例如，一次旅行的主人 VMIVME-7750 VMIVME-7750-746001 350-027750-746001 VMIVME-7750 VMIVME-7750-746001 350-027750-746001Two separate trip circuit supervision functions are included, TCSSCBR1 for PO3
(X100:15-19) and TCSSCBR2 for PO4 (X100:20-24). Both functions are blocked
by the Master Trip (TRPPTRC1 and TRPPTRC2) and the circuit breaker open
signal. The TCS alarm indication is connected to LED 9.
By default it is expected that there is no external resistor in the
circuit breaker tripping coil circuit connected parallel with circuit
breaker normally open auxiliary contact.
3.6.3.3 Functional diagrams for control and interlocking
A071358 V4 EN
Figure 35: Master trip
The operate signals from the protections are connected to the two trip output
contacts PO3 (X100:15-19) and PO4 (X100:20-24) via the corresponding Master
Trips TRPPTRC1 and TRPPTRC2. Open control commands to the circuit breaker
from local or remote CBXCBR1-exe_op or from the auto-recloser DARREC1-
open_cb are connected directly to the output PO3 (X100:15-19).
TRPPTRC1 and 2 provide the lockout/latching function, event generation and the
trip signal duration setting. If the lockout operation mode is selected, one binary
Section 3 1MRS756378 K
REF615 standard configurations
76 REF615
Application Manual
input can be reassigned to the RST_LKOUT input of the Master Trip to enable
external reset with a push button.
A071360 V4 EN
Figure 36: Circuit breaker control
The ENA_CLOSE input, which enables the closing of the circuit breaker, is a
status of the Master Trip in the breaker control function block CBXCBR. The open
operation is always enabled.
If the ENA_CLOSE signal is completely removed from the breaker
control function block CBXCBR with PCM600, the function
assumes that the breaker close commands are allowed continuously.
1MRS756378 K Section 3
REF615 standard configurations
REF615 77
Application Manual
PHLPTOC1-start
PHHPTOC1-start
PHHPTOC2-start
PHIPTOC1-start
NSPTOC1-start
NSPTOC2-start
PDNSPTOC1-start
PDNSPTOC1-operate
PHLPTOC1-operate PHHPTOC1-operate PHHPTOC2-operate PHIPTOC1-operate NSPTOC1-operate NSPTOC2-operate ARCSARC1-operate ARCSARC2-operate ARCSARC3-operate
EFLPTOC1-start
EFHPTOC1-start
EFIPTOC1-start
EFLPTOC2-start
EFLPTOC1-operate EFHPTOC1-operate EFIPTOC1-operate TPGAPC1 IN1 OUT1 IN2 OUT2 +
+
X100
10
11
12
13
14
EFLPTOC2-operate OR
OR
COMMON ALARM / INDICATION 1 & 2
Start Indication
Operate Indication SO1
SO2
A071362 V4 EN
Figure 37: Alarm indication
The signal outputs from the IED are connected to give dedicated information on:
• Start of any protection function SO1 (X100:10-12)
• Operation (trip) of any protection function SO2 (X100:13-14)
TPGAPC are timers and used for setting the minimum pulse length for the outputs.
There are four generic timers (TPGAPC1..4) available in the IED. The remaining
ones not described in the functional diagram are available in PCM600 for
connection where applicable.
3.7 Standard configuration D
3.7.1 Applications
The standard configuration for non-directional overcurrent and non-directional earthfault protection is mainly intended for cable and overhead-line feeder applications
in directly or resistance earthed distribution networks.
The IED with a standard configuration is delivered from the factory with default
settings and parameters. The end-user flexibility for incoming, outgoing and
internal signal designation within the IED enables this configuration to be further
adapted to different primary circuit layouts and the related functionality needs by
modifying the internal functionality using PCM600.
