.电弧保护，实例2电弧2电弧（2）50L/50NL（2）
电弧保护，例如3弧电弧3弧（3）50L/50NL（3）
控制
断路器控制CBXCBR1 I<->O断路器I<->O断路器
隔离开关控制，例如1 DCXSWI1 I<->O DCC
(1)
I<->O DCC
(1)
隔离开关控制，实例2 DCXSWI2 I<->O DCC
(2)
I<->O DCC
(2)
接地开关控制ESXSWI1 I<->O ESC I<->O ESC
隔离开关位置指示，例如1 DCSXSWI1 I<->O DC（1）I<->O DC（2）
隔离开关位置指示，例如2 DCSXSWI2 I<->O DC（2）I<->O DC（1）
隔离开关位置指示，例如3 DCSXSWI3 I<->O DC（3）I<->O DC（2）
接地开关指示，例如1 ESSXSWI1 I<->O ES（1）I<->O ES（2）
接地开关指示，例如2 ESSXSWI2 I<->O ES（2）I<->O ES（3）
自动重合闸DARREC1 O->I 79
状态监测
断路器状态监测SSCBR1 CBCM CBCM
跳闸电路监控，例如1 TCSCBR1 TCS（1）TCM（1）
跳闸电路监控，实例2 TCSCBR2 TCS（2）TCM（2）
电流电路监控CCRDIF1 MCS 3I MCS 3I
保险丝故障监控SEQRFUF1 FUSEF 60
测量
干扰记录器RDRE1--
三相电流测量，例如1 CMMXU1 3I 3I
顺序电流测量CSMSQI1 I1、I2、I0 I1、I2、I2
下一页续表
第3节1MRS756378 K
REF615标准配置
94参考文献615
应用手册
功能IEC 61850 IEC 60617 IEC-ANSI
剩余电流测量，实例1 RESCMMSU1 Io In
三相电压测量VMMXU1 3U 3U
剩余电压测量RESVMMXU1 Uo Vn
序列电压测量VSMSQI1 U1、U2、U0 U1、U2、U2
三相功率和能量测量PEMMXU1 P、E P、E
3.8.2.1默认I/O连接
表33：二进制输入的默认连接
二进制输入默认使用连接器引脚
X110-BI1 MCB开路X110-1,2
X110-BI2方向接地故障保护的基本角度控制X110-3,4
X110-BI3断路器低压报警X110-5,6
X110-BI4断路器弹簧充电指示X110-7,6
X110-BI5断路器台车处于（工作位置）指示X110-8,9
X110-BI6断路器卡车出（测试位置）指示X110-10,9
X110-BI7接地开关闭合指示X110-11,12
X110-BI8接地开关断开指示X110-13,12
X120-BI1阻断过电流瞬时级X120-1,2
X120-BI2断路器闭合指示X120-3,2
X120-BI3断路器断开指示X120-4,2
X120-BI4锁定复位X120-5,6
表34：二进制输出的默认连接
二进制输出默认使用连接器引脚
X100-PO1闭合断路器X100-6,7
X100-PO2断路器故障，上游断路器X100-8,9的备用跳闸
X100-SO1一般启动指示X100-10,11，（12）
X100-SO2一般操作指示X100-13,14
X100-PO3断路器/跳闸线圈1 X100-15-19
X100-PO4断路器/跳闸线圈2 X100-20-24
X110-SO1上游过电流闭锁X110-14,15
X110-SO2过电流运行报警X110-17,18
X110-SO3接地故障操作警报X110-20,21
1MRS756378 K第3节
REF615标准配置
参考文献615:95
应用手册
表35：LED的默认连接
LED默认使用
1.无方向过电流保护操作
2方向接地故障保护运行
3.双（越野）接地故障或剩余过电压保护运行
4负序过电流或相位不连续保护运行
5热过载保护运行
6.断路器故障保护，后备保护操作
7干扰记录器触发
8断路器状态m ABB 83SR07A-E GJR2392700R1210 供应DCS/PLC控制系统应用
 ABB 83SR07A-E GJR2392700R1210 供应DCS/PLC控制系统应用
Arc protection, instance 2 ARCSARC2 ARC (2) 50L/50NL (2)
Arc protection, instance 3 ARCSARC3 ARC (3) 50L/50NL (3)
Control
Circuit-breaker control CBXCBR1 I <-> O CB I <-> O CB
Disconnector control, instance 1 DCXSWI1 I <-> O DCC
(1)
I <-> O DCC
(1)
Disconnector control, instance 2 DCXSWI2 I <-> O DCC
(2)
I <-> O DCC
(2)
Earthing switch control ESXSWI1 I <-> O ESC I <-> O ESC
Disconnector position indication, instance 1 DCSXSWI1 I <-> O DC (1) I <-> O DC (1)
Disconnector position indication, instance 2 DCSXSWI2 I <-> O DC (2) I <-> O DC (2)
Disconnector position indication, instance 3 DCSXSWI3 I <-> O DC (3) I <-> O DC (3)
Earthing switch indication, instance 1 ESSXSWI1 I <-> O ES (1) I <-> O ES (1)
Earthing switch indication, instance 2 ESSXSWI2 I <-> O ES (2) I <-> O ES (2)
