space.
14
IPI’s Methodology for Implementing Sustainable Energy-Saving Strategies in Collections Environments (2017)
Variable Air Volume (VAV) System
Components/Layout:
Heating Coils
Air Flow Sensor
Dampers
Actuator
Controller
Contactors
Thermostat
Air Flow:
VAV stands for variable air volume, and VAV boxes may be a part of an air handling system. They are located in
ductwork before the air reaches a designated space. Primary air from the air handling unit is pushed downstream
to a VAV box. Just before the VAV box there are a set of dampers (C). These dampers are controlled by an air
flow sensor (B) or a space thermostat (G) that will command the actuator (D) to open or close to adjust the
volume of air that is pushed across the heating coils (optional). When air enters a VAV the heating coils inside
will heat the air if necessary. As the air is heated it is pushed out of the VAV box and delivered to the space as
secondary air. If no heating is required the contactor will not activate the heating coils and the air passes on with
no heating.
System Variations:
1. A heating coil may not be present in every unit.
2. A fan may be located inside the VAV to increase air velocity when air volume is low.
3. In some cases a humidifier may be present.
Direct Expansion (DX) Individual Air Conditioning System
Components/Layout:
Condenser Coil
Fans
Compressor
Expansion Valve
Evaporator Coil
Thermostat