Section 3 1MRS756378 K
REF615 standard configurations
78 REF615
Application Manual
3.7.2 Functions
Table 26: Functions included in the standard configuration D
Function IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional overcurrent
protection, low stage, instance 1 PHLPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional overcurrent
protection, high stage, instance 1 PHHPTOC1 3I>> (1) 51P-2 (1)
Three-phase non-directional overcurrent
protection, high stage, instance 2 PHHPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional overcurrent
protection, instantaneous stage, instance 1 PHIPTOC1 3I>>> (1) 50P/51P (1)
Non-directional earth-fault protection, low
stage, instance 1 EFLPTOC1 Io> (1) 51N-1 (1)
Non-directional earth-fault protection, low
stage, instance 2 EFLPTOC2 Io> (2) 51N-1 (2)
Non-directional earth-fault protection, high
stage, instance 1 EFHPTOC1 Io>> (1) 51N-2 (1)
Non-directional earth-fault protection,
instantaneous stage EFIPTOC1 Io>>> 50N/51N
Harmonics based earth-fault protection HAEFPTOC1 Io>HA 51NHA
Negative-sequence overcurrent protection,
instance 1 NSPTOC1 I2> (1) 46 (1)
Negative-sequence overcurrent protection,
instance 2 NSPTOC2 I2> (2) 46 (2)
Phase discontinuity protection PDNSPTOC1 I2/I1> 46PD
Three-phase thermal protection for feeders,
cables and distribution transformers T1PTTR1 3Ith>F 49F
Circuit breaker failure protection CCBRBRF1 3I>/Io>BF 51BF/51NBF
Three-phase inrush detector INRPHAR1 3I2f> 68
Master trip, instance 1 TRPPTRC1 Master Trip (1) 94/86 (1)
Master trip, instance 2 TRPPTRC2 Master Trip (2) 94/86 (2)
Arc protection, instance 1 ARCSARC1 ARC (1) 50L/50NL (1)
Arc protection, instance 2 ARCSARC2 ARC (2) 50L/50NL (2)
Arc protection, instance 3 ARCSARC3 ARC (3) 50L/50NL (3)
Control
Circuit-breaker control CBXCBR1 I <-> O CB I <-> O CB
Disconnector control, instance 1 DCXSWI1 I <-> O DCC
(1)
I <-> O DCC
(1)
Disconnector control, instance 2 DCXSWI2 I <-> O DCC
(2)
I <-> O DCC
(2)
Earthing switch control ESXSWI1 I <-> O ESC I <-> O ESC
Disconnector position indication, instance 1 DCSXSWI1 I <-> O DC (1) I <-> O DC (1)
Disconnector position indication, instance 2 DCSXSWI2 I <-> O DC (2) I <-> O DC (2)
Disconnector position indication, instance 3 DCSXSWI3 I <-> O DC (3) I <-> O DC (3)
Table continues on next page
1MRS756378 K Section 3
REF615 standard configurations
REF615 79
Application Manual
Function IEC 61850 IEC 60617 IEC-ANSI
Earthing switch indication, instance 1 ESSXSWI1 I <-> O ES (1) I <-> O ES (1)
Earthing switch indication, instance 2 ESSXSWI2 I <-> O ES (2) I <-> O ES (2)
Auto-reclosing DARREC1 O -> I 79
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement, instance 1 CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Residual current measurement, instance 1 RESCMMXU1 Io In
3.7.2.1 Default I/O connections
Table 27: Default connections for binary inputs
Binary input Default usage Connector pins
X110-BI2 Auto reclose external start command X110-3,4
X110-BI3 Circuit breaker low gas pressure indication X110-5,6
X110-BI4 Circuit breaker spring charged indication X110-6,7
X110-BI5 Circuit breaker truck in (service position) indication X110-8,9
X110-BI6 Circuit breaker truck out (test position) indication X110-10,9
X110-BI7 Earthing switch closed indication X110-11,12
X110-BI8 Earthing switch open indication X110-13,12
X120-BI1 Blocking of overcurrent instantaneous stage X120-1,2
X120-BI2 Circuit breaker closed indication X120-3,2
X120-BI3 Circuit breaker open indication X120-4,2
X120-BI4 Reset of master trip lockout X120-5,6
Table 28: Default connections for binary outputs
Binary output Default usage Connector pins
X100-PO1 Close circuit breaker X100-6,7
X100-PO2 Circuit breaker failure protection trip to upstream
breaker
X100-8,9
X100-PO3 Open circuit breaker/trip coil 1 X10 VMIVME-7750 VMIVME-7750-746001 350-027750-746001 | VMIVME-7750 VMIVME-7750-746001 350-027750-746001 | | | | |
