所有操作信号均连接至主跳闸和报警LED。LED 1
用于过电流，LED 4用于负序过电流保护
操作指示。LED 4也用于相位不连续保护操作
指示
从过电流第二高阶段开始的上游阻塞
（PHHPTOC2）连接到输出SO1（X110:14-16）。使用此输出
用于向相关过电流保护级发送闭锁信号
在进料舱安装简易爆炸装置。
第3节1MRS756378 K
REF615标准配置
98参考文献615
应用手册
DEFLPDEF1
I0>->（1）
67N-1（1）I0
U0
块ENA_MULT RCA_CTL
开动
DEFLPDEF2
I0>->（2）
67N-1（2）I0
U0
块ENA_MULT RCA_CTL
开动
DEFHPDEF1
I0>>->
67N-1 I0
U0
块ENA_MULT RCA_CTL
开动
WPWDE1
P0>->（1）
32N（1）I0
U0
块RCA_CTL
开始运行WPWDE2
P0>->（2）
32N（2）I0
U0
块RCA_CTL
开始运行WPWDE3
P0>->（3）
32N（3）I0
U0
块RCA_CTL
开动
或
INTRPTEF1
I0>
67NIEF I0
U0
块启动操作BLK_EF
EFHPTOC1
I0>>
51N-2 I0
块ENA_MULT
开始运行计算Io
LED2（EF操作）
EFPADM1
Y0>->（1）
21YN（1）I0
U0
块释放
开动
EFPADM2
Y0>->（2）
21YN（2）I0
U0
块释放
开动
EFPADM3
Y0>->（3）
21YN（3）I0
U0
块释放
开动
双人（越野）
接地故障保护
定向接地故障
保护
间歇性接地故障
保护
瓦特计接地故障
保护（可选）
接地故障导纳
保护（可选）
LED3（NEF运行）
或LED2（WDE操作）
或LED2（ADM操作）
X110
3.
4.
BI 2（BACTRL）
CCRDIF_FAIL
GUID-1F3C1F26-6F11-4250-9476-82C47C3AC570 V3 EN
图47：定向接地故障保护
提供三级定向接地故障保护。根据
命令代码，方向接地故障保护方法可基于
仅常规定向接地故障（DEFxPDEF）或同时发生
具有导纳标准（EFPADM）或功率计接地故障保护（WPWDE）
或基于谐波的接地故障保护（HAEFPTOC）。此外，还有
用于瞬态接地故障的专用保护级（INTRPTEF）
补偿网络中的电缆间歇性接地故障保护。
专用非定向接地故障保护块（EFHPTOC）旨在：
用于在隔离或补偿的情况下防止双接地故障
网络。该保护功能使用计算的剩余电流源
从相电流。
1MRS756378 K第3节
REF615标准配置
参考文献615:99
应用手册
二进制输入2（X110:3-4）用于定向接地故障保护
模块继电器特性角（RCA:0°/-90°）或运行模式（I0Sinφ/
φ）的变化。所有操作信号均连接至主跳闸装置以及
报警指示灯。LED 2用于定向接地故障，LED 3用于双接地故障保护操作指示。
GUID-3A78AEF7-8219-42C1-9BB9-FBAED53FF38F V1 EN
图48：剩余过压保护
剩余过压保护（ROVPTOV）提供接地故障保护
通过检测剩余电压的异常电平。例如，它可以用作
选择性定向接地故障的非选择性后备保护
功能。操作信号连接至报警LED 3。
第3节1MRS756378 K
REF615标准配置
100参考文献615
应用手册
EFPADM2操作PHHPTOC2操作PHHPTOC1操作PHIPTOC1操作DEFLPDEF2操作DEFHPDEF1操作或
X120_BI2（CB闭合）+PO2
8.
9
X100
LED6（CBFP操作）
上游断路器CCBRBRF1的CBFP跳闸
3I>/Io->BF
51BF/51NBF 3I
Io
启动POSCLOSE CB_FAULT块
TRRET TRBU CB_FAULT_AL
PDNSTOC1
I2/I1
46PD 3I
闭塞启动操作
T1PTTR1
3 >
49F 3I
BLK_OPR ENA_MULT
操作报警BLK_CLOSE START
热过载保护
相位不连续保护
断路器故障保护
LED5（过载报警）
LED4（NPS/PD运行）
WPWDE2操作WPWDE3操作
EFPADM3运行电弧ARC1运行电弧ARC2运行电弧ARC3运行
CCRDIF_FAIL
GUID-8BD4614B-2C4D-475E-ADC3-A376E213BF3C V3 EN
图49：相位不连续、热过载和断路器故障
保护
相位不连续性保护（PDNPSTOC1）提供以下保护：
正常三相负载供电中断，例如，在停机时
指挥情况。相位不连续保护的操作信号为：
连接到主跳闸，也连接到报警LED和干扰
录音机热过载保护（T1PTTR1）提供以下指示：
超载情况。热过载保护的操作信号为：
连接到主跳闸和报警LED。LED 4用于
相位不连续保护操作指示，与负极相同
顺序过电流保护操作指示，LED 5用于
热过载保护报警指示。
