Air Flow:
Air is drawn into the unit through the filter by the blower fan, at point E. The fan pushes air past the heat
exchanger (C) which warms the air as it passes through. The resulting warmer air is sent through the supply duct
(B) to the space. As the warm air is supplied to the space, the cooler air is pushed down and is drawn into the
return and is reused by the system. A unit will typically operate until the space temperature is satisfied, at which
time the furnace turns off. These units require a free flow of air to operate and for proper air flow should have
open return air ducts and an unobstructed air path to help draw in air when operating.
System Variations:
1. A system may utilize one of a number of means to heat the air (gas burner, electric coils, heat pump, or
hydronic coils).
2. The return for a unit may be actual ductwork or may be return grates cut into the floors and walls to
create circulation.
3. Humidification unit may be present after the heating coil depending on the design.
Forced Air Cooling
Components/Layout:
Exhaust Fan
Compressor
Condenser Coil
Expansion Valve
Evaporator Coil
Heating Coil
Blower Fan
Filter
Supply Duct
Vent
Outside Air Intake
Air Flow:
This unit utilizes the air circulation methods of a forced air furnace; however it is being used for cooling as well as
heating. Air is drawn into the unit through the filter, (H), and is pulled through the blower (G). The blower pushes
air past the heating coil or heat exchanger (F), but this coil will not operate when cooling. The air continues past
to the evaporator coil or cooling coil (E), which cools the air as it passes through. The resulting air is sent through
the supply duct (I) to the space. The systems main goal is to sensibly cool the passing air. Any dehumidification
that may happen will be a byproduct of the process. The cooler air that exits the system may have lost some
moisture in the cooling process but will have a higher relative humidity. The unit will typically operate until space
temperature is satisfied at which time the unit turns off. These units require a free flow of air to operate and must
have open return air ducts or an unobstructed air path to IPI’s Methodology for Implementing Sustainable Energy-Saving Strategies in Collections Environments (2017)
Refrigerant/Heating Supply:
The system works like a basic air conditioner with a few changes in positioning. The expansion valve (D),
compressor (B) and condenser (C) are located outside of the building, while the evaporator coil (E) is inside the
furnace. The refrigerant must travel through long lengths of tubing from inside to outside
Beginning just after the expansion valve refrigerant starts off as a low temperature, low pressure liquid. Under this
low pressure condition the refrigerant has a low boiling point. The refrigerant is pushed through the evaporator
coil where it absorbs heat from warm air that is passing over the coils. The heat absorbed from the warm air
causes the refrigerant to boil and become a vapor. The refrigerant continues through the system toward the
compressor. As it enters the compressor the refrigerant is now a low temperature, low pressure vapor.
The refrigerant enters the compressor where it is pressurized into a high temperature, high pressure vapor.
The refrigerant is now under very high pressure and has a high boiling point. At these conditions, the refrigerant
can condense easily. As the refrigerant moves through the condenser coil the fan inside the unit pushes air
across the coils. The refrigerant will expel heat to the passing air as it is pushed though the fins by the fan. The
passing air absorbs the heat, causing the refrigerant to cool and condense into a liquid. The high-pressure liquid
moves towards the outlet of the condenser, the expansion valve. The refrigerant will enter the valve as a high
temperature, high pressure liquid. The valve allows the pressure of the refrigerant to change and the refrigerant
will exit the valve as a low temperature, low pressure liquid and start the process over again.
System Variations:
1. A return for the unit may be actual ductwork or may be return grates cut into the floors and walls to
create circulation.
Desiccant Wheel