Auto-reclosing DARREC1 O -> I 79
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Current circuit supervision CCRDIF1 MCS 3I MCS 3I
Fuse failure supervision SEQRFUF1 FUSEF 60
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement, instance 1 CMMXU1 3I 3I
Sequence current measurement CSMSQI1 I1, I2, I0 I1, I2, I0
Table continues on next page
Section 3 1MRS756378 K
REF615 standard configurations
94 REF615
Application Manual
Function IEC 61850 IEC 60617 IEC-ANSI
Residual current measurement, instance 1 RESCMMXU1 Io In
Three-phase voltage measurement VMMXU1 3U 3U
Residual voltage measurement RESVMMXU1 Uo Vn
Sequence voltage measurement VSMSQI1 U1, U2, U0 U1, U2, U0
Three-phase power and energy measurement PEMMXU1 P, E P, E
3.8.2.1 Default I/O connections
Table 33: Default connections for binary inputs
Binary input Default usage Connector pins
X110-BI1 MCB open X110-1,2
X110-BI2 Directional earth fault protection's basic angle control X110-3,4
X110-BI3 Circuit breaker low gas pressure alarm X110-5,6
X110-BI4 Circuit breaker spring charged indication X110-7,6
X110-BI5 Circuit breaker truck in (service position) indication X110-8,9
X110-BI6 Circuit breaker truck out (test position) indication X110-10,9
X110-BI7 Earthing switch closed indication X110-11,12
X110-BI8 Earthing switch open indication X110-13,12
X120-BI1 Blocking of overcurrent instantaneous stage X120-1,2
X120-BI2 Circuit breaker closed indication X120-3,2
X120-BI3 Circuit breaker open indication X120-4,2
X120-BI4 Lock-out reset X120-5,6
Table 34: Default connections for binary outputs
Binary output Default usage Connector pins
X100-PO1 Close circuit breaker X100-6,7
X100-PO2 Breaker failure backup trip to upstream breaker X100-8,9
X100-SO1 General start indication X100-10,11,(12)
X100-SO2 General operate indication X100-13,14
X100-PO3 Open circuit breaker/trip coil 1 X100-15-19
X100-PO4 Open circuit breaker/trip coil 2 X100-20-24
X110-SO1 Upstream overcurrent blocking X110-14,15
X110-SO2 Overcurrent operate alarm X110-17,18
X110-SO3 Earth fault operate alarm X110-20,21
1MRS756378 K Section 3
REF615 standard configurations
REF615 95
Application Manual
Table 35: Default connections for LEDs
LED Default usage
1 Non-directional overcurrent protection operated
2 Directional earth-fault protection operated
3 Double (cross country) earth fault or residual overvoltage protection operated
4 Negative-sequence overcurrent or phase discontinuity protection operate ABB 83SR07A-E GJR2392700R1210 供应DCS/PLC控制系统应用
| | | |
