空气通过过滤器（A）进入装置。空气进入大型蒸发器盘管（B），在这里被冷却
并且线圈的温度非常低。如果通过的空气的露点高于盘管温度，
空气中的水分将冷凝并落到冷凝盘上。冷凝盘将允许水进入
以排出装置。冷空气被带到装置的后部，然后被向下推动，从那里通过
通过冷凝器盘管（E），用于在将空气从装置后部排出之前加热空气。
制冷剂/冷却剂循环：
该系统的工作原理就像一个基本的空调。就在膨胀阀（F）之后，制冷剂开始工作
作为低温低压液体。在此低压条件下，制冷剂具有低沸点
指向制冷剂被推动通过蒸发器盘管（C），在那里从热空气中吸收热量，即
通过线圈。热空气吸收的热量使制冷剂沸腾并变成蒸汽。这个
制冷剂继续通过系统流向压缩机（G）。当制冷剂进入压缩机时
答：
B：
C：
D：
E：
F：
G：
H：
IPI在环境中实施可持续节能战略的方法（2017年）
27
现在是低温低压蒸汽。
制冷剂进入压缩机，在那里被加压成高温高压蒸汽。这个
制冷剂现在处于非常高的压力下并且具有高沸点。在这些条件下，制冷剂可以
容易浓缩。当制冷剂通过冷凝器盘管（E）时，装置内的风扇推动空气
穿过线圈。当风扇推动空气通过散热片时，制冷剂将热量排出到通过的空气中。这个
通过的空气将吸收热量，使制冷剂冷却并冷凝成液体。高压
液体流向冷凝器的出口，即膨胀阀。制冷剂将进入阀门
高温高压液体。该阀将允许制冷剂的压力变化
制冷剂将作为低温低压液体离开阀门，并重新开始该过程。
系统变化：
1.该系统可以采用多种形状和尺寸。
空调
ACH–每小时换气次数
ACU–空调机组
AHU–空气处理装置
ASHRAE——美国采暖制冷学会
和空调工程师
BAS——建筑自动化系统
BMS——建筑管理系统
英国热量单位
BTUh——英国热单位/小时
C–摄氏度
CAV–恒定风量
CC–冷却盘管
氟氯化碳
CFM–立方英尺/分钟
CHW–冷冻水
CHWP–冷冻水泵
CHWR–冷冻水回流
CHWS–冷冻水供应
DB——干球
直接数字控制
DP–露点
DX–直接扩展
EA–排气
EAT–进入空气温度
EER——能效比
EF——排气扇
EMS–能源管理系统
EWT——进水温度
F–华氏温度
FCU–风机盘管机组
FLA–满载放大器
FPM–英尺/分钟
FPS–英尺/秒
机械系统缩略语
28
IPI在环境中实施可持续节能战略的方法（2017年）
GPM–加仑/分钟
HC——加热盘管
高效微粒捕集器
HP–热泵或马力
HPS–高压蒸汽
HW——热水
HWP–热水泵
HWR——热水回流
HWS–热水供应
暖通空调——供暖、通风和空调
Hz–赫兹
红外-红外
kW–千瓦
KWH–千瓦时
LAT–离开空气温度
LEED–能源和环境领导力
设计
LL–下限
低压-低压
LPS——低压蒸汽
LWT——出水温度
LWB–离开湿球
MA–混合空气
MAT–混合空气温度
MUA–补充空气
常闭
否–常开
OA、OSA——室外空气
OAI–外部进气
OAT–外部空气温度
PM–预防性维护
PH–预热
PSI–磅/平方英寸
RA–回风
RF–回风机
相对湿度——相对湿度
RPM–每分钟转数
RTU–屋顶单元
SA–供气
SD–烟雾探测器
SF–送风机
T——温度或恒温器
V–伏特
VAV–可变风量
VD–音量调节器
VFD–变频驱动
SAFT188IOC 58125067-CA SAFT 188IOC 扩展模块 ABB
SAFT188IOC 58125067-CA SAFT 188IOC 扩展模块 ABB
Air is brought into the unit through the filter (A). The air enters a large evaporator coil (B), here it is cooled
and the temperature of the coil is very low. If the passing air has a higher dew point than the coil temperature,
moisture in the air will condense and drop onto a condensation tray. The condensation tray will allow the water
to drain out of the unit. The cool air is brought to the back of the unit then pushed downward where it will pass
through a condenser coil (E) that is used to heat the air before ejecting it out the rear of the unit.
