PLC电路板 DSDI110AV1 3BSE018295R1三相无方向过电流
保护，级，实例2 PHHPTOC2 3I>>（2）51P-2（2）
三相无方向过电流
保护，瞬时级，实例1 PHIPTOC1 3I>>>（1）50P/51P（1）
无方向接地故障保护，低
在这个阶段，实例1 EFLPTOC1 Io>（1）51N-1（1）
无方向接地故障保护，低
在这个阶段，实例2 EFLPTOC2 Io>（2）51N-1（2）
非定向接地故障保护，
在这个阶段，实例1 EFHPTOC1 Io>>（1）51N-2（1）
无方向接地故障保护，
瞬时级EFIPTOC1 Io>>>50N/51N
负序过电流保护，
实例1 NSPTOC1 I2>（1）46（1）
负序过电流保护，
实例2 NSPTOC2 I2>（2）46（2）
相位不连续保护PDNSPTOC1 I2/I1＞46PD
下一页续表
1MRS756378 K第3节
REF615标准配置
参考文献615:67
应用手册
功能IEC 61850 IEC 60617 IEC-ANSI
馈线的三相热保护，
电缆和配电变压器T1PTTR1 3th>F 49F
断路器故障保护CCBRBRF1 3I>/Io>BF 51BF/51NBF
三相涌流检测器INRPHAR1 3I2f>68
主跳闸，实例1 TRPPTRC1主跳闸（1）94/86（1）
主跳闸，实例2 TRPPTRC2主跳闸（2）94/86（2）
电弧保护，实例1电弧电弧1电弧（1）50L/50NL（1）
电弧保护，实例2电弧2电弧（2）50L/50NL（2）
电弧保护，例如3弧电弧3弧（3）50L/50NL（3）
控制
断路器控制CBXCBR1 I<->O断路器I<->O断路器
自动重合闸DARREC1 O->I 79
状态监测
跳闸电路监控，例如1 TCSCBR1 TCS（1）TCM（1）
跳闸电路监控，实例2 TCSCBR2 TCS（2）TCM（2）
测量
干扰记录器RDRE1--
三相电流测量，例如1 CMMXU1 3I 3I
顺序电流测量CSMSQI1 I1、I2、I0 I1、I2、I2
剩余电流测量，实例1 RESCMMSU1 Io In
3.6.2.1默认I/O连接
表22：二进制输入的默认连接
二进制输入默认使用连接器引脚
X120-BI1阻断过电流瞬时级X120-1,2
X120-BI2断路器闭合指示X120-3,2
X120-BI3断路器断开指示X120-4,2
X120-BI4主跳闸闭锁复位X120-5,6
表23：二进制输出的默认连接
二进制输出默认使用连接器引脚
X100-PO1闭合断路器X100-6,7
X100-PO2断路器故障保护跳闸至上游
断路器
X100-8,9
X100-PO3断路器/跳闸线圈1 X100-15,16,17,18,1
9
X100-PO4断路器/跳闸线圈2 X100-20,21,22,23,2
4.
X100-SO1一般启动指示X100-10,11,12
X100-SO2一般操作指示X100-13,14,15
第3节1MRS756378 K
REF615标准配置
68参考文献615
应用手册
表24：LED的默认连接
LED默认使用
1.无方向过电流运行
2.非定向接地故障运行
3.敏感接地故障操作
4负序列。过电流/相位不连续运行
5热过载报警
6断路器故障操作
7干扰记录器触发
8未连接
9跳闸电路监控报警
10.电弧保护操作
11自动重合闸正在进行
3.6.2.2默认干扰记录器设置
表25：默认模拟信道选择和文本设置
频道选择和文本
此外，默认连接的所有数字输入也将启用
设置。默认触发设置取决于
连接输入信号类型。通常，选择所有保护启动信号以：
触发默认记录的干扰。
1MRS756378 K第3节
REF615标准配置
参考文献615:69
应用手册
3.6.3功能图
功能图描述了默认输入、输出、报警LED和功能到功能连接。可以使用查看和更改默认连接
如有必要，根据应用要求提供PCM600。
模拟通道具有指向不同功能块的固定连接
在IED的标准配置中。这条规则的例外是12
用于干扰记录器功能的模拟通道。这些渠道是：
可自由选择，是干扰记录器参数设置的一部分。
模拟信道分配给不同的功能。公共信号
用3I表示三相电流。标有Io的信号
表示通过相位求和连接测得的剩余电流
电流互感器。
3.6.3.1保护功能图
功能图详细描述了IED的保护功能，以及
想象工厂设置的默认连接。
第3节1MRS756378 K
REF615标准配置
70参考文献615
应用手册
A071348 V3 EN
图30：过电流保护
提供四个过电流级，用于过电流和短路保护。
瞬时级（PHIPTOC1）可以通过给二进制通电来阻止
输入1（X120:1-2）。两个负序过电流级（NSPTO
PLC电路板 DSDI110AV1 3BSE018295R1
 PLC电路板 DSDI110AV1 3BSE018295R1
Three-phase non-directional overcurrent
protection, high stage, instance 2 PHHPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional overcurrent
protection, instantaneous stage, instance 1 PHIPTOC1 3I>>> (1) 50P/51P (1)
Non-directional earth-fault protection, low
stage, instance 1 EFLPTOC1 Io> (1) 51N-1 (1)
Non-directional earth-fault protection, low
stage, instance 2 EFLPTOC2 Io> (2) 51N-1 (2)
Non-directional earth-fault protection, high
stage, instance 1 EFHPTOC1 Io>> (1) 51N-2 (1)
Non-directional earth-fault protection,
instantaneous stage EFIPTOC1 Io>>> 50N/51N
Negative-sequence overcurrent protection,
instance 1 NSPTOC1 I2> (1) 46 (1)
Negative-sequence overcurrent protection,
instance 2 NSPTOC2 I2> (2) 46 (2)
Phase discontinuity protection PDNSPTOC1 I2/I1> 46PD
Table continues on next page
1MRS756378 K Section 3
REF615 standard configurations
REF615 67
Application Manual
Function IEC 61850 IEC 60617 IEC-ANSI
Three-phase thermal protection for feeders,
cables and distribution transformers T1PTTR1 3Ith>F 49F
Circuit breaker failure protection CCBRBRF1 3I>/Io>BF 51BF/51NBF
Three-phase inrush detector INRPHAR1 3I2f> 68
Master trip, instance 1 TRPPTRC1 Master Trip (1) 94/86 (1)
Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)
Arc protection, instance 1 ARCSARC1 ARC (1) 50L/50NL (1)
Arc protection, instance 2 ARCSARC2 ARC (2) 50L/50NL (2)
Arc protection, instance 3 ARCSARC3 ARC (3) 50L/50NL (3)
Control
Circuit-breaker control CBXCBR1 I <-> O CB I <-> O CB
Auto-reclosing DARREC1 O -> I 79
Condition monitoring
