并在其通过时被加热线圈（a）显著加热。这种加热空气具有更大的能力：
保持水分，并以与工艺空气相反的方向穿过干燥剂。当空气穿过
干燥剂它从车轮上吸收水分并干燥干燥剂。然后将再生空气吸入
风扇（C），并作为热/湿空气排出建筑物。车轮继续转动，重新激活
干燥剂准备再次处理空间。
系统变化：
1.干燥剂轮上的管道布置可能因装置而异。
2.干燥剂轮可在空气进入空气处理器之前对空气进行预处理，或调节正在通过的空气
空气处理器，取决于设计。
3.干燥剂单元不需要连接到空气处理器，它可以是独立的。
蒸发冷却系统
组件/布局：
阻尼器
过滤器
加热线圈
蒸发介质
送风机
回风机
空气流量：
这种类型的装置在亚利桑那州和内华达州等地区很常见，在这些地区，空气中的水分去除不是
以及从该系统添加到空气中的水分有助于提高低露点。启动
在外部空气入口，空气进入外部空气管道，并与来自空间的返回空气混合
过滤器（B）。混合后的空气通过一组过滤器排出杂质。然后空气就过去了
一组加热线圈（C），必要时将空气加热至所需温度。然后空气通过
通过蒸发介质（D）。该介质是一种采用蜂窝状设计的垫，充满了冷空气
IPI在环境中实施可持续节能战略的方法（2017年）
水当空气通过介质时，来自垫的水蒸发到空气中。此过程删除
来自空气的能量导致较低/较冷的温度，同时将水分添加到
通过空气，增加露点。接下来，空气被吸入送风机（E），送风机将推动空气通过
供应管道系统，通过扩散器进入空间。然后，回风机（F）将从
空间并将其推过回流管道系统。空气被排出或返回至待混合的装置
室外空气，重新开始循环。
制冷剂/冷却剂循环：
加热线圈由热源（例如锅炉或电力）供给。来自这些线圈的热量被传递
对经过它的空气。
蒸发介质是利用蜂窝设计的纤维素材料制成的垫。供应系统
通过向介质表面浇水或滴水来添加水。这些水沿着介质和
没有被吸收或蒸发到空气中的物质将收集在一个特殊的池中。水池里的水被泵回
直到介质顶部并重复使用。游泳池设计有一个浮子，以防止溢流和供水
如果游泳池水位过低，管线将替换任何损失的水。
系统变化：
1.系统可以具有多组过滤器以去除不同水平的杂质。
2.加热线圈可能不存在于每个单元中。
3.加热盘管可能位于管道系统中较远的管线下方，称为再热。作为线圈的再加热
将在空气从管道排出之前将空气加热特定空间。
4.每个装置中可能不存在回风机。如果送风机产生足够的吸力，它会吸走空气
穿过太空。
