6SM 77K-3.000-G-J-09-HA-IN -1功能提供与断路器相关的不同操作模式
位置和测量断路器故障保护（CCBRBRF1）通过启动输入由
IED中不同保护级的数量。断路器故障保护
功能提供与断路器相关的不同操作模式
位置以及测量的相位和剩余电流。断路器故障
保护有两个操作输出：TRRET和TRBU。TRRET运行
输出用于通过主跳闸2重新触发其自身断路器。TRBU
输出用于向断路器上游馈电提供备用跳闸。为此
目的：TRBU操作输出信号连接到输出PO2（X100:
8-9). LED 6用于备用（TRBU）操作指示。
1MRS756378 K第3节
REF615标准配置
参考文献615:85
应用手册
PHHPTOC2操作PHHPTOC1操作PHIPTOC1操作
或
电弧保护（可选）
LED10（电弧保护）
ARCSARC1运行ARCSARC2运行ARCSARC3运行
自动重合闸（可选）
或
选择PDNSPTOC1操作NSPTOC2操作CBXCBR1
LED11（AR进行中）
X110
6.
7.
X120_BI3（断路器开路）
BI4（CB弹簧充电）
DARREC1
0 -> 1
79初始化_1初始化_ 2初始化u3初始化单元4初始化 5初始化U6 DEL_INIT_2 DEL_ INIT _3 delUinitu4 BLK_RECL_T BLK_ RCLM_T BLK_THERM CB_POS CB_ READY INC_SHOTP INHIBIT_RECR_ON SYNC
OPEN_CB CLOSE_CB CMD_WAIT INPRO LOCKED PROT_CRD UNSC_RECL AR_ON READY
弧弧1
弧（1）
50L/50NL（1）3I
Io
块REM_FLT_ARC OPR_MODE
操作ARC_FLT_DET
弧弧2
弧（2）
50L/50NL（2）3I
Io
块REM_FLT_ARC OPR_MODE
操作ARC_FLT_DET
弧弧3
弧（3）
50L/50NL（3）3I
Io
块REM_FLT_ARC OPR_MODE
操作ARC_FLT_DET
EFLPTOC1操作EFHPTOC1操作X110_BI2（AR外部启动）
A071370 V5 EN
图41：电弧保护
电弧保护（ARCSARC1…3）和自动重合闸（DARREC1）包括在：
可选功能。
第3节1MRS756378 K
REF615标准配置
86参考文献615
应用手册
电弧保护为三个电弧传感器提供单独的功能块，可以：
连接到IED。每个电弧保护功能块有两个不同的
运行模式，带或不带相位和剩余电流检查。运转
来自电弧保护功能块的信号连接到主跳闸
并且还连接到报警LED 10作为公共操作指示。
自动重合闸被配置为通过来自多个
通过INIT1…5输入的保护级。自动重合闸中的INIT6输入
功能块由二进制输入2（X110:3-4）控制，允许使用
外部启动命令。可以为以下对象创建单独的自动重合序列：
每个输入。
自动重合闸功能可通过INHIBIT_RECL输入被阻断。通过
默认情况下，所选保护功能的操作连接到此输入。A.
对本地或远程断路器的控制命令也会阻止
通过CBXCBR选择信号自动重合闸功能。
自动重合闸序列的断路器可用性表示为：
DARREC1中的CB_READY输入。在配置中，该信号未连接
到任何二进制输入。因此，该功能假设断路器为
随时可用。
正在进行的自动重合闸序列指示连接至报警LED
6SM 77K-3.000-G-J-09-HA-IN -1
 6SM 77K-3.000-G-J-09-HA-IN -1
function offers different operating modes associated with the circuit breaker
position and the measurThe breaker failure protection (CCBRBRF1) is initiated via the start input by a
number of different protection stages in the IED. The breaker failure protection
function offers different operating modes associated with the circuit breaker
position and the measured phase and residual currents. The breaker failure
protection has two operating outputs: TRRET and TRBU. The TRRET operate
output is used for retripping its own breaker through the Master Trip 2. The TRBU
output is used to give a back-up trip to the breaker feeding upstream. For this
purpose, the TRBU operate output signal is connected to the output PO2 (X100:
8-9). LED 6 is used for back-up (TRBU) operate indication.
1MRS756378 K Section 3
REF615 standard configurations
REF615 85
Application Manual
PHHPTOC2-operate PHHPTOC1-operate PHIPTOC1-operate
OR
ARC PROTECTION (Optional)
LED10 (ARC PROTECTION)
ARCSARC1-operate ARCSARC2-operate ARCSARC3-operate
AUTORECLOSING (Optional)
OR
PDNSPTOC1-operate NSPTOC1-operate NSPTOC2-operate CBXCBR1-selected
LED11 (AR IN PROGRESS)
X110
6
7
X120_BI3 (CB Open)
BI4 (CB Spring Charged)
DARREC1
0 -> 1
79 INIT_1 INIT_2 INIT_3 INIT_4 INIT_5 INIT_6 DEL_INIT_2 DEL_INIT_3 DEL_INIT_4 BLK_RECL_T BLK_RCLM_T BLK_THERM CB_POS CB_READY INC_SHOTP INHIBIT_RECL RECL_ON SYNC
OPEN_CB CLOSE_CB CMD_WAIT INPRO LOCKED PROT_CRD UNSUC_RECL AR_ON READY
ARCSARC1
ARC (1)
50L/50NL (1) 3I
Io
BLOCK REM_FLT_ARC OPR_MODE
OPERATE ARC_FLT_DET
ARCSARC2
ARC (2)
50L/50NL (2) 3I
Io
BLOCK REM_FLT_ARC OPR_MODE
OPERATE ARC_FLT_DET
ARCSARC3
ARC (3)
50L/50NL (3) 3I
Io
BLOCK REM_FLT_ARC OPR_MODE
OPERATE ARC_FLT_DET
EFLPTOC1-operate EFHPTOC1-operate X110_BI2 (AR ext. Start)
A071370 V5 EN
Figure 41: Arc protection
Arc protection (ARCSARC1...3) and autoreclosing (DARREC1) are included as
optional functions.
Section 3 1MRS756378 K
REF615 standard configurations
86 REF615
Application Manual
The arc protection offers individual function blocks for three arc sensors that can
be connected to the IED. Each arc protection function block has two different
operation modes, with or without the phase and residual current check. Operate
signals from the arc protection function blocks are connected to the Master Trip
and also to the alarm LED 10 as a common operate indication.
The autorecloser is configured to be initiated by operate signals from a number of
protection stages through the INIT1...5 inputs. The INIT6 input in the autorecloser
function block is controlled by a binary input 2 (X110:3-4) enabling the use of the
external start command. It is possible to create individual autoreclose sequences for
each input.
The autoreclose function can be blocked with the INHIBIT_RECL input. By
default, the operation of selected protection functions are connected to this input. A
control command to the circuit breaker, either local or remote, also blocks the
autoreclose function via the CBXCBR-selected signal.
The circuit breaker availability for the autoreclosure sequence is expressed with the
CB_READY input in DARREC1. In the configuration, this signal is not connected
to any of the binary inputs. As a result, the function assumes that the breaker is
available all the time.
The autoreclose sequence in progress indication is connected to the alarm LED 6SM 77K-3.000-G-J-09-HA-IN -1
| | | |
