至12个称重传感器
（1至4个称重传感器+AI1+AI2）
0.001 12 Fnom 0.001 12 Fnom
•差信号0.001 Fnom 0.001 12 Fnom
张力电子PFEA113，用户手册
3.13.5节通过Profibus处理测量数据
3BSE029382R0101版本C 3-45
用户定义的缩放
Profibus测量范围和负载分配可根据用户进行调整
偏好。
Profibus测量范围
Profibus测量范围（正常运行期间估计的卷筒纸张力）是一个参数
由用户输入。用户更改测量范围值后，更改称重传感器
标称负载不影响Profibus缩放。定义了低有效位的值
作为负载划分。
负荷分配
负荷分配是Profibus上使用的分辨率。负荷分配值为：
由PFEA113计算并取决于设定的测量范围。
测量范围在2001-5000范围内分为有限的几个部分。
负载划分值=一个划分，仅包含一个有效数字（1、2或5）。
Profibus多可处理–32768到+32767（216）个分区。
例1：
a、 Profibus测量范围（用户设置）=15 500 N
（正常运行期间的预计腹板张力）
b、 PFEA113计算的负荷分配=5 N
（Profibus上低有效位的值）
c、 Profibus测量范围/负载分配=15500/5=3100
（测量范围分为3100个分区）
例2：
如果示例1中的负载分配5N不够，则可以调整负载分配。
这可以通过将杂项菜单中的测量范围设置（减小）为
提供足够的负荷分配（分辨率）的值。
a、 测量范围=9000 N
（新的较低测量范围设置）
b、 PFEA113计算的新负荷分配=2 N
（Profibus上低有效位的新值）
在PFEA113中设置9000 N时，Profibus测量范围0–15500 N（分为
7750个分区）仍然可以使用。
通常情况下，无需将测量范围设置为低于估计幅材的1/3
正常操作期间的张力。
对于给定的负荷分配，可通过Profibus传输的大值为：
–大值=荷载分区x 32767
张力电子PFEA113，用户手册
三章调试
3-46 3 BSE029382R0101版本C
注
用户更改测量范围值后，一的方法是
返回默认缩放，即使用
杂项菜单。
3.13.5.3 Profibus测量值的过滤
测量值1-6具有与AO1-AO6相同的滤波。
3.13.5.4从PFEA113到PLC的输入缓冲器、通信块
本节指定输入缓冲区中的测量值和布尔值
通信阻塞。
数据
值1:AO1（16位2补码）
值2:AO2（16位2补码）
值3:AO3（16位2补码）
值4:AO4（16位2补码）
值5:AO5（16位2补码）
值6:AO6（16位2补码）
布尔输入（未使用的位设置为零）
13字节：
当相应位设置为“1”时，错误或警告激活。
数据字节号。
一点也不。
76543210
值1
01 MSB
02 LSB
价值2
03 MSB
04 LSB
价值3
05 MSB
06 LSB
价值4
07 MSB
08 LSB
价值5
09 MSB
10 LSB
价值6
11 MSB
12 LSB
13、7、6、5、4、3、2、1、0中的布尔值
14、7、6、5、4、3、2、1、0中的布尔值
张力电子PFEA113，用户手册
3.13.5节通过Profibus处理测量数据
3BSE029382R0101版本C 3-47
0位：闪存错误
1位：EEPROM存储器错误
2位：电源错误
3位：称重传感器励磁错误
4位：同步问题
14字节
0位：电平检测器1激活
1位：电平检测器2激活
2位：液位检测器3激活
3位：电平检测器4激活
3.13.5.5输出缓冲器，从PLC到PFEA113的通信块
本节指定输出缓冲区通信块中的布尔值。
0位：零集。当位从“0”变为“1”时，执行零设置。
–1卷的零组，或
–如果选择分段滚动，则所有称重传感器的零集。
1位：零集。当位从“0”变为“1”时，执行零设置。
–2卷的零组
2位：增益调度。
–如果位设置为“0”，则使用回绕增益参数1
–如果位设置为“1”，则使用回绕增益参数2
数据字节号。
一点也不。
76543210
布尔输出017、6、5、4、3、2、1、0
02备用
张力电子PFEA113，用户手册
三章调试
3-48 3 BSE029382R0101版本C
3.14可选装置的调试
3.14.1绝缘放大器PXUB 201
绝缘放大器连接到张力电子装置电压输出。
S1通常设置为电压1:1比。
选择输出以通过开关S1和S2产生电压或电流输出。
通过开关S2、po选择较慢的响应
WONDERWARE 显示屏 OICB-15B-7HMXU IP15IA99-A1 -AN0201
WONDERWARE 显示屏 OICB-15B-7HMXU IP15IA99-A1 -AN0201
to 12 load cells
(1 to 4 load cells + AI1 + AI2)
0.001 12 Fnom 0.001 12 Fnom
• Difference signal 0.001 Fnom 0.001 12 Fnom
Tension Electronics PFEA113, User Manual
Section 3.13.5 Handling of Measurement Data through Profibus
3BSE029382R0101 Rev C 3-45
User Defined Scaling
The Profibus Measuring Range and Load Division can be adjusted according to user
preferences.
Profibus Measuring Range
Profibus Measuring Range (estimated web tension during normal operation) is a parameter
entered by the user. After the user has changed the Measuring Range value, changing Load cell
nominal load does not affect the Profibus scaling. The value of the least significant bit is defined
as Load Division.
