IC698CMX016-ED VMIVME-5567-000 350-005567-000 E隔离开关位置指示，例如3 DCSXSWI3 I<->O DC（3）I<->O DC（2）
下一页续表
1MRS756378 K第3节
REF615标准配置
参考文献615:79
应用手册
功能IEC 61850 IEC 60617 IEC-ANSI
接地开关指示，例如1 ESSXSWI1 I<->O ES（1）I<->O ES（2）
接地开关指示，例如2 ESSXSWI2 I<->O ES（2）I<->O ES（3）
自动重合闸DARREC1 O->I 79
状态监测
断路器状态监测SSCBR1 CBCM CBCM
跳闸电路监控，例如1 TCSCBR1 TCS（1）TCM（1）
跳闸电路监控，实例2 TCSCBR2 TCS（2）TCM（2）
测量
干扰记录器RDRE1--
三相电流测量，例如1 CMMXU1 3I 3I
顺序电流测量CSMSQI1 I1、I2、I0 I1、I2、I2
剩余电流测量，实例1 RESCMMSU1 Io In
3.7.2.1默认I/O连接
表27：二进制输入的默认连接
二进制输入默认使用连接器引脚
X110-BI2自动重合闸外部启动命令X110-3,4
X110-BI3断路器低气压指示X110-5,6
X110-BI4断路器弹簧充电指示X110-6,7
X110-BI5断路器台车处于（工作位置）指示X110-8,9
X110-BI6断路器卡车出（测试位置）指示X110-10,9
X110-BI7接地开关闭合指示X110-11,12
X110-BI8接地开关断开指示X110-13,12
X120-BI1阻断过电流瞬时级X120-1,2
X120-BI2断路器闭合指示X120-3,2
X120-BI3断路器断开指示X120-4,2
X120-BI4主跳闸闭锁复位X120-5,6
表28：二进制输出的默认连接
二进制输出默认使用连接器引脚
X100-PO1闭合断路器X100-6,7
X100-PO2断路器故障保护跳闸至上游
断路器
X100-8,9
X100-PO3断路器/跳闸线圈1 X100-15,16,17,18,1
9
X100-PO4断路器/跳闸线圈2 X100-20,21,22,23,2
4.
X100-SO1一般启动指示X100-10,11,12
X100-SO2一般操作指示X100-13,14,15
下一页续表
第3节1MRS756378 K
REF615标准配置
80参考文献615
应用手册
二进制输出默认使用连接器引脚
X110-SO1上游过电流闭锁X110-14,15,16
X110-SO2过电流运行报警X110-17,18,19
X110-SO3接地故障操作报警X110-20,21,22
表29：LED的默认连接
LED默认使用
1.无方向过电流运行
2.非定向接地故障运行
3.敏感接地故障操作
4负序列。过电流/相位不连续运行
5热过载报警
6断路器故障操作
7干扰记录器触发
8断路器状态监测报警
9跳闸电路监控报警
10.电弧保护操作
11自动重合闸正在进行 IC698CMX016-ED VMIVME-5567-000 350-005567-000 E
 IC698CMX016-ED VMIVME-5567-000 350-005567-000 E
Disconnector position indication, instance 3 DCSXSWI3 I <-> O DC (3) I <-> O DC (3)
Table continues on next page
1MRS756378 K Section 3
REF615 standard configurations
REF615 79
Application Manual
Function IEC 61850 IEC 60617 IEC-ANSI
Earthing switch indication, instance 1 ESSXSWI1 I <-> O ES (1) I <-> O ES (1)
Earthing switch indication, instance 2 ESSXSWI2 I <-> O ES (2) I <-> O ES (2)
Auto-reclosing DARREC1 O -> I 79
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement, instance 1 CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Residual current measurement, instance 1 RESCMMXU1 Io In
3.7.2.1 Default I/O connections
Table 27: Default connections for binary inputs
Binary input Default usage Connector pins
X110-BI2 Auto reclose external start command X110-3,4
X110-BI3 Circuit breaker low gas pressure indication X110-5,6
X110-BI4 Circuit breaker spring charged indication X110-6,7
X110-BI5 Circuit breaker truck in (service position) indication X110-8,9
X110-BI6 Circuit breaker truck out (test position) indication X110-10,9
X110-BI7 Earthing switch closed indication X110-11,12
X110-BI8 Earthing switch open indication X110-13,12
X120-BI1 Blocking of overcurrent instantaneous stage X120-1,2
X120-BI2 Circuit breaker closed indication X120-3,2
X120-BI3 Circuit breaker open indication X120-4,2
X120-BI4 Reset of master trip lockout X120-5,6
Table 28: Default connections for binary outputs
Binary output Default usage Connector pins
X100-PO1 Close circuit breaker X100-6,7
X100-PO2 Circuit breaker failure protection trip to upstream
breaker
X100-8,9
X100-PO3 Open circuit breaker/trip coil 1 X100-15,16,17,18,1
9
X100-PO4 Open circuit breaker/trip coil 2 X100-20,21,22,23,2
4
X100-SO1 General start indication X100-10,11,12
X100-SO2 General operate indication X100-13,14,15
Table continues on next page
Section 3 1MRS756378 K
REF615 standard configurations
80 REF615
Application Manual
Binary output Default usage Connector pins
X110-SO1 Upstream overcurrent blocking X110-14,15,16
X110-SO2 Overcurrent operate alarm X110-17,18,19
X110-SO3 Earth fault operate alarm X110-20,21,22
Table 29: Default connections for LEDs
LED Default usage
1 Non-directional overcurrent operate
2 Non-directional earth fault operate
3 Sensitive earth fault operate
4 Negative seq. overcurrent/phase discontinuity operate
5 Thermal overload alarm
6 Breaker failure operate
7 Disturbance recorder triggered
8 Circuit breaker condition monitoring alarm
9 Trip circuit supervision alarm
10 Arc protection operate
11 Auto reclose in progress