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement, instance 1 CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Residual current measurement, instance 1 RESCMMXU1 Io In
3.6.2.1 Default I/O connections
Table 22: Default connections for binary inputs
Binary input Default usage Connector pins
X120-BI1 Blocking of overcurrent instantaneous stage X120-1,2
X120-BI2 Circuit breaker closed indication X120-3,2
X120-BI3 Circuit breaker open indication X120-4,2
X120-BI4 Reset of master trip lockout X120-5,6
Table 23: Default connections for binary outputs
Binary output Default usage Connector pins
X100-PO1 Close circuit breaker X100-6,7
X100-PO2 Circuit breaker failure protection trip to upstream
breaker
X100-8,9
X100-PO3 Open circuit breaker/trip coil 1 X100-15,16,17,18,1
9
X100-PO4 Open circuit breaker/trip coil 2 X100-20,21,22,23,2
4
X100-SO1 General start indication X100-10,11,12
X100-SO2 General operate indication X100-13,14,15
Section 3 1MRS756378 K
REF615 standard configurations
68 REF615
Application Manual
Table 24: Default connections for LEDs
LED Default usage
1 Non-directional overcurrent operate
2 Non-directional earth fault operate
3 Sensitive earth fault operate
4 Negative seq. overcurrent/phase discontinuity operate
5 Thermal overload alarm
6 Breaker failure operate
7 Disturbance recorder triggered
8 Not connected
9 Trip circuit supervision alarm
10 Arc protection operate
11 Auto reclose in progress
3.6.2.2 Default disturbance recorder settings
Table 25: Default analog channel selection and text settings
Channel Selection and text
Additionally, all the digital inputs that are connected by default are also enabled
with the setting. Default triggering settings are selected depending on the
connected input signal type. Typically all protection START signals are selected to
trigger the disturbance recorded by default.
1MRS756378 K Section 3
REF615 standard configurations
REF615 69
Application Manual
3.6.3 Functional diagrams
The functional diagrams describe the default input, output, alarm LED and functionto-function connections. The default connections can be viewed and changed with
PCM600 according to the application requirements, if necessary.
The analog channels have fixed connections towards the different function blocks
inside the IED’s standard configuration. Exceptions from this rule are the 12
analog channels available for the disturbance recorder function. These channels are
freely selectable and a part of the disturbance recorder’s parameter settings.
The analog channels are assigned to different functions. The common signal
marked with 3I represents the three phase currents. The signal marked with Io
represents the measured residual current via a summation connection of the phase
current transformers.
3.6.3.1 Functional diagrams for protection
The functional diagrams describe the IED’s protection functionality in detail and
picture the factory set default connections.
Section 3 1MRS756378 K
REF615 standard configurations
70 REF615
Application Manual
A071348 V3 EN
Figure 30: Overcurrent protection
Four overcurrent stages are offered for overcurrent and short-circuit protection.
The instantaneous stage (PHIPTOC1) can be blocked by energizing the binary
input 1 (X120:1-2). Two negative sequence overcurrent stages (NSPTOC1 and
NSPTOC2) are offered for phase unbalance protection. The inrush detection
block’s (INRPHAR1) output BLK2H enables either blocking the function or
multiplying the active settings for any of the described protection function blocks.
All operate signals are connected to the Master Trip and to the alarm LEDs. LED 1
is used for overcurrent and LED 4 for negative-sequence overcurrent protection