Load Division
Load Division is the resolution that will be used on Profibus. The Load Division value is
calculated by PFEA113 and depends on the set measuring range.
The measuring range is divided into a limited number of divisions in the range 2001 - 5000.
The Load Division value = one division, contains only one significant digit (1, 2 or 5).
The Profibus can handle max. –32768 to +32767 (216) divisions.
Example 1:
a. Profibus Measuring Range (set by user) = 15 500 N
(estimated web tension during normal operation)
b. Load Division calculated by PFEA113 = 5 N
(value of least significant bit on Profibus)
c. Profibus Measuring Range/Load Division = 15500/5 = 3100
(the measuring range is divided into 3100 divisions)
Example 2:
If the Load Division, 5 N, in Example 1 is not sufficient, the Load Division can be adjusted.
This can be done by setting (decreasing) MeasuringRange in the Miscellaneous Menu to a
value that gives a sufficient Load Division (resolution).
a. Measuring Range = 9000 N
(New, lower measuring rangesetting)
b. New Load Division calculated by PFEA113 = 2 N
(New value of least significant bit on Profibus)
With the setting 9000 N in PFEA113 , the Profibus measuring range 0 – 15500 N (divided into
7750 divisions) can still be used, now with the Load Division (resolution) 2 N.
Normally, there is no need to set the measuring range lower than 1/3 of the estimated web
tension during normal operation.
The max. value that can be transmitted via Profibus, for a given Load Division, is:
– Max. value = Load Division x 32767
Tension Electronics PFEA113, User Manual
Chapter 3 Commissioning
3-46 3BSE029382R0101 Rev C
NOTE
After the user has changed the Measuring Range value, the only way to
return to Default scaling, is to use the function Set Factory default in the
Miscellaneous Menu.
3.13.5.3 Filtering of Profibus Measuring Values
Measuring values 1-6 have the same filtering as AO1-AO6.
3.13.5.4 Input Buffer, Communication Block from PFEA113 to PLC
This section specifies measurement values and Boolean values in the input buffer
communication block.
Data
Value 1: AO1 (16 bit 2-complement)
Value 2: AO2 (16 bit 2-complement)
Value 3: AO3 (16 bit 2-complement)
Value 4: AO4 (16 bit 2-complement)
Value 5: AO5 (16 bit 2-complement)
Value 6: AO6 (16 bit 2-complement)
Boolean in (not used bits are set to zero)
Byte No. 13:
The error or warning is active when the corresponding bit is set to “1”.
Data Byte No.
Bit No.
76543210
Value 1
01 MSB
02 LSB
Value 2
03 MSB
04 LSB
Value 3
05 MSB
06 LSB
Value 4
07 MSB
08 LSB
Value 5
09 MSB
10 LSB
Value 6
11 MSB
12 LSB
Boolean in 13 No. 7 No. 6 No. 5 No. 4 No. 3 No. 2 No. 1 No. 0
Boolean in 14 No. 7 No. 6 No. 5 No. 4 No. 3 No. 2 No. 1 No. 0
Tension Electronics PFEA113, User Manual
Section 3.13.5 Handling of Measurement Data through Profibus
3BSE029382R0101 Rev C 3-47
Bit No. 0: Flash memory error
Bit No. 1: EEPROM memory error
Bit No. 2: Supply error
Bit No. 3: Load cell excitation error
Bit No. 4: Synchronization problem
Byte No. 14
Bit No. 0: Level detector 1 is active
Bit No. 1: Level detector 2 is active
Bit No. 2: Level detector 3 is active
Bit No. 3: Level detector 4 is active
3.13.5.5 Output Buffer, Communication Block from PLC to PFEA113
This section specifies Boolean values in the output buffer communication block.
Bit No. 0: Zero Set. Zero set is performed when the bit is changed from “0” to “1”.
– Zero set of Roll 1 or
– Zero set of all load cells if Segmented roll is selected.
Bit No. 1: Zero Set. Zero set is performed when the bit is changed from “0” to “1”.
– Zero set of Roll 2
Bit No. 2: Gain Scheduling.
– Wrap gain parameter 1 is used if the bit is set to “0”
– Wrap gain parameter 2 is used if the bit is set to “1”
Data Byte No.
Bit No.
76543210
Boolean out 01 No. 7 No. 6 No. 5 No. 4 No. 3 No. 2 No. 1 No. 0
02 Spare for future use
Tension Electronics PFEA113, User Manual
Chapter 3 Commissioning
3-48 3BSE029382R0101 Rev C
3.14 Commissioning of Optional Units
3.14.1 Insulation Amplifier PXUB 201
The insulation amplifier is connected to the tension electronics voltage output.
S1 is normally set for voltage 1:1 ratio.
The output is selected to generate a voltage or current output by means of switch S1 and S2.
Slower response is selected by means of switch S2, position 3.
The switches are located inside the unit.
Figure 3-27. Insulation Amplifier PXUB 201
You must open the insulation amplifier to be able to set the switches S1 and S2.
1. Demount the insulation amplifier from the DIN rail.
Use a screw driver to unload the spring at the bottom of the insulation amplifier.
2. Press down the snap-locks on both sides of the insulation amplifier.
3. Pull the top lid open, until you see both the switches S1 and S2.
S2
1 2 3
ON
S