Refrigerant/Coolant Cycle:
The system works just like a basic air conditioner. Beginning just after the expansion valve (F) the refrigerant starts
off as a low temperature, low pressure liquid. Under this low pressure condition the refrigerant has a low boiling
point. The refrigerant is pushed through the evaporator coil (C) where it absorbs heat from the warm air that is
passing over the coils. The heat absorbed by the warm air causes the refrigerant to boil and become a vapor. The
refrigerant continues through the system toward the compressor (G). As it enters the compressor the refrigerant
A:
B:
C:
D:
E:
F:
G:
H:
IPI’s Methodology for Implementing Sustainable Energy-Saving Strategies in Collections Environments (2017)
27
is now a low temperature, low pressure vapor.
The refrigerant enters the compressor where it is pressurized into a high temperature, high pressure vapor. The
refrigerant is now under very high pressure and has a high boiling point. At these conditions, the refrigerant can
condense easily. As the refrigerant moves through the condenser coil (E) the fan inside the unit is pushing air
across the coils. The refrigerant will expel heat to the passing air as it is pushed though the fins by the fan. The
passing air will absorb the heat, causing the refrigerant to cool and condense into a liquid. The high-pressure
liquid moves towards the outlet of the condenser, the expansion valve. The refrigerant will enter the valve as
a high temperature, high pressure liquid. The valve will allow the pressure of the refrigerant to change and the
refrigerant will exit the valve as a low temperature, low pressure liquid and start the process over again.
System Variations:
1. This system can take a variety of shapes and sizes.
AC – Air Conditioning
ACH – Air Changes per Hour
ACU – Air Conditioning Unit
AHU – Air Handling Unit
ASHRAE – American Society of Heating Refrigeration
and Air Conditioning Engineers
BAS – Building Automated System
BMS – Building Management System
BTU – British Thermal Unit
BTUh – British Thermal Unit per hour
C – Celsius
CAV – Constant Air Volume
CC – Cooling Coil
CFC - Chlorofluorocarbon
CFM – Cubic Feet per Minute
CHW – Chilled Water
CHWP – Chilled Water Pump
CHWR – Chilled Water Return
CHWS – Chilled Water Supply
DB – Dry Bulb
DDC – Direct Digital Control
DP – Dew Point
DX – Direct Expansion
EA – Exhaust Air
EAT – Entering Air Temperature
EER – Energy Efficiency Ratio
EF – Exhaust Fan
EMS – Energy Management System
EWT – Entering Water Temperature
F – Fahrenheit
FCU – Fan Coil Unit
FLA – Full Load Amps
FPM – Feet per Minute
FPS – Feet per Second
Mechanical System Acronyms
28
IPI’s Methodology for Implementing Sustainable Energy-Saving Strategies in Collections Environments (2017)
GPM – Gallon per Minute
HC – Heating Coil
HEPA – High-Efficiency Particulate Arrestor
HP – Heat Pump or Horse Power
HPS – High Pressure Steam
HW – Hot Water
HWP – Hot Water Pump
HWR – Hot Water Return
HWS – Hot Water Supply
HVAC – Heating, Ventilation and Air Conditioning
Hz – Hertz
IR – Infrared
kW – Kilowatt
KWH – Kilowatt-hour
LAT – Leaving Air Temperature
LEED – Leadership in Energy and Environmental
Design
LL – Low Limit
LP – Low Pressure
LPS – Low Pressure Steam
LWT – Leaving Water Temperature
LWB – Leaving Wet Bulb
MA – Mixed Air
MAT – Mixed Air Temperature
MUA – Make Up Air
NC – Normally Closed
NO – Normally Open
OA, OSA – Outside Air
OAI – Outside Air Intake
OAT – Outside Air Temp
PM – Preventative Maintenance
PH – Preheat
PSI – Pounds per Square Inch
RA – Return Air
RF – Return Fan
RH – Relative Humidity
RPM – Revolutions per Minute
RTU – Roof Top Unit
SA – Supply Air
SD – Smoke Detector
SF – Supply Fan
T – Temperature or Thermostat
V – Volts
VAV – Variable Air Volume
VD – Volume Damper
VFD – Variable Frequency Drive
